1997 FORD F250 Owners Manual

105 %
*
[SS08080(F )01/96]
Using the Power Seats (If equipped)
*
[SS08090(F )01/96]
If your vehicle has the power seat option, you
can adjust it in several directions. The controls
are on the outboard side of the seat.
[SS08100(F )04/96]
half page art:0021084-A
The power controls on the 40/20/40 seat Ð SuperCab
driver's seat only
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

106 %
*
[SS08120(F )01/96]
Using the Power Lumbar Support and Side
Bolsters (if equipped)
[SS08130(F )04/96]
If your vehicle is equipped with this option, you
can inflate a lumbar support pad in the seat
back. To inflate the lumbar pad, push the (+)
side of the rocker switch. To deflate push the (-)
side of the switch.
[SS08140(F )04/96]
quarter page art:0020860-B
Power lumbar switch
[SS08150(F )04/96]
quarter page art:0021085-A
Power lumbar switch - 40/20/40 seat
[SS08160(F )05/96]
Using Manual Lumbar Support
(if equipped)
[SS08170(F )05/96]
Rotate the control on the seat to increase or
decrease the lumbar support.
[SS08180(F )05/96]
quarter page art:0021630-AFile:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

107
%*
[SS10500(F )02/96]
Important Safety Belt Information
*
[SS10600(F )02/96]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
*
[SS10700(F )02/96]
Safety belts provide best restraint when:
*
[SS10750(F )03/96]
RWARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, failure to do so may increase the
risk of personal injury in the event of a
collision.
*
[SS10800(F )02/96]
q
the seatback is upright
*
[SS10900(F )02/96]
q
the occupant is sitting upright (not slouched)
*
[SS11000(F )02/96]
q
the lap belt is snug and low on the hips
*
[SS11100(F )02/96]
q
the shoulder belt is snug against the chest
*
[SS11200(F )02/96]
q
the knees are straight forward
*
[SS11300(F )02/96]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety Belt Warning Light and Chimein
theInstrumentationchapter.
*
[SS11500(F )02/96]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

108
*
[SS11600(F )02/96]
RWARNING
Always drive and ride with your seatback
upright and the lap belt snug and low
across the hips.
*
[SS11650(F )05/96]
RWARNING
It is extremely dangerous to ride in a
cargo area, inside or outside of a vehicle.
In a collision, people riding in these areas
are more likely to be seriously injured or
killed. Do not allow people to ride in any
area of your vehicle that is not equipped
with seats and safety belts. Be sure
everyone in your vehicle is in a seat and
using a safety belt properly.
*
[SS11700(F )05/96]
RWARNING
Cargo should always be secured to
prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
*
[SS11800(F )02/96]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SS11900(F )02/96]
RWARNING
Children should always ride with the
seatback in the fully upright position.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

109
*
[SS12000(F )05/96]
RWARNING
Each seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair. 1)
Use the shoulder belt on the outside
shoulder only. Never wear the shoulder
belt under the arm. 2) Never swing it
around your neck over the inside
shoulder. 3) Never use a single belt for
more than one person.
*
[SS12100(F )02/96]
RWARNING
Lock the doors of your vehicle before
driving to lessen the risk of the door
coming open in a collision.
% [SS12150(F )05/96]
Dual Locking Mode Retractors
[SS12200(F )01/96]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for
front seat passenger and rear seat outboard
passengers.
[SS12500(F )01/96]
Vehicle Sensitive (Emergency) Locking Mode
*
[SS12600(F )01/96]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering or impacts of approximately
5 mph (8 km/h) or more.
[SS12700(F )01/96]
The front seat belt retractor can also be made to
lock by pulling/jerking on the belt.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

110 % [SS12800(F )01/96]Automatic Locking Mode
*
[SS12900(F )08/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and remain
locked when the combination lap/shoulder
safety belt is buckled, and does not allow the
occupant freedom of movement. This mode
provides the following:
*
[SS13000(F )01/96]
q
A tight lap/shoulder belt fit on occupant
[SS13100(F )01/96]
q
Child seat/infant carrier installation restraint
[SS13300(F )01/96]
This mode must be used when installing a child
seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
[SS13400(F )01/96]
To switch the retractor from the ªemergency
locking modeº to the ªautomatic locking mode,º
perform the following steps:
*
[SS13500(F )02/96]
1. Buckle the lap/shoulder combination belt.
[SS13600(F )01/96]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted, and when allowed to retract, a
clicking sound will be heard. At this time,
the belt retractor is in the ªautomatic locking
modeº (child restraint mode).
[SS13700(F )01/96]
3. A clicking sound will continue to be heard
as the belt is allowed to retract. This
indicates that the retractor is in the
ªautomatic locking mode.º
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

111 [SS13750(F )05/96]
How to cancel the Automatic Locking
Mode:
[SS13775(F )05/96]
Disconnect the combination lap and shoulder
belt and allow it to completely retract to cancel
the Automatic Locking Mode and be in the
Vehicle Sensitive (Emergency) Mode.
[SS13800(F )01/96]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch back to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
%
*
[SS14350(F )02/96]
Combination Lap and Shoulder
Belts
[SS14400(F )04/96]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, corner hard or if
your truck receives an impact of 5 mph
(8 km/h) or more, the combination lap/shoulder
belt locks and helps reduce your forward
movement. The front seat belt systems can also
be made to lock by jerking on the shoulder belt.
[SS14450(F )04/96]
NOTE: The rear belts cannot be made to lock
up by jerking on shoulder belt.
*
[SS14500(F )01/96]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SS14600(F )01/96]
To fasten the belt
*
[SS14700(F )02/96]
Pull the combination lap/shoulder belt from the
retractor so that the shoulder portion of the belt
crosses your shoulder and chest. Be sure the belt
is not twisted. If it is, remove the twist. Insert
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

112the belt tongue into the proper buckle until you
hear a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
[SS14800(F )01/96]
10-1/2 pica art:0020639-D*
[SS15100(F )05/96]
RWARNING
Each seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair. 1)
Use the shoulder belt on the outside
shoulder only. Never wear the shoulder
belt under the arm. 2) Never swing it
around your neck over the inside
shoulder. 3) Never use a single belt for
more than one person.
*
[SS15200(F )01/96]
To tighten the lap portion of the belt, pull up on
the shoulder belt until it fits you snugly. The
belt should rest as low on your hips as possible.
*
[SS15400(F )01/96]
Due to folding rear seats, sometimes the buckles
and tongues toward the center of the vehicle
may be hidden by the rear edge of the seat
cushion. Pull them out so they will be accessible.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com
