1997 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

Severe Duty Schedule 181
*
[BK60000( ALL)01/95]
45,000 MILES (75,000 Kilometers)
*
[BK60100( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK60150( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK60400( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK60600( ALL)08/95]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK60630( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK60635( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK60650( ALL)04/93]
four pica chart:0060627-A
*
[BK60700( ALL)01/95]
48,000 MILES (80,000 Kilometers)
*
[BK60800( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK60900( ALL)01/95]
q
Change engine coolant initially at 48,000 miles
(80,000 km) or 48 months. Thereafter, change
engine coolant every 30,000 miles (50,000 km) or
36 months.
*
[BK61300( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK61400( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

182 Severe Duty Schedule
*
[BK61450( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK61500( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK61800( ALL)09/95]
q
Lubricate throttle kickdown or TV lever ball
studs.
*
[BK62150( ALL)04/93]
four pica chart:0060627-A
*
[BK62200( ALL)01/95]
51,000 MILES (85,000 Kilometers)
*
[BK62300( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK62340( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK62350( ALL)04/93]
four pica chart:0060627-A
*
[BK62400( ALL)01/95]
54,000 MILES (90,000 Kilometers)
*
[BK62500( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK62700( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK62800( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 183
*
[BK62850( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK62900( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK63050( ALL)04/93]
four pica chart:0060627-A
*
[BK63100( ALL)01/95]
57,000 MILES (95,000 Kilometers)
*
[BK63200( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK63250( ALL)04/93]
four pica chart:0060627-A
*
[BK63300( ALL)01/95]
60,000 MILES (100,000 Kilometers)
*
[BK63400( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK63500( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK63700( ALL)08/95]
q
Replace air cleaner filter every 30,000 miles
(50,000 km) or 30 months. If operating in dusty
conditions consult your dealer and/or follow severe
duty maintenance schedule. (1)
*
[BK63800( ALL)04/93]
q
Replace crankcase emission air filter. If operating
in dusty conditions consult your dealer and/or
follow severe duty maintenance schedule.(1)
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

184 Severe Duty Schedule
*
[BK63900( ALL)08/95]
q
Replace PCV valve. (7)
*
[BK64000( ALL)06/94]
q
Check thermactor hoses and clamps.
(Recommended, not required.)
*
[BK64125( ALL)04/95]
q
Replace spark plugs (Gasoline engines only).
*
[BK64200( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK64400( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK64500( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK64550( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK64600( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK64900( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK65100( ALL)08/95]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK65400( ALL)05/93]
q
Inspect and lubricate front wheel bearings. (2)
*
[BK65500( ALL)08/95]
q
Inspect parking brake system for damage and
operation.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 185
*
[BK66030( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK66035( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK66050( ALL)04/93]
four pica chart:0060627-A
*
[BK66100( ALL)01/95]
63,000 MILES (105,000 Kilometers)
*
[BK66200( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK66350( ALL)10/95]
q
Change automatic transmission fluid.
*
[BK66550( ALL)04/93]
four pica chart:0060627-A
*
[BK66600( ALL)01/95]
66,000 MILES (110,000 Kilometers)
*
[BK66700( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK66900( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK67000( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK67050( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

186 Severe Duty Schedule
*
[BK67100( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK67250( ALL)04/93]
four pica chart:0060627-A
*
[BK67300( ALL)01/95]
69,000 MILES (115,000 Kilometers)
*
[BK67400( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK67445( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK67450( ALL)04/93]
four pica chart:0060627-A
*
[BK67500( ALL)01/95]
72,000 MILES (120,000 Kilometers)
*
[BK67600( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK68100( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK68200( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK68250( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 187
*
[BK68300( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK68600( ALL)09/95]
q
Lubricate throttle kickdown or TV lever ball
studs.
*
[BK68650( ALL)04/93]
four pica chart:0060627-A
*
[BK68700( ALL)01/95]
75,000 MILES (125,000 Kilometers)
*
[BK68800( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK68850( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK69100( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK69300( ALL)08/95]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK69330( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK69335( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK69350( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

188 Severe Duty Schedule
*
[BK69400( ALL)01/95]
78,000 MILES (130,000 Kilometers)
*
[BK69500( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK69525( ALL)05/95]
q
Change engine coolant every 30,000 miles
(50,000 km) or 36 months.
*
[BK69550( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK69700( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK69800( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK69850( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK69900( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK70350( ALL)06/93]
four pica chart:0060627-A
*
[BK70400( ALL)01/95]
81,000 MILES (135,000 Kilometers)
*
[BK70500( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK70550( ALL)04/93]
four pica chart:0060627-A
