1997 FORD F250 washer fluid

73 %
*
[CF28900(FM)01/96]
Variable Interval Wipers
[CF29000(FM)04/96]
In addition to two speed wipers, your vehicle is
equipped with wipers that you can set to
operate at varying intervals. For example, you
can set the interval so they wipe less often when
it drizzles or more often in heavier rain.
[CF29100(FM)04/96]
one third page art:0020831-A
Interval wiper on turn signal lever
*
[CF29200(FM)08/95]
To set the interval wipers, rotate the knob at the
end of the turn signal lever toward or away
from the instrument panel to the interval
operation you desire.
*
[CF29300(FM)01/96]
Windshield Washer
*
[CF29400(FM)01/96]
To clean the windshield, push in the end of the
wiper knob. For a constant spray, keep the knob
pushed in. After you release the knob, the
wipers operate for two to three cycles before
turning off (if wipers were off) or returning to
the selected setting.
*
[CF29500(FM)08/95]
Do not try to clean the windshield when the
washer fluid container is empty or activate the
washers at any time for more than 15 seconds
continuously. This could damage the washer
pump system.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

74 [CF29510(FM)05/96]The addition of shields to the front of the
vehicle as used to deflect bugs, may also
adversely affect the washer system from
delivering fluid to the windshield. Devices such
as bug shields are not recommended.
*
[CF29600(FM)01/96]
RWARNING
Always warm up the windshield with the
defroster before you use the washer fluid.
In freezing weather, the washer solution
may freeze on the windshield and obscure
your vision.
*
[CF29700(F )03/96]
For information about refilling the washer fluid
or replacing your windshield wiper blades, see
Windshield washer fluid and Wipersin the Index.
%
*
[CF29800(FM)03/96]
Hazard Flasher
*
[CF29900(FM)01/96]
The hazard flasher is used to alert other drivers
to hazardous situations.
*
[CF30000(FM)01/96]
The flashers will continue to flash with the brake
pedal depressed.
*
[CF30200(FM)01/96]
The flashers work whether your vehicle is
running or not. The flashers work for up to two
hours when the battery is fully charged and in
good condition without draining the battery
excessively. If the flashers run for longer than
two hours or if the battery is not fully charged,
the battery can be drained.
*
[CF30300(FM)01/96]
To use the hazard flasher:
*
[CF30400(FM)01/96]
1. Push in the flasher button; it will pop out
and the lamps will begin to flash.
*
[CF30500(FM)01/96]
2. To stop the flashers, push in the flasher
button again.
File:05ltcff.ex
Update:Tue May 28 08:42:43 1996
ProCarManuals.com

271
%*
[MC10700(FM)01/96]
Driveline Universal Joint and Slip
Yoke
*
[MC10750(F )03/96]
The universal joints that come standard with
your vehicle do not require lubrication. If your
original equipment universal joints are replaced
with universal joints equipped with grease
fittings, lubrication will be necessary at the
intervals shown in theMaintenance Schedule
booklet.
*
[MC10850(F )01/96]
Your vehicle may be equipped with a constant
velocity or double cardan joint at the transfer
case end of the driveshaft. The front driveshaft
double cardan joint may be fitted with a flush
type grease fitting that requires an adapter to
permit proper lubrication. Lubricate the drive
joint according to the intervals shown in the
Maintenance Schedulebooklet.
[MC10875(F )04/96]
quarter page art:0020379-A
Double cardan joint
%*
[MC10900(F )02/96]
Windshield Washer Fluid
%*
[MC10950(F )03/96]
Washer Fluid
*
[MC11000(F )02/96]
Check the level of the windshield washer fluid
every time you stop for fuel. The reservoir for
the windshield washer fluid is located in the
engine compartment.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

