1997 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

Severe Duty Schedule 173
*
[BK50100( ALL)01/95]
3,000 MILES (5,000 Kilometers)
*
[BK50200( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK50450( ALL)04/93]
four pica chart:0060627-A
*
[BK50501( ALL)01/95]
6,000 MILES (10,000 Kilometers)
*
[BK50601( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK50650( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK50801( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK50901( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK50910( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK51001( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK51150( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

174 Severe Duty Schedule
*
[BK51201( ALL)01/95]
9,000 MILES (15,000 Kilometers)
*
[BK51301( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK51350( ALL)04/93]
four pica chart:0060627-A
*
[BK51401( ALL)01/95]
12,000 MILES (20,000 Kilometers)
*
[BK51501( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK52001( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK52101( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK52110( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK52201( EFM)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK52350( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 175
*
[BK52401( ALL)01/95]
15,000 MILES (25,000 Kilometers)
*
[BK52501( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK52550( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK52601( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK52801( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK53001( ALL)08/95]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK53030( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK53035( FM)02/95]
q
Inspect parking brake fluid (F-Super Duty).
*
[BK53050( ALL)04/93]
four pica chart:0060627-A
*
[BK53101( ALL)01/95]
18,000 MILES (30,000 Kilometers)
*
[BK53201( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK53501( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK53601( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK53610( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

176 Severe Duty Schedule
*
[BK53801( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK54050( ALL)04/93]
four pica chart:0060627-A
*
[BK54101( ALL)01/95]
21,000 MILES (35,000 Kilometers)
*
[BK54201( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK54225( ALL)10/95]
q
Change automatic transmission fluid.
*
[BK54250( ALL)04/93]
four pica chart:0060627-A
*
[BK54301( ALL)01/95]
24,000 MILES (40,000 Kilometers)
*
[BK54401( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK54501( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK54801( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK54901( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK54910( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 177
*
[BK55101( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK55301( ALL)09/95]
q
Lubricate throttle kickdown or TV lever ball
studs.
*
[BK55350( ALL)04/93]
four pica chart:0060627-A
*
[BK55401( ALL)01/95]
27,000 MILES (45,000 Kilometers)
*
[BK55501( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK55550( ALL)04/93]
four pica chart:0060627-A
*
[BK55601( ALL)01/95]
30,000 MILES (50,000 Kilometers)
*
[BK55701( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK55800( ALL)08/95]
q
Replace air cleaner filter every 30,000 miles
(50,000 km) or 30 months. If operating in dusty
conditions consult your dealer and/or follow severe
duty maintenance schedule. (1)
*
[BK55950( ALL)06/95]
q
Inspect engine cooling system, hoses, and clamps;
and check coolant strength every 15,000 miles
(25,000 km) or 12 months.
*
[BK55985( ALL)04/93]
q
Replace crankcase emission air filter. If operating
in dusty conditions consult your dealer and/or
follow severe duty maintenance schedule.
*
[BK56200( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

178 Severe Duty Schedule
*
[BK56300( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK56350( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK56400( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK56700( ALL)05/93]
q
Inspect disc brake system and lubricate
caliper slide rails. (2)
*
[BK56900( ALL)08/95]
q
Change fuel filter (Recommended but not
required for California Certified Vehicles).
*
[BK57000( ALL)05/93]
q
Inspect and lubricate front wheel bearings. (2)
*
[BK57100( ALL)08/95]
q
Inspect parking brake system for damage and
operation.
[BK57225( M)08/95]
q
Inspect parking brake fluid (F-Super Duty
only).
*
[BK57520( FM)02/95]
q
Check spring U-bolt torque (F-Super Duty).
*
[BK57550( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

Severe Duty Schedule 179
*
[BK57600( ALL)01/95]
33,000 MILES (55,000 Kilometers)
*
[BK57700( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK57750( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK58050( ALL)04/93]
four pica chart:0060627-A
*
[BK58100( ALL)01/95]
36,000 MILES (60,000 Kilometers)
*
[BK58200( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK58700( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK58800( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK58850( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK58900( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK59050( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996

180 Severe Duty Schedule
*
[BK59100( ALL)01/95]
39,000 MILES (65,000 Kilometers)
*
[BK59200( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK59250( ALL)04/93]
four pica chart:0060627-A
*
[BK59300( ALL)01/95]
42,000 MILES (70,000 Kilometers)
*
[BK59400( ALL)11/95]
q
Change engine oil and replace oil filter.
*
[BK59425( ALL)10/95]
q
Change automatic transmission fluid.
*
[BK59450( ALL)08/95]
q
Rotate tires and adjust air pressure. (3)(5)(6)
*
[BK59600( ALL)09/95]
q
Inspect and lubricate automatic transmission
shift linkage.
*
[BK59700( ALL)06/95]
q
Inspect exhaust system for leaks, damage or
loose parts. Remove any foreign material
trapped by exhaust system shielding.
*
[BK59750( ALL)09/95]
NOTE: It is normal for a certain amount of
moisture and staining to be present
around the muffler seams. The
presence of soot, light surface rust or
moisture does not indicate a faulty
muffler.
*
[BK59800( ALL)08/95]
q
Lubricate steering linkage suspension,
driveshaft U-joint if equipped with grease
fittings and lubricate slip yoke (if equipped).
(2)
*
[BK59950( ALL)04/93]
four pica chart:0060627-A
File:18ltbkm.ex
Update:Thu Dec 12 13:32:30 1996
