1997 FORD F250 radio controls

28
%*
[AS01200(F )10/95]
Compact Disc Radio
*
[AS01250(F )10/95]
The Compact Disc Radio combines the Electronic
Stereo Radio with the Ford Compact Disc Player.
*
[AS01300(F )08/95]
Using the Controls on Your New Radio/CD
Player
*
[AS01400(F )10/95]
Most of the features of this unit work for both
radio and CD operation. Also, some of the knobs
and buttons control several different functions,
so be sure to read all of the operating
instructions carefully.
*
[AS01500(F )03/96]
How to turn the radio on and off
*
[AS01600(F )10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS01625(F )03/96]
How to adjust the volume
*
[AS01650(F )03/96]
Press the (R/S) side of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS01675(F )02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS01700(F )03/96]
Selecting the AM or FM frequency band
*
[AS01800(F )10/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to tune radio stations.
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

35 %
*
[AS06050(F )10/95]
Using the Controls on Your New Compact
Disc Player
*
[AS06150(F )03/96]
Your new Ford Compact Disc Player is capable
of playing 12 cmor8 cm discs, without an
adapter. The player operates when the power is
on and a disc is inserted (label side up). Handle
the disc by its edge only. (Be sure to read and
follow all of the care and cleaning instructions
underHow To Take Care of and Clean Your CD
Player and Discs.)
*
[AS06200(F )09/95]
NOTE: If after you insert a disc, the disc is
ejected and ªERRORº begins scrolling
in the display, remove the disc and
reinsert it right side up (label side up).
*
[AS06250(F )08/95]
The digital display on your CD player will
either show the track (selection) number or the
elapsed time. (The display mode can be selected
by pressing the ªCLOCKº button.) Indicators for
play (
a), stop (
X) and compression on (ªCº)
are also in the display. (These features are
described later.)
*
[AS06300(F )10/95]
Once a disc is inserted, operation of the CD
player will override that of the radio.
*
[AS06350(F )09/95]
NOTE: The volume, bass, treble, balance and
fader controls on the radio are also
used with the CD player. Refer to
earlier operating instructions on these
controls.
*
[AS06400(F )04/96]
How to insert a disc and begin play
*
[AS06450(F )10/95]
Insert one disc,label side upinto the disc
opening. When inserted, the disc automatically
loads into the unit and play starts at the
beginning of the first track (selection).
*
[AS06500(F )04/96]
When the disc reaches the end, the disc player
automatically returns to the beginning of the
disc and resumes playing.
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

42
%*
[AS21300(F )09/95]
Electronic Stereo and Stereo
Cassette Radios
*
[AS21400(F )03/96]
Using the Controls on Your New Radio
*
[AS21415(F )02/96]
full page art:0060586-C
Electronic Stereo Radio
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

47
*
[AS24500(F )02/96]
Speaker features and operation
*
[AS24600(F )02/96]
q
Adjusting speaker balance
*
[AS24650(F )02/96]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBAL.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the right
speakers, and push the left (S) side to shift
the sound to the left speakers.
*
[AS24800(F )04/96]
q
Adjusting speaker fader
*
[AS24850(F )02/96]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADE.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the front
speakers, and push the left (S) side to shift
the sound to the rear speakers.
[AS24950(F )04/96]
NOTE: Illuminated bars show relative levels of
bass and treble and positions of
speaker balance and fader functions
after adjustments are made, then revert
to volume level set.
%*
[AS25000(F )04/96]
Using the Controls of Your Cassette Tape
Player
*
[AS25500(F )08/95]
How to insert a tape
*
[AS25600(F )08/95]
Insert a cassette (with the open edge to the
right) firmly into the tape door opening, making
sure the cassette is completely in and ªseated.º
*
[AS25650(F )08/95]
NOTE: A cassette tape can be loaded with the
ignition on whether or not the radio
power is on.
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