272
*
[MC11050(F )01/96]
Adding washer fluid
*
[MC11100(F )01/96]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
[MC11150(F )04/96]
quarter page art:0020360-C
Adding windshield washer fluid
%*
[MC11300(F )02/96]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOCs) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
*
[MC11350(F )01/96]
If you choose to use a windshield washing
solution that must be mixed, follow the
manufacturer's mixing instructions. Improperly
mixed solutions may freeze unexpectedly.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

273 [MC11400(F )01/96]
NOTE: The addition of shields to the front of
the vehicle, as used to deflect bugs,
may also adversely affect the washer
system from delivering fluid to the
windshield. Devices such as bug
shields are not recommended to be
added to your new Ford product.
%
*
[MC11450(F )02/96]
Wiper Blades
*
[MC11500(F )01/96]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Such substances as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
*
[MC11550(F )01/96]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear water. Do
not use fuel, kerosene, paint thinner, or other
solvents to clean your wiper blades. These will
damage your blades.
*
[MC11600(F )01/96]
To make reaching the wiper blades easy, simply
turn the ignition switch to ACC and turn your
wipers on. Wait for them to reach a vertical
position and turn the ignition to OFF. Do not
move the wipers manually. Moving the wipers
manually may damage them.
*
[MC11650(F )02/96]
Wiper blade replacement
[MC11675(F )04/96]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

275 % [MC12150(F )04/96]
quarter page art:0020360-C
Adding engine coolant
*
[MC12300(FM)01/96]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[MC12350(FM)01/96]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
*
[MC12400(FM)05/96]
RWARNING
Never remove the coolant recovery cap
while the engine is running or hot.
[MC12450(FM)04/96]
RWARNING
Follow these steps to minimize risk of
personal injury.
*
[MC12500(FM)05/96]
1. Before you remove the radiator cap, turn the
engine off and let it cool. Even when the
engine is cool, be careful when you remove
the radiator cap.
*
[MC12550(FM)05/96]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly
counterclockwise to the first stop.
*
[MC12600(FM)05/96]
3. Step back while the pressure releases.
*
[MC12650(FM)01/96]
4. When you are sure that all the pressure has
been released, use the cloth to press, turn,
and remove cap.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

315
*
[MC51700(F )01/96]
NOTE: Before using any cleaner, test it on a
small, hidden area of fabric. If the
fabric's color or texture is adversely
affected by a particular cleaner, do not
use it.
*
[MC51800(F )01/96]
Cleaning the Engine
*
[MC51900(F )01/96]
A clean engine is more efficient because a
buildup of grease and dirt acts as an insulator,
keeping the engine warmer than usual.
*
[MC52000(F )01/96]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[MC52100(F )04/96]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[MC52200(F )04/96]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[MC52300(F )01/96]
q
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%*
[MC52400(F )03/96]
Cleaning the Wheels
*
[MC52450(F )03/96]
Wash the wheels with the same detergent you
use to wash your vehicle's body. Do not use
acid-based wheel cleaners, steel wool, abrasives,
fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil
remover to remove grease and tar.
*
[MC52500(F )03/96]
NOTE: Before going to a car wash, find out if
the brushes are abrasive.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

382 Index
Power features
door locks............... 84
lumbar support............ 106
mirrors............... 79,81
seats................. 105
windows..............84±85
Power point electrical outlet........ 66
Power steering
dipstick............... 280
driving with power steering...... 151
fluid, checking and adding....... 280
fluid, refill capacity.......... 318
fluid, specifications.......... 324
servicing............... 151
Prop rod, hood............. 260
R
Radio (see Electronic sound systems).... 27
Rear anti-lock brakes........... 146
description.............. 146
Rear axle
lubricant specification......... 324
refill capacity............. 318
traction lok.............. 220
Rear window............... 84
washer reservoir........... 271
Refill capacities for fluids........ 318
Regulations, National Highway Traffic Safety
Administration............ 333
Remote entry system............ 89
illuminated entry............ 92
locking/unlocking doors......... 89
panic alarm............... 90
replacement/additional transmitters.... 92
replacing the batteries.......... 91
