1997 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

45
Driving
%*
[GF00500( ALL)01/96]
Brakes
[GF00550( M)01/96]
Your vehicle is equipped with the following
features:
[GF00600( M)01/96]
q
Front self-adjusting disc brakes.
[GF00650( M)01/96]
q
Rear self-adjusting disc brakes.
[GF00700( M)01/96]
q
Independent front and rear hydraulic brake
circuits with a common fluid reservoir and
fluid level sensor in the master cylinder.
[GF00750( M)01/96]
q
Hydro boost.
[GF00800( M)01/96]
q
Parking brake.
*
[GF00850( ALL)01/96]
Front Disc Brakes
*
[GF01000( M)01/96]
The front disc brakes are self-adjusting. They do
not require service other than periodic
lubrication of the caliper slide rails and
inspection for pad wear.
*
[GF01250( M)01/96]
Rear Disc Brakes
*
[GF01300( EFM)01/96]
The rear disc brakes are self-adjusting. They do
not require service other than periodic
lubrication of the caliper slide rails and
inspection for pad wear.
*
[GF01350( ALL)01/96]
Hydraulic Power Brakes
[GF01450( M)01/96]
The hydraulic brake system is made up of two
independent hydraulic circuits. One hydraulic
circuit supplies fluid to the front disc brakes and
the other hydraulic circuit supplies fluid to the
rear disc brakes. These two circuits are supplied
by a common hydraulic brake fluid reservoir,
with a fluid level sensor.
File:09ltgfm.ex
Update:Fri Dec 13 11:22:54 1996

46
*
[GF01500( ALL)01/96]
The brake light in the instrument cluster will
light for low brake fluid in the common brake
fluid reservoir.
*
[GF01550( ALL)01/96]
RWARNING
An increase in pedal travel will result in
reduced braking capability. The brake
system should be checked immediately.
[GF01600( E M)01/96]
Hydraulic Brake Booster System
(Hydro Boost)
[GF01650( E M)01/96]
The Hydro Boost system receives its source of
power from the power steering system pump.
%*
[GF02900(BE M)01/96]
If Brakes Do Not Grip Well or Pedal is
ªLowº
*
[GF03050( ALL)01/96]
If during normal operation the brake pedal
seems ªlowº, it may indicate the need for a
brake system inspection and/or service. You
should have your brakes checked as soon as
possible.
*
[GF03100( ALL)01/96]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes annoyingly loud or increases
significantly in frequency of occurrence, return
the vehicle to your dealer for inspection.
%*
[GF03400( ALL)01/96]
Stopping Distances
*
[GF03450( ALL)01/96]
Stopping distances vary with different loads and
driving conditions. Use caution when
encountering new conditions and acquaint
yourself with vehicle performance. Take full
advantage of engine braking power when
slowing down.
File:09ltgfm.ex
Update:Fri Dec 13 11:22:54 1996

47 %
*
[GF03500( ALL)01/96]
Applying the Brakes
*
[GF03550( ALL)01/96]
Apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
*
[GF03600( ALL)01/96]
Do not drive with your foot resting on the brake
pedal. This will increase your vehicle's stopping
distance and may also cause brake damage.
*
[GF03650( ALL)01/96]
RWARNING
If you are driving down a long or steep
hill, shift to a lower gear. Do not apply
your brakes continuously, as they may
overheat and become less effective.
[GF03700( M)01/96]
When front or rear brake linings are replaced, it
is essential that authorized Ford service
replacement or equivalent linings be installed.
This will assure that the vehicle stopping
distances are not adversely affected and will
maintain the proper balance between front and
rear wheel braking.
%
*
[GF03750( ALL)01/96]
Using the Parking Brake
[GF03900( E M)01/96]
The parking brake pedal is suspended just below
the bottom of the instrument panel to the left of
the service brake. To set the parking brake while
parking your vehicle, press the brake pedal with
your right foot and hold it while you push the
parking brake pedal down firmly with your left
foot.
[GF03950( M)01/96]
The BRAKE warning light will go on as soon as
you start to move the parking brake pedal. The
brake will not prevent the vehicle from moving
unless you push it down firmly and fully.
Remove your foot from the service brake pedal
and make sure there is no vehicle movement.
File:09ltgfm.ex
Update:Fri Dec 13 11:22:54 1996

48
*
[GF04000(B FM)01/96]
one third page art:0020893-A
Parking Brake
*
[GF04250( E M)01/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[GF04400(B FM)01/96]
To release the parking brake, press the service
brake pedal with your right foot and pull the
parking brake release lever.
*
[GF04500( ALL)01/96]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
[GF04600( M)01/96]
The parking brake is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the transmission
mounted parking brake assembly, the stopping
distance will increase greatly and the handling
of your vehicle will be adversely affected.
File:09ltgfm.ex
Update:Fri Dec 13 11:22:54 1996

