1997 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

93 %
*
[ER19600( ALL)01/96]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[ER19650( ALL)01/96]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[ER19750( ALL)01/96]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
*
[ER19800( ALL)01/96]
Preparing Your Vehicle
*
[ER19850( ALL)01/96]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[ER19900( ALL)01/96]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[ER19950( ALL)01/96]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
File:10lterm.ex
Update:Fri Dec 13 11:23:45 1996

94
*
[ER21000( ALL)01/96]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[ER21100( ALL)01/96]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
%*
[ER21200( ALL)01/96]
Connecting the jumper cables
*
[ER21300( ALL)01/96]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[ER21500( ALL)01/96]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[ER21600( ALL)01/96]
3. Connect one end of the second cable to the
negative (S) terminal of the booster battery
Ð NOT to the discharged battery.
*
[ER21700( ALL)01/96]
4. Connect the other end of the second cable to
a good metallic surface on the engine or
frame of the disabled vehicle.
File:10lterm.ex
Update:Fri Dec 13 11:23:45 1996

95
*
[ER21800( ALL)01/96]
RWARNING
Do not connect the end of the second
cable to the negative (S) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
*
[ER21900( ALL)01/96]
one third page art:0020262-C
Attaching jumper cables
*
[ER22000( ALL)01/96]
Jump-Starting
*
[ER22100( ALL)01/96]
1. Make sure that the jumper cables are not in
the way of moving engine parts, then start
the booster vehicle. Run the engine at a
moderate speed.
*
[ER22200( ALL)01/96]
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle.
It may take a couple of tries before the
vehicle starts. If the vehicle does not start
after several attempts, there may be a
different problem.
*
[ER22300( ALL)01/96]
3. When both vehicles are running, let them
idle for a few minutes to charge the
discharged battery.
File:10lterm.ex
Update:Fri Dec 13 11:23:45 1996

96 %
*
[ER22400( ALL)01/96]
Removing jumper cables
*
[ER22500( ALL)01/96]
1.Always remove the jumper cables in the
reverse order.Remove the negative (S) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[ER22600( ALL)01/96]
2. Remove the negative (S) cable from the
booster battery.
*
[ER22700( ALL)01/96]
3. Remove the positive (+) cable from the
booster battery.
*
[ER22800( ALL)01/96]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[ER22900( ALL)01/96]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
Driveability may be deteriorated slightly until all
drive modes are ªrelearned.ºYou may need to
use a battery charger to fully recharge the
battery.
*
[ER23000( ALL)01/96]
If you need to replace your battery, seeBattery
in theMaintenance and Carechapter.
File:10lterm.ex
Update:Fri Dec 13 11:23:45 1996

97
%*
[ER23100( ALL)01/96]
Towing Your Vehicle
[ER23200(B FM)01/96]
If you need to have your vehicle towed, contact
a professional towing service or, if you are a
member, your roadside assistance center.
Recommended towing options include wheel lift
towing or flat bed towing.
[ER23500( ALL)01/96]
When calling for a tow truck, tell the operator
what kind of vehicle you have. A towing
manual is available from Ford Motor Company
for all authorized tow truck operators. Have
your tow truck driver refer to this manual for
the proper hook-up and towing procedures for
your vehicle.
File:10lterm.ex
Update:Fri Dec 13 11:23:45 1996

98
Notes
File:10lterm.ex
Update:Fri Dec 13 11:23:45 1996

99
Maintenance and Care
%*
[MC00200( ALL)01/96]
Service Made Easy
*
[MC00900( ALL)01/96]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[MC01000( ALL)01/96]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[MC01100( ALL)01/96]
Ford Motor Company recommends that the
Owner Maintenance Checks listed in the
Maintenance Schedule and Recordbooklet be
performed for the proper operation of your
vehicle. In addition to the conditions listed in
theOwner Maintenance Checklist, be alert for any
unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice
something unusual, see that your vehicle is
serviced promptly.
%
*
[MC01200( ALL)01/96]
Precautions When Servicing Your
Vehicle
*
[MC01300( ALL)01/96]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
*
[MC01400( ALL)01/96]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
*
[MC01500( ALL)01/96]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

100
*
[MC01600( ALL)01/96]
q
Never get under a vehicle while it is
supported only by a jack. If you must work
under a vehicle, use safety stands.
*
[MC01700( ALL)01/96]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[MC01800( ALL)01/96]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
*
[MC01900( ALL)01/96]
Working with the engine off:
*
[MC02000( E M)01/96]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park).
*
[MC02300( ALL)01/96]
2. Remove the key from the ignition after you
turn the engine off.
*
[MC02400( ALL)01/96]
3. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC02500( ALL)01/96]
Working with the engine on:
*
[MC02700( E M)01/96]
1. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park).
*
[MC02800( E M)01/96]
2. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC03000( ALL)01/96]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996
