1996 FORD ESCORT Owners Manual

103 [SR20710(ALL)08/95]
Cleaning the built-in child seat
[SR20720(ALL)08/95]
Your built-in child seat may be cleaned with
mild soap and water. Do not use household
cleaners as they may weaken the webbing or
damage the plastic parts. For your convenience,
the liner is removable and can be
machine-washed and air-dried. See Figure 12.
[SR20730(ALL)09/95]
one third page art:0070256-D
Figure 12: Removing the washable liner
File:03ctsre.ex
Update:Tue Sep 19 15:05:35 1995

105
Starting Your Escort
*
[ST03300(ALL)03/95]
Ignition
%*
[ST03400(ALL)01/95]
Understanding the Positions of the Ignition
[ST03500(ALL)09/95]
Your vehicle may have one of the following lock
cylinders depending on when it was built:
[ST03600(ALL)09/95]
quarter page art:0070292-A
The ignition lock cylinders
[ST03605(ALL)02/94]
LOCK locks the steering wheel when the key is
removed. It also locks the console-mounted
gearshift on vehicles with automatic transaxles.
To turn the key to this position on an automatic
transaxle vehicle, the shift control lever must be
in P (Park).
*
[ST03610(ALL)05/95]
RWARNING
LOCK position does not lock the gearshift
on floor-mounted manual transaxle
gearshifts. If the parking brake is not set
and the gearshift is moved out of gear,
your vehicle may move unexpectedly and
injure someone.
File:04ctste.ex
Update:Tue Sep 19 14:42:54 1995

106 [ST03615(ALL)08/95]The automatic transaxle console-mounted
gearshift will lock only when you turn the key
to LOCK. When the gearshift is in any gear
position but P (Park), the ignition key cannot be
turned to LOCK or be removed from the
steering column.
[ST03620(ALL)02/95]
If you have a manual transaxle, you must push
the key in while turning to the LOCK position
in order to remove the key.
*
[ST03625(ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
[ST03635(ALL)09/95]
OFF (if equipped) allows you to shut off the
engine and all accessories without locking the
steering wheel.
*
[ST03650(ALL)07/95]
ACC (accessory) allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
[ST03850(ALL)02/95]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. (The brake system warning light will
remain lit if the parking brake is set or if there
is a problem with the brake system.) The key
returns to the ON position once the engine is
started and remains in this position while the
engine runs.
[ST03900(ALL)02/95]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake system warning light.
File:04ctste.ex
Update:Tue Sep 19 14:42:54 1995

107 %
*
[ST04500(ALL)02/95]
Removing the Key From the Ignition
*
[ST04600(ALL)05/94]
Procedures for removing your key from the
ignition vary, depending on whether your
vehicle has an automatic or manual transaxle.
*
[ST04700(ALL)04/94]
If your vehicle has an automatic transaxle:
*
[ST04800(ALL)06/92]
1. Put the gearshift lever in P (Park).
*
[ST04900(ALL)01/95]
2. Set the parking brake fully.
*
[ST04950(ALL)03/95]
3. Turn the ignition key to LOCK.
*
[ST05100(ALL)03/95]
4. Remove the key.
*
[ST05200(ALL)04/94]
If your vehicle has a manual transaxle:
*
[ST05300(ALL)06/92]
1. Put the gearshift lever in 1 (First).
*
[ST05400(ALL)01/95]
2. Set the parking brake fully.
[ST05450(ALL)02/95]
3. Turn the ignition key counterclockwise to
ACC. Push the key in while turning to
LOCK.
*
[ST05900(ALL)03/95]
4. Remove the key.
%*
[ST06000(ALL)05/95]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
*
[ST07500(ALL)06/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park) (automatic transaxle) or
in 1 (First) (manual transaxle).
File:04ctste.ex
Update:Tue Sep 19 14:42:54 1995

