1996 FORD ESCORT Owners Manual

6
%*
[IN07100(ALL)04/95]
Cleaning the Outside of Your
Vehicle
%*
[IN07200(ALL)04/95]
Washing and Polishing Your Vehicle
*
[IN07300(ALL)04/95]
Wash the outside of your vehicle, including the
underside, with a mild detergent.
*
[IN07400(ALL)06/95]
DO NOT:
*
[IN07500(ALL)04/95]
q
Wash your vehicle with hot water
*
[IN07600(ALL)04/95]
q
Wash your vehicle while it sits in direct
sunlight
*
[IN07700(ALL)04/95]
q
Wash your vehicle while the body is hot
*
[IN07800(ALL)07/95]
Pollen, bird droppings and tree sap can damage
the paint, especially in hot weather. Wash your
vehicle as often as necessary to keep it clean.
*
[IN07900(ALL)07/95]
Take similar precautions if your vehicle is
exposed to chemical industrial fallout.
*
[IN08000(ALL)07/95]
Paint damage resulting from fallout is not
related to a defect in paint materials or
workmanship and therefore is not covered by
warranty. Ford, however, believes that continual
improvement in customer satisfaction is a high
priority. For this reason, Ford has authorized its
dealers to repair, at no charge to the owner, the
surfaces of new vehicles damaged by
environmental fallout within 12 months or 12,000
miles (20,000 km) of purchase, whichever comes
first. Customers may be required to bring their
vehicle in for inspection by a Ford
representative.
*
[IN08100(ALL)04/95]
Polish your vehicle to remove harmful deposits
and protect the finish.
File:02ctine.ex
Update:Tue Sep 19 14:42:23 1995

7 %
*
[IN08200(ALL)04/95]
Cleaning Chrome and Aluminum Parts
*
[IN08300(ALL)04/95]
Wash chrome and aluminum parts with a mild
detergent. Do not use steel wool, abrasive
cleaners, fuel, or strong detergents.
%*
[IN08400(ALL)04/95]
Cleaning Plastic Parts
*
[IN08500(ALL)04/95]
Some of your vehicle's exterior trim parts are
plastic. Clean with a tar and road oil remover if
necessary. Use a vinyl cleaner for routine
cleaning.
*
[IN08600(ALL)04/95]
Do not clean plastic parts with thinners, solvents
or petroleum-based cleaners.
%*
[IN08700(ALL)04/95]
If you have your vehicle rustproofed, remove
oversprayed rustproofing with a tar and road oil
remover. If rustproofing is not removed from
plastic and rubber parts, it can cause
deterioration.
File:02ctine.ex
Update:Tue Sep 19 14:42:23 1995

9
Safety Restraints
%*
[SR00500(ALL)04/95]
Important Safety Belt Information
*
[SR00600(ALL)03/95]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
*
[SR00700(ALL)08/95]
Safety belts provide best restraint when:
*
[SR00800(ALL)08/95]
q
the seatback is upright
*
[SR00900(ALL)08/95]
q
the occupant is sitting upright (not slouched)
*
[SR01000(ALL)08/95]
q
the lap belt is snug and low on the hips
*
[SR01100(ALL)08/95]
q
the shoulder belt is snug against the chest
*
[SR01200(ALL)08/95]
q
the knees are straight forward
[SR01300(ALL)06/95]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety belt warning light/chimein the
Warning Lights and Gaugeschapter.
*
[SR01400(ALL)07/95]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
%*
[SR02000(ALL)05/95]
RWARNING
Make sure that you and your passengers
wear safety belts. Always drive and ride
with your seatback upright and the lap
belt snug and low across the hips.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

10 [SR02100(ALL)08/95]
RWARNING
Passengers should not be allowed to ride
in the cargo area. Persons not riding in a
seat with a fastened seat belt are much
more likely to suffer serious injury in a
collision. Cargo should always be secured
to prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
*
[SR02200(ALL)06/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
*
[SR02350(ALL)06/95]
RWARNING
Never drive or ride with a twisted or
jammed safety belt. If you cannot untwist
or unjam the safety belt, see the nearest
qualified technician immediately.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

11
*
[SR02400(ALL)06/95]
RWARNING
Children should always ride with the
seatback in the fully upright position.
When the seatback is not fully upright,
there is a greater risk that the child will
slide under the safety belt and be
seriously injured in a collision.
*
[SR02500(ALL)08/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR02700(ALL)09/95]
RWARNING
Lock the doors of your vehicle before
driving to lessen the risk of the door
coming open in a collision.
[SR03100(E )07/93]
Motorized Shoulder Belt Passive Restraint
System (Not available on Canadian
vehicles)
[SR03200(ALL)01/92]
The front seat shoulder belts automatically adjust
and together with the manual lap belt, help to
provide added restraint in the event of a
collision.
[SR03300(ALL)04/93]
While you drive, the shoulder belt adjusts to
your movement. However, if you brake hard,
turn hard, or if your car receives an impact of
5 mph (8 km/h) or more, the shoulder belt
locks and helps reduce your forward movement.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

12 [SR03400(ALL)06/94]
half page art:0070061-EThe proper position of the front lap safety belt
*
[SR03500(ALL)07/95]
RWARNING
The lap belts should fit snugly and as low
as possible around the hips, not around
the waist.
[SR03600(ALL)02/95]
To operate the motorized shoulder belt:
[SR03700(ALL)02/94]
1. Get into your vehicle and close the door.
Check to be sure the shoulder belt is latched
to the emergency release buckle.
[SR03750(ALL)11/92]
2. If it is not latched, pull the shoulder belt
from the retractor and buckle it to the
emergency release buckle. Note the twist in
the shoulder belt as in Figures 1 and 2.
*
[SR03800(ALL)11/92]
3. Turn the ignition key to the ON position.
[SR03900(ALL)02/95]
A motor causes the shoulder belt to slide along
its track from the A-pillar to the B-pillar until it
locks in place.
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

13 [SR03950(ALL)03/93]
If the belt does not lie flat against you, or the
belt has a twist in it at the retractor, unlatch the
belt at the buckle, remove twist, and relatch the
belt into the buckle.
[SR04000(ALL)06/94]
half page art:0070041-E
The shoulder belt sliding along its track
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

14 [SR04100(ALL)08/92]
half page art:0070042-BThe shoulder belt in the locked position
[SR04200(ALL)10/91]
half page art:0070043-A
The shoulder belt in the locked position
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995