51
*
[AS32500(F )03/96]
Using the Controls on Your New Radio
*
[AS32600(F )08/95]
How to turn the radio on and adjust the
volume
[AS32700(F )04/96]
Press the ªON/VOL-PUSH-CLOCKº control to
turn the radio on. Press again to turn it off.
Rotate the control clockwise to increase the
volume.
[AS32900(F )04/96]
NOTE: If your radio has a clock feature, turn
the radio on by rotating the control
clockwise. Pushing the control in will
change the display from the radio
frequency to the clock (time) or from
the clock to the radio frequency.
%*
[AS33000(F )03/96]
How to tune radio stations
[AS33100(F )04/96]
There are two ways for you to tune to a
particular station. You can manually locate a
station using the ªTUNEº button or select a
station using the ªMEMORY PRESETº buttons,
which you can set to any desired frequency.
*
[AS33200(F )03/96]
q
Using the ªTUNEº function
[AS33300(F )04/96]
You can change the frequency up or down
one increment at a time by pressing and
releasing either the right (+) or left (s) side
of the ªTUNEº button. To change frequencies
quickly press and hold down either the right
or left side of the ªTUNEº button.
[AS33400(F )04/96]
The ªTUNEº control adjusts your radio to
any allowable broadcast frequency regardless
of whether or not a station is present on that
frequency. (SeeAll About Radio Frequenciesin
this section.)
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

52
*
[AS33500(F )02/96]
q
Setting the Station Memory Preset buttons
[AS33600(F )04/96]
Your radio is equipped with 6 station
memory preset buttons. These buttons can be
used to select up to 6 preset AM stations.
Follow the easy steps below to set these
buttons to the desired frequencies:
[AS33800(F )04/96]
1. Tune to the desired frequency.
[AS33900(F )04/96]
2. Press one of the memory preset buttons and
hold the button in until the sound returns.
That station is now held in memory on that
button.
[AS34000(F )04/96]
3. Follow the two steps above for each station
memory preset you want to set.
*
[AS34100(F )08/95]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons (if programmed in auto mode)
will need to be reset.
*
[AS34200(F )10/95]
Adjusting the tone balance and speaker
output of your radio
[AS34300(F )04/96]
The ªTONEº control on the right side of your
radio controls the bass and treble balance. Rotate
the control clockwise to increase the treble
response (more highs) and counterclockwise to
increase the bass response (more lows).
%*
[AS34400(F )01/96]
Clock Operation
*
[AS34500(F )08/95]
How to view the clock mode
*
[AS34600(F )08/95]
Press the ªCLOCKº button to alternate the
frequency and time in the display. In the clock
mode, pressing any radio function will
automatically display the radio frequency for
approximately ten seconds before changing back
to the clock mode.
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

57
Controls and Features
[CF00200(F )04/96]
NOTE: The following section does not apply
to Stripped Chassis vehicles. See your
Body Builder's instructions for location
and operation of controls for climate
control systems, lamps, radio and
windshield wiper/washer.
*
[CF00400(F )03/96]
Your vehicle has a variety of features designed
for your comfort, convenience and safety. Read
this chapter to find out about standard and
optional features.
%
*
[CF00500(F )03/96]
The Climate Control Systems
*
[CF00600(F )03/96]
Your vehicle is equipped with a control
assembly designed to handle either a
combination A/C-Heater System or a
Heater-Only System.
*
[CF00625(F )05/96]
one third page art:0020104-D
Climate control knobs (Heater A/C system)
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

Index 371
Cleaning your vehicle (continued)
upholstery and interior trim...... 314
washing.............312±313
waxing............... 313
wheels................ 315
Climate control system.......... 57
Clock.............. 34,48,52
Clutch................. 158
adjusting............... 270
fluid................. 270
fluid reservoir..........268, 270
operation while driving........ 158
recommended shift speeds....... 161
shifting the gears........... 159
specifications............. 324
Cold engine starting........... 139
Combination lap and shoulder belts . 107, 111
Compact disc player (see Electronic
sound system)........... 28,35
Compact disc radio (see Electronic
sound system)............. 28
Console, description............ 87
Controls
mirrors.............. 79,81
power seat.............. 105
Convenience kit in cargo area...... 237
Coolant (see Engine coolant)....... 274
checking and adding......... 274
preparing for storage......... 331
proper solution............ 276
refill capacities............ 318
specifications...........277, 324
temperature gauge........... 21
warnings............... 274
Cooling fan............... 258
Crankcase emission filter......... 317