49 [GF04650( M)01/96]
Checking Parking Brake and Transmission
Park Mechanism
[GF04700( M)01/96]
Periodically check the holding ability of the
parking brake by stopping on a steep hill and
restraining the vehicle by using only the parking
brake with the transmission in N (Neutral).
Check the holding ability of the P (Park)
mechanism (automatic transmissions) by
releasing all brakes after moving the
transmission selector lever to the P (Park)
position.
%
*
[GF05200( ALL)01/96]
Steering Your Vehicle
%*
[GF05300( ALL)01/96]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[GF05350( ALL)01/96]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
*
[GF05400( ALL)01/96]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
*
[GF05450( ALL)01/96]
NOTE: After any severe impact such as
striking large potholes, sliding into
curbs on icy roads, or a collision
involving the front end, observe the
steering wheel alignment. If the spokes
of the steering wheel seem to be in a
different position while going straight
down the road, have the front
suspension and steering checked for
possible damage.
File:09ltgfm.ex
Update:Fri Dec 13 11:22:54 1996

50
% [GF07450( M)01/96]
Automatic Transmission
Operation (E4OD)
[GF07500( M)01/96]
The E4OD transmission is an electronically
controlled four speed automatic transmission
with overdrive. Transmission operation is
controlled by the Powertrain Control Module
(PCM).
*
[GF07525( ALL)01/96]
The PCM will automatically adjust transmission
operation to make up for varying conditions.
Several sensors located on the engine and
transmission such as Throttle Position, Engine
Speed, Vehicle Speed and Transmission
Temperature are used by the PCM to shift the
transmission into a higher or lower gear when
required for the best performance and fuel
economy. For example, you may notice that the
transmission will upshift to a higher gear more
quickly when the vehicle is first driven and has
not reached normal operating temperature.
*
[GF07550( ALL)01/96]
The PCM also controls the transmission's Torque
Converter Clutch to further raise vehicle
performance and fuel economy. The Torque
Converter Clutch will engage when the
transmission operating temperature and other
conditions determined by the PCM have been
met. Engagement of the clutch may be noted as
a decrease in engine speed after an upshift has
completed or when the driver has depressed the
throttle while driving at a steady road speed.
[GF07575( ALL)01/96]
To help in troubleshooting, the PCM continually
performs self-tests on the electronic control
system and if any faults are detected, will store
them in memory. The Transmission Control
Indicator Light (TCIL), which is located on the
gearshift lever, may flash steadily if a
malfunction has been detected. If the TCIL is
flashing, contact your Ford dealer as soon as
possible. If this condition persists, damage to the
transmission could occur.
File:09ltgfm.ex
Update:Fri Dec 13 11:22:54 1996

51 [GF07600( ALL)01/96]
NOTE: The word ªOFFº located on the end of
the gearshift lever is the transmission
control indicator light (TCIL).
%*
[GF07625( ALL)01/96]
Putting Your Vehicle in Gear
*
[GF07650( ALL)01/96]
Your vehicle's gearshift is on the steering
column. The Transmission Control Switch and
indicator light are located on the end of the
gearshift lever. You can put the gearshift in any
of the several positions.
[GF07675( M)01/96]
one third page art:0020133-E
The positions of the column-mounted gearshift
%*
[GF07725( ALL)01/96]
quarter page art:0020771-C
Transmission Control Switch and indicator light (located
on the gearshift lever)
File:09ltgfm.ex
Update:Fri Dec 13 11:22:54 1996

52
*
[GF07750( ALL)01/96]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
*
[GF07775( ALL)01/96]
Once you place the gearshift securely into
position, gradually release the brake pedal and
use the accelerator as necessary.
%*
[GF07800( ALL)01/96]
NOTE: Your vehicle is equipped with a
brake-shift interlock feature. This
feature prevents you from shifting
from P (Park) unless you have the
brake pedal depressed. (The ignition
must be in the ON position.) If you
cannot shift from P (Park) with the
brake pedal depressed:
*
[GF07825( ALL)01/96]
1. Apply the parking brake.
*
[GF07850( ALL)01/96]
2. Remove the key.
*
[GF07875( ALL)01/96]
3. Insert the key and rotate it one position
clockwise (ignition in the OFF position).
*
[GF07900( ALL)01/96]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted back to P
[Park], you must repeat the previous steps.)
*
[GF07925( ALL)01/96]
5. Start the vehicle.
*
[GF07950( ALL)01/96]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledRoadside Emergenciesin
this Owner Guide for instructions on checking
and replacing fuses.
File:09ltgfm.ex
Update:Fri Dec 13 11:22:54 1996
