1997 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

Severe Duty Schedule 189
*
[BK70600( ALL)01/95]
84,000 MILES (140,000 Kilometers)
*
[BK70700( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK71150( ALL)10/95]
q
Change automatic transmission fluid.
*
[BK71200( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK71300( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK71350( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK71400( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK71550( ALL)04/93]
four pica chart:0060627-A
*
[BK71600( ALL)01/95]
87,000 MILES (145,000 Kilometers)
*
[BK71700( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK71740( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK71750( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

190 Severe Duty Schedule
*
[BK71800( ALL)01/95]
90,000 MILES (150,000 Kilometers)
*
[BK71900( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK72000( ALL)08/95]
q
Replace air cleaner filter every 30,000 miles
(50,000 km) or 30 months. If operating in dusty
conditions consult your dealer and/or follow severe
duty maintenance schedule. (1)
*
[BK72150( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK72175( ALL)08/95]
q
Inspect accessory drive belt(s).
*
[BK72195( ALL)04/93]
q
Replace crankcase emission air filter. If operating
in dusty conditions consult your dealer and/or
follow severe duty maintenance schedule.
*
[BK72400( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK72500( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK72550( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK72600( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK72800( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 191
*
[BK73000( ALL)08/95]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK73100( ALL)05/93]
q
Inspect and lubricate front wheel bearings. (2)
*
[BK73200( ALL)08/95]
q
Inspect parking brake system for damage and
operation.
*
[BK73710( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK73720( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK73750( ALL)04/93]
four pica chart:0060627-A
*
[BK73800( ALL)01/95]
93,000 MILES (155,000 Kilometers)
*
[BK73900( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK74250( ALL)04/93]
four pica chart:0060627-A
*
[BK74300( ALL)01/95]
96,000 MILES (160,000 Kilometers)
*
[BK74400( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK74500( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK74900( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK75000( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

192 Severe Duty Schedule
*
[BK75050( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK75100( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK75300( ALL)09/95]
q
Lubricate throttle kickdown or TV lever ball
studs.
*
[BK75450( ALL)04/93]
four pica chart:0060627-A
*
[BK75500( ALL)01/95]
99,000 MILES (165,000 Kilometers)
*
[BK75600( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK75650( M)06/94]
q
Inspect accessory drive belt(s).
*
[BK75700( ALL)06/94]
q
Replace rear axle lube.
*
[BK75750( ALL)04/93]
four pica chart:0060627-A
*
[BK75800( ALL)01/95]
102,000 MILES (170,000 Kilometers)
*
[BK75900( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK76100( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK76200( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 193
*
[BK76250( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK76300( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK76450( ALL)04/93]
four pica chart:0060627-A
*
[BK76500( ALL)01/95]
105,000 MILES (175,000 Kilometers)
*
[BK76600( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK76650( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK76700( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK76750( ALL)10/95]
q
Change automatic transmission fluid.
*
[BK76900( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK77100( ALL)08/95]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK77130( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK77135( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK77150( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

194 Severe Duty Schedule
*
[BK77200( ALL)01/95]
108,000 MILES (180,000 Kilometers)
*
[BK77300( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK77400( ALL)05/95]
q
Change engine coolant every 30,000 miles
(50,000 km) or 36 months.
*
[BK77800( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK77900( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK77950( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK78000( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK78450( ALL)04/93]
four pica chart:0060627-A
*
[BK78500( ALL)01/95]
111,000 MILES (185,000 Kilometers)
*
[BK78600( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK78650( ALL)08/95]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 195
*
[BK78700( ALL)01/95]
114,000 MILES (190,000 Kilometers)
*
[BK78800( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK78850( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK79000( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK79100( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK79150( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK79200( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK79350( ALL)08/95]
four pica chart:0060627-A
*
[BK79400( ALL)01/95]
117,000 MILES (195,000 Kilometers)
*
[BK79500( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK79550( ALL)08/95]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

196 Severe Duty Schedule
*
[BK79600( ALL)01/95]
120,000 MILES (200,000 Kilometers)
*
[BK79700( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK79800( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK79900( ALL)08/95]
q
Replace air cleaner filter every 30,000 miles
(50,000 km) or 30 months. If operating in dusty
conditions consult your dealer and/or follow severe
duty maintenance schedule. (1)
*
[BK80100( ALL)04/95]
q
Replace spark plugs (Gasoline engines only).
*
[BK80300( ALL)04/93]
q
Replace crankcase emission air filter. If operating
in dusty conditions consult your dealer and/or
follow severe duty maintenance schedule.
*
[BK80400( ALL)07/95]
q
Replace PCV valve.
*
[BK80500( ALL)06/94]
q
Check thermactor hoses and clamps.
(Recommended, not required.)
*
[BK80600( ALL)08/95]
q
Inspect accessory drive belt(s).
*
[BK81000( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK81100( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK81150( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK81200( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
