1997 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS Owners Manual

125
*
[MC27150( ALL)01/96]
RWARNING
Make sure that all replacement tires are of
the same size, type, load-carrying capacity,
and tread design (e.g. ªAll Terrainº, etc.),
as originally offered by Ford.
*
[MC27200( ALL)01/96]
RWARNING
Do not replace your tires with ªhigh
performanceº tires or larger size tires.
*
[MC27300( ALL)01/96]
RWARNING
Failure to follow these precautions may
adversely affect the handling of the
vehicle and make it easier to lose control
and roll over.
*
[MC27350( ALL)01/96]
Tires that are larger or smaller than your
vehicle's original tires may also affect the
accuracy of your speedometer.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

126
*
[MC27500( FM)01/96]
full page art:0020370-C
Tire identification chart
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

127 [MC27600( M)01/96]
RWARNING
Use only wheel assemblies approved and
released by Ford Motor Company for your
vehicle model.
[MC27650( M)01/96]
A wheel or tire of the wrong size or type may
adversely affect such things as load carrying
capacity, wheel and bearing life, brake cooling,
speedometer/odometer calibration, stopping
ability, headlight aim, bumper height, vehicle
ground clearance, and tire or tire chain clearance
to the body and chassis. Replacement with used
wheels is not advised: they may have been
treated harshly or have high mileage, and they
could fail without warning.
[MC27700( M)01/96]
The use of wheels with load carrying limits
higher than the limits of the wheels originally
installed on your vehicle does not in itself
increase the GAWR or GVWR of the vehicle.
[MC27750( M)01/96]
RWARNING
Use only wheel assemblies approved and
released by Ford Motor Company for your
vehicle model.
[MC27800( M)01/96]
RWARNING
Alterations to the vehicle suspension or
steering by raising the chassis (i.e., use of
aftermarket ªlift kitsº) may adversely
affect vehicle handling and braking
performance.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

128 %
*
[MC27900( ALL)01/96]
Wheel and Tire Matching
*
[MC27950( ALL)01/96]
See an authorized tire dealer for proper
servicing procedures. Wheels and tires must be
properly removed, matched and remounted to
maintain the best possible ride.
%
*
[MC29600( ALL)01/96]
Filling the Fuel Tank
%*
[MC30400( ALL)01/96]
Removing the fuel cap
*
[MC30500( ALL)01/96]
The proper instructions for removing the fuel
cap are as follows:
*
[MC30600( ALL)01/96]
q
Unscrew the fuel cap by exerting pressure on
the plastic lock bar and rotating the fuel cap
counterclockwise.
*
[MC30700( ALL)01/96]
q
Turn the fuel cap 1/2 to 3/4 of a turn until a
hissing sound is heard. When the hissing
sound stops, continue rotating
counterclockwise to remove the fuel cap.
*
[MC30800( ALL)01/96]
q
Make sure that you follow the above fuel cap
removal instructions and use caution. Such
caution will minimize the possibility of fuel
spraying during removal of the fuel cap.
*
[MC30900( ALL)01/96]
To replace and secure the fuel cap; place it in
position and rotate it clockwise until it clicks
(ratchets). Doing so will not damage or break
the fuel cap. The ratcheting mechanism allows
the fuel cap to be sealed without overtightening.
*
[MC31000( ALL)01/96]
If you lose the fuel cap, replace it with an
authorized Motorcraft or equivalent part.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

129 %
*
[MC31100( ALL)01/96]
RWARNING
If you do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision.
*
[MC31200( ALL)01/96]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
*
[MC31300( ALL)01/96]
RWARNING
The fuel system may be under pressure. If
the fuel cap is venting vapor or if you
hear a hissing sound, wait until it stops
before completely removing the cap.
[MC31900( M)01/96]
You can prevent excessive condensation in the
fuel tank by keeping it over half full.
%*
[MC32000( ALL)01/96]
Choosing the Right Fuel
*
[MC32200( ALL)01/96]
Use only UNLEADED FUEL. Using leaded fuel
is prohibited by federal law. Any vehicle
damage may not be covered by your warranty.
%*
[MC32400( ALL)01/96]
Octane recommendations
*
[MC32500( ALL)01/96]
Your engine is designed to use regular
unleaded fuel with an octane rating of 87.We
do not recommend gasolines labeled ªregularº
that are sold with octane ratings of 86 or even
less in altitude areas.
*
[MC32600( ALL)01/96]
one inch art:0060001-C
Typical octane rating label
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

