1997 FORD F250 Owners Manual

266 [MC07900(FM)05/96]
quarter page art:0021609-AEngine oil dipstick (5.8L engine)
[MC07910(FM)05/96]
quarter page art:0021601-A
Engine oil dipstick (7.5L engine)
*
[MC08000(FM)01/96]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QT.º line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in FULL, engine
damage or high oil consumption may occur
and some oil must be removed from the
engine.
*
[MC08100(FM)01/96]
7. Put the dipstick back in and make sure it is
fully seated.
*
[MC08200(FM)01/96]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[MC08300(FM)01/96]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

267 %
*
[MC08400(FM)01/96]
Changing the Engine Oil and the Oil Filter
*
[MC08500(FM)01/96]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[MC08600(F )01/96]
one third page art:0060618-C
Oil change intervals
[MC08800(FM)04/96]
NOTE: Idling the engine for extended periods
will accumulate more hours of use on
your vehicles than is actually indicated
by the mileage odometer.
Consequently, the odometer reading
can be often misleading when
determining the right time to change
your engine oil and filter.
[MC08900(F )04/96]
If you are using your Ford vehicle in a manner
which allows it to remain stationary while the
engine is running for long periods (door to
door delivery, taxi, police, power/utility
company trucks, or similar duty), then Ford
recommends you increase the frequency of oil
and filter changes to an interval equivalent to
200 ENGINE HOURS of use. Since most
vehicles are not equipped with hourmeters, it
may be necessary for you to approximate your
idle time and plan oil/filter changes
accordingly.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

268 [MC09000(F )04/96]If the above conditions do not apply, change
the engine oil and oil filter every 6 months or
5,000 miles (8,000 km), whichever comes first.
*
[MC09100(FM)02/96]
Refer to theMaintenance Schedulebooklet for
additional information.
[MC09200(F )04/96]
NOTE: Refer to thePower Stroke Diesel Engine
Owner's Guide Supplementfor oil
viscosity, filter application and oil and
filter change intervals.
%*
[MC09300(FM)04/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[MC09400(FM)01/96]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[MC09500(FM)01/96]
Protect your skin by washing with soap and
water.
%
*
[MC09600(FM)01/96]
Brake Fluid
*
[MC09625(FM)01/96]
Your vehicle is equipped with a brake fluid level
indicator in the master cylinder which lights the
BRAKE warning light on the instrument panel
when the brake fluid level is low.
*
[MC09650(FM)01/96]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
*
[MC09675(FM)01/96]
Check the brake fluid at least once a year. You
can do this by looking at the fluid level in the
plastic brake fluid reservoir on the master
cylinder. The fluid level should be at or near the
MAX mark.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

269
*
[MC09700(FM)01/96]
RWARNING
Brake fluid is toxic.
*
[MC09725(FM)01/96]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
%*
[MC09750(FM)03/96]
If the fluid is low, carefully clean and remove
the filler cap from the reservoir. Fill the
reservoir to the MAX line with Ford High
Performance DOT 3 Brake Fluid C6AZ-19542-AB
or DOT 3 equivalent fluid meeting Ford
specification ESA-M6C25-A.
*
[MC09775(FM)01/96]
NOTE: If brake fluid is spilled on painted
surfaces, it must be flushed and wiped
away immediately. Brake fluid may
dissolve the paint finish on your
vehicle.
*
[MC09800(FM)01/96]
RWARNING
If you use a brake fluid that is not DOT
3, you will cause permanent damage to
your brakes.
*
[MC09825(FM)01/96]
Do not fill the reservoir above the MAX line.
*
[MC09850(FM)01/96]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
*
[MC09875(FM)01/96]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

270 [MC09900(F )04/96]
quarter page art:0020381-ABrake master cylinder
%*
[MC10400(F )01/96]
The Clutch
*
[MC10450(F )01/96]
The clutch on your vehicle is automatically
self-adjusting and should not require any routine
service.
*
[MC10500(F )01/96]
During normal operation the fluid level in the
clutch reservoir will slowly rise. If for any
reason the fluid level drops, maintain the fluid
level at the step in the reservoir body.
*
[MC10525(F )05/96]
one third page art:0020377-A
Clutch fluid reservoir
%*
[MC10550(F )05/96]
If it becomes necessary to remove the reservoir
cap, thoroughly clean the reservoir cap before
removing it to prevent dirt or water from
entering the reservoir. Remove the internal
diaphragm and then add only a DOT 3 brake
fluid such as Ford High Performance DOT 3
Brake Fluid (Ford Part Number C6AZ-19542-AB)
meeting Ford specification ESA-M6C25-A.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

271
%*
[MC10700(FM)01/96]
Driveline Universal Joint and Slip
Yoke
*
[MC10750(F )03/96]
The universal joints that come standard with
your vehicle do not require lubrication. If your
original equipment universal joints are replaced
with universal joints equipped with grease
fittings, lubrication will be necessary at the
intervals shown in theMaintenance Schedule
booklet.
*
[MC10850(F )01/96]
Your vehicle may be equipped with a constant
velocity or double cardan joint at the transfer
case end of the driveshaft. The front driveshaft
double cardan joint may be fitted with a flush
type grease fitting that requires an adapter to
permit proper lubrication. Lubricate the drive
joint according to the intervals shown in the
Maintenance Schedulebooklet.
[MC10875(F )04/96]
quarter page art:0020379-A
Double cardan joint
%*
[MC10900(F )02/96]
Windshield Washer Fluid
%*
[MC10950(F )03/96]
Washer Fluid
*
[MC11000(F )02/96]
Check the level of the windshield washer fluid
every time you stop for fuel. The reservoir for
the windshield washer fluid is located in the
engine compartment.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

272
*
[MC11050(F )01/96]
Adding washer fluid
*
[MC11100(F )01/96]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
[MC11150(F )04/96]
quarter page art:0020360-C
Adding windshield washer fluid
%*
[MC11300(F )02/96]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOCs) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
*
[MC11350(F )01/96]
If you choose to use a windshield washing
solution that must be mixed, follow the
manufacturer's mixing instructions. Improperly
mixed solutions may freeze unexpectedly.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

273 [MC11400(F )01/96]
NOTE: The addition of shields to the front of
the vehicle, as used to deflect bugs,
may also adversely affect the washer
system from delivering fluid to the
windshield. Devices such as bug
shields are not recommended to be
added to your new Ford product.
%
*
[MC11450(F )02/96]
Wiper Blades
*
[MC11500(F )01/96]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Such substances as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
*
[MC11550(F )01/96]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear water. Do
not use fuel, kerosene, paint thinner, or other
solvents to clean your wiper blades. These will
damage your blades.
*
[MC11600(F )01/96]
To make reaching the wiper blades easy, simply
turn the ignition switch to ACC and turn your
wipers on. Wait for them to reach a vertical
position and turn the ignition to OFF. Do not
move the wipers manually. Moving the wipers
manually may damage them.
*
[MC11650(F )02/96]
Wiper blade replacement
[MC11675(F )04/96]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent.