108
*
[ST07600(ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
%
*
[ST07700(ALL)03/95]
Fuel-Injected Engines
*
[ST07800(ALL)03/95]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[ST08200(ALL)03/95]
Starting Your Vehicle
%*
[ST08300(ALL)05/94]
Preparing to Start Your Vehicle
*
[ST08350(ALL)07/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
File:04ctste.ex
Update:Tue Sep 19 14:42:54 1995

109
*
[ST08400(ALL)01/95]
Before you start your vehicle, do the following:
*
[ST08500(ALL)08/95]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[ST08600(ALL)03/95]
2. Make sure the headlamps and other
accessories are turned off when starting.
*
[ST08700(ALL)02/92]
3.If you have an automatic transaxle, make
sure that the gearshift is in P (Park) and the
parking brake is set before you turn the key.
[ST08750(ALL)03/95]
If you have an automatic transaxle, your
vehicle has a special shift-lock safety feature.
It prevents you from moving the gearshift
lever out of the P (Park) position unless the
ignition is in the ON position and your foot
is on the brake. To move the gearshift lever,
you must also depress the thumb button.
*
[ST08800(ALL)07/93]
If you have a manual transaxle, make sure
that the parking brake is fully set, push the
clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.(Remember, the starter will operate
only if the clutch pedal is pushed all the
way to the floor.)
[ST09000(ALL)06/95]
4. Before you start your vehicle, you should
check the warning lights on the instrument
panel to make sure that they work. Refer to
theWarning Lights and Gaugeschapter.
%*
[ST09400(ALL)02/95]
Starting Your Engine
*
[ST09500(ALL)06/95]
To start your engine:
*
[ST09600(ALL)05/95]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[ST09650(ALL)03/95]
2. Turn the ignition key to the ON position.
*
[ST09720(ALL)06/95]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
File:04ctste.ex
Update:Tue Sep 19 14:42:54 1995

110
*
[ST09740(ALL)02/95]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[ST09750(ALL)02/95]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
%*
[ST09752(ALL)04/95]
For a cold engine:
*
[ST09754(ALL)06/95]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[ST09756(ALL)04/95]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
%*
[ST09768(ALL)05/95]
For a warm engine:
*
[ST09770(ALL)04/95]
q
Do not hold the key in the START position
for more thanfive (5) secondsat a time. If
the engine does not start within five (5)
seconds on the first try, turn the key to the
OFF position. Wait a few seconds after the
starter stops, then try again.
*
[ST09780(ALL)08/95]
Whenever you start your vehicle, release the key
as soon as the engine starts. Excessive cranking
could damage the starter.
*
[ST09790(ALL)09/95]
After starting, allow the engine to idle for a few
seconds before driving away.
File:04ctste.ex
Update:Tue Sep 19 14:42:54 1995

111
*
[ST09800(ALL)05/95]
NOTE: If your vehicle is equipped with an
automatic transaxle, your vehicle has
an interlock that prevents you from
shifting out of P (Park) unless your
foot is on the brake pedal.
%*
[ST09860(ALL)04/95]
If the engine does not start after two attempts:
*
[ST09880(ALL)03/95]
1. Turn the key to the OFF position and wait
about two minutes.
*
[ST09890(ALL)04/95]
2. Press the accelerator all the way to the floor
and hold it.
*
[ST09900(ALL)04/95]
3. Turn the ignition key to the START position.
*
[ST09910(ALL)04/95]
4. Release the ignition key when the engine
starts.
*
[ST09920(ALL)04/95]
5. Release the accelerator gradually as the
engine speeds up. Then drive away in the
normal manner.
*
[ST09930(ALL)04/95]
If the engine still does not start, the fuel pump
shut-off switch may have been triggered. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchlater in this chapter.
[ST10200(ALL)06/93]
A computer system controls the engine's idle
RPM. When you start your vehicle, the engine's
idling RPM normally runs higher than when
warm. The engine idle control system should
only be serviced by a qualified technician.
*
[ST10290(ALL)07/95]
If the engine idle speed does not slow down
automatically, do not allow your vehicle to idle
for more than 10 minutes. Have the vehicle
checked.
File:04ctste.ex
Update:Tue Sep 19 14:42:54 1995