130 %
*
[MC32800( ALL)01/96]
Do not be concerned if your vehicle sometimes
knocks lightly. However, if it knocks heavily
under most driving conditions on the
recommended octane rated fuel, see your dealer
or a qualified service technician to prevent any
engine damage.
%*
[MC32900( ALL)01/96]
Fuel quality
*
[MC33000( ALL)01/96]
If you are experiencing starting, rough idle or
hesitation problems, try a different brand of fuel.
If the condition persists, see your dealer or a
qualified service technician.
*
[MC33100( ALL)01/96]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
%*
[MC34000( ALL)01/96]
Gasolines for clean air
*
[MC34100( ALL)01/96]
Ford approves the use of gasolines, including
those reformulated, that contain oxygenates such
as ethanol (10% maximum) and MTBE (15%
maximum). If methanol is used, the gasoline
should contain no more than 5% with
co-solvents.
%*
[MC34400( ALL)01/96]
Safety Information Relating to Automotive
Fuels
*
[MC34500( ALL)01/96]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[MC34600( ALL)01/96]
Gasoline and other automotive fuels are
extremely flammable. Turn your vehicle off and
do not smoke while refueling your vehicle. Keep
sparks and other sources of ignition away from
fuels.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

131
*
[MC34700( ALL)01/96]
Automotive fuels can be harmful or fatal if
swallowed. Further, gasoline may be blended
with methanol. Even small amounts of methanol
can cause blindness and possibly death when
swallowed. Therefore, never attempt to siphon
any fuel by mouth.
*
[MC34800( ALL)01/96]
If any fuel is swallowed, call a physician or
poison control center immediately.Do not delay
calling a physician merely because no adverse
effects are noticed at first; the toxic effects of a
gasoline-methanol blend, including blindness,
may not become apparent for many hours.If
gasoline is swallowed, do not induce vomiting.
If a gasoline-methanol blend is swallowed,
induce vomiting under the direction of a
physician or poison control center.
*
[MC34900( ALL)01/96]
Gasoline and gasoline-methanol blends may
contain small amounts of carcinogens, such as
benzene. Long-term exposure to unleaded
gasoline vapors has caused cancer in laboratory
animals. Further, excessive inhalation of fuel
vapors can cause headache, dizziness, nausea,
loss of coordination, and other symptoms which
could interfere with your ability to safely
operate your vehicle. To the extent possible,
avoid breathing vapors while refueling. If fuel
vapors are inhaled in excessive quantities, move
the victim to fresh air and seek medical
attention.
*
[MC35000( ALL)01/96]
Fuels can also be harmful if absorbed through
the skin. When refueling, be careful not to
splash fuel on yourself or your clothing. If fuel
is splashed on the skin, promptly remove
contaminated clothing and wash the skin
thoroughly with soap and water.
File:11ltmcm.ex
Update:Fri Dec 13 11:24:54 1996

132
*
[MC35100( ALL)01/96]
Fuels can cause severe eye irritation and possibly
eye damage. If fuel is splashed in the eyes,
remove contact lenses (if worn), flush with large
amounts of water for 15 minutes, and seek
medical attention.
*
[MC35200( ALL)01/96]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
*
[MC35300( ALL)01/96]
Filling the fuel tank
*
[MC35400( ALL)01/96]
RWARNING
Do not overfill the fuel tank. The pressure
in an overfilled tank may cause leakage
and lead to fuel spray and fire.
*
[MC35500( ALL)01/96]
To fill the fuel tank properly:
*
[MC35600( ALL)01/96]
NOTE: Extinguish all lit cigarettes, other
smoking materials, and any open
flames before fueling your vehicle.
*
[MC35700( ALL)01/96]
1. Remove the fuel cap by following the
instructions above underRemoving the Fuel
Capin this chapter. Proceed to add fuel to
the tank only if your vehicle is on level
ground.
*
[MC35800( ALL)01/96]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe.
*
[MC35900( ALL)01/96]
NOTE: If you spill any fuel on the body of
your vehicle, clean it off immediately.
The fuel may dull or soften the paint
if you do not wash it off.
