Controls and Features
[CF00300( M)01/96]
NOTE: The following section does not apply
to Stripped Chassis vehicles. See your
Body Builder's instructions for location
and operation of controls for climate
control systems, lamps and radio.
%*
[CF14100( ALL)01/96]
Turning On the Exterior Lights
*
[CF14200( ALL)01/96]
To turn on your headlamps, parking lamps,
marker lamps, license plate lamps and tail
lamps, use the headlamp switch to the left of the
steering column.
*
[CF14300( ALL)01/96]
1. Pull the headlamp control knob toward you
to the first position. Parking lamps, tail
lamps and marker lamps are now on.
*
[CF14400( ALL)01/96]
2. Pull the headlamp control knob toward you
to the outer position. Headlamps are now on
in addition to the above.
File:05ltcfm.ex
Update:Thu Dec 12 13:31:05 1996

22
*
[CF14600(B FM)01/96]
half page art:0010194-E
Headlamp switch
%*
[CF14800( ALL)01/96]
Daytime Running Light System
*
[CF14900( ALL)01/96]
(Canadian vehicles only)
*
[CF15000( ALL)01/96]
The Daytime Running Light (DRL) system turns
the high beam headlamps on, with a reduced
light output, when:
*
[CF15100( ALL)01/96]
q
The headlamp system is in the OFF position,
and
*
[CF15200( ALL)01/96]
q
The vehicle is running, and
*
[CF15300( ALL)01/96]
q
The vehicle has a fully released parking
brake.
*
[CF15400( ALL)01/96]
NOTE: You may notice that the lights flicker
when the vehicle is turned on or off.
This is a normal condition.
File:05ltcfm.ex
Update:Thu Dec 12 13:31:05 1996

23
*
[CF24100( ALL)01/96]
Ignition
%*
[CF24110( ALL)01/96]
Understanding the Positions of the Ignition
*
[CF24120( ALL)01/96]
quarter page art:0020004-B
The positions of the key in the ignition lock cylinder.
*
[CF24130( ALL)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[CF24140( ALL)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
*
[CF24150( ALL)01/96]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
[CF24170( E M)01/96]
LOCK locks the steering wheel. It also locks the
gearshift.
*
[CF24190( M)01/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
File:05ltcfm.ex
Update:Thu Dec 12 13:31:05 1996

24
*
[CF24220( ALL)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
%*
[CF24230( ALL)01/96]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
%*
[CF24240( ALL)01/96]
ACCESSORY allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
%*
[CF24280( ALL)01/96]
Removing the Key From the Ignition
[CF24320( E M)01/96]
Procedures for removing your key from the
ignition are as follows:
[CF24340( E M)01/96]
Your vehicle's gearshift lever is mounted on
the column:
*
[CF24350( ALL)01/96]
1. Put the gearshift in P (Park).
*
[CF24360( ALL)01/96]
2. Set the parking brake fully before removing
your foot from the service brake. (This will
avoid ªbindingº or ªloadingº the park gear
if you park on a grade.)
*
[CF24370( ALL)01/96]
3. Turn the ignition key to LOCK.
*
[CF24380( ALL)01/96]
4. Remove the key.
*
[CF24470( E M)01/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[CF24500( ALL)01/96]
RWARNING
Do not leave children, unreliable adults,
or pets unattended in your vehicle.
File:05ltcfm.ex
Update:Thu Dec 12 13:31:05 1996

25
%*
[CF26900( ALL)01/96]
The Turn Signal Lever
*
[CF27000( ALL)01/96]
You can use the turn signal lever on the left side
of the steering column to:
*
[CF27100( ALL)01/96]
q
operate the turn signals and cornering lamps
%*
[CF27500( ALL)01/96]
Turn Signals
*
[CF27600( ALL)01/96]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
*
[CF27700( ALL)01/96]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
*
[CF27800( ALL)01/96]
one third page art:0020081-C
Turn signal lever and functions
*
[CF27900( ALL)01/96]
If the turn indicator light in the instrument
panel does not illuminate or remains on (doesn't
flash) when you signal a turn, the turn signaling
system is malfunctioning. Have this condition
corrected as soon as possible, but make sure that
you use the accepted hand signals in the
meantime.
File:05ltcfm.ex
Update:Thu Dec 12 13:31:05 1996

26 %
*
[CF28000( ALL)01/96]
High Beams
*
[CF28100( ALL)01/96]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[CF28200( ALL)01/96]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
*
[CF28300( ALL)01/96]
one third page art:0020074-B
Headlamp high beam switch and turn signal lever
%*
[CF28400( ALL)01/96]
Flashing the Lights
*
[CF28500( ALL)01/96]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
File:05ltcfm.ex
Update:Thu Dec 12 13:31:05 1996

27
%*
[CF28600( ALL)01/96]
Windshield Wipers and Washer
*
[CF28700( ALL)01/96]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
*
[CF28800( ALL)01/96]
Turn the knob on the end of the turn signal
lever toward the front of the vehicle. You can
turn it to either the LO or HI speed position.
%*
[CF28900( ALL)01/96]
Variable Interval Wipers
*
[CF29000( ALL)01/96]
In addition to two speed wipers, your vehicle is
equipped with wipers that you can set to
operate at varying intervals. For example, you
can set the interval so they wipe less often when
it drizzles or more often in heavier rain.
*
[CF29100( ALL)01/96]
one third page art:0020831-A
Interval wiper on turn signal lever
*
[CF29200( ALL)01/96]
To set the interval wipers, rotate the knob at the
end of the turn signal lever toward or away
from the instrument panel to the interval
operation you desire.
*
[CF29300( ALL)01/96]
Windshield Washer
*
[CF29400( ALL)01/96]
To clean the windshield, push in the end of the
wiper knob. For a constant spray, keep the knob
pushed in. After you release the knob, the
wipers operate for two to three cycles before
turning off (if wipers were off) or returning to
the selected setting.
File:05ltcfm.ex
Update:Thu Dec 12 13:31:05 1996

28
*
[CF29500( ALL)01/96]
Do not try to clean the windshield when the
washer fluid container is empty or activate the
washers at any time for more than 15 seconds
continuously. This could damage the washer
pump system.
*
[CF29600( ALL)01/96]
RWARNING
Always warm up the windshield with the
defroster before you use the washer fluid.
In freezing weather, the washer solution
may freeze on the windshield and obscure
your vision.
%
*
[CF29800( ALL)01/96]
Hazard Flasher
*
[CF29900( ALL)01/96]
The hazard flasher is used to alert other drivers
to hazardous situations.
*
[CF30000( FM)01/96]
The flashers will continue to flash with the brake
pedal depressed.
*
[CF30200( ALL)01/96]
The flashers work whether your vehicle is
running or not. The flashers work for up to two
hours when the battery is fully charged and in
good condition without draining the battery
excessively. If the flashers run for longer than
two hours or if the battery is not fully charged,
the battery can be drained.
*
[CF30300( ALL)01/96]
To use the hazard flasher:
*
[CF30400( ALL)01/96]
1. Push in the flasher button; it will pop out
and the lamps will begin to flash.
*
[CF30500( ALL)01/96]
2. To stop the flashers, push in the flasher
button again.
*
[CF30600( ALL)01/96]
NOTE: The flasher button will be sticking up
slightly higher when on than when off.
File:05ltcfm.ex
