1996 FORD ESCORT Owners Manual

128 [LG10450(ALL)02/94]
one inch art:0070205-AThe anti-lock brake system light
%*
[LG20000(ALL)02/95]
Engine Oil Pressure Warning Light
[LG20025(ALL)06/95]
This light indicates low oil pressure,not low oil
level. However, if your engine's oil level is low,
it could affect the oil pressure. This light comes
on every time your ignition key is turned to ON
or START. The light should turn off after a few
seconds. If the light stays on when the engine is
running, you have lost oil pressure and
continued operation will cause severe engine
damage.
[LG20050(ALL)03/93]
one inch art:0000839-A
The engine oil pressure light
*
[LG20100(ALL)03/95]
1. Pull off the road as soon as safely possible.
*
[LG20125(ALL)11/94]
2. Shut off the engine immediately. If you do
not stop the engine as soon as safely
possible, severe engine damage could result.
*
[LG20150(ALL)11/94]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil in this Owner Guide. (SeeEngine oilin
the Index.) If you do not follow these
instructions, you or others could be injured.
To ensure an accurate reading, your vehicle
should be on level ground.
File:05ctlge.ex
Update:Tue Sep 19 14:44:43 1995

129 [LG20175(ALL)02/94]
4. If the oil level is low, add as much oil as
necessary before you drive your vehicle
again. Do not overfill. Do not operate the
engine when the oil pressure light is on,
even if the oil level is correct. For more
information about adding oil, seeAdding
engine oilin the Index.
%*
[LG20176(ALL)01/95]
Fuel Gauge
*
[LG20177(ALL)06/93]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON.
[LG20178(ALL)06/93]
For proper fuel gauge indication after adding
fuel, the ignition switch should be in the OFF
position while the vehicle is being refueled.
*
[LG20179(ALL)06/93]
The fuel gauge indicator may vary slightly when
the vehicle is in motion.
[LG20180(ALL)06/93]
With the ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
%*
[LG20181(ALL)01/95]
Speedometer
*
[LG20182(ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[LG20183(ALL)01/95]
Odometer
*
[LG20184(ALL)01/95]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[LG20185(ALL)11/94]
Trip Odometer
*
[LG20186(ALL)11/94]
The trip odometer tells you how many miles
(kilometers) your vehicle has been driven since
the last reset. Press the reset button to return the
trip odometer to zero.
File:05ctlge.ex
Update:Tue Sep 19 14:44:43 1995

130 %
*
[LG20187(ALL)01/95]
Engine Coolant Temperature Gauge
*
[LG20188(ALL)03/95]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[LG20189(ALL)06/94]
The pointer moves from C (Cold) into the
normal band as your vehicle warms up. Under
most driving conditions, the pointer should stay
in the normal band. If you are driving in heavy
traffic or uphill in hot weather, the pointer may
reach to the top of the normal band.
[LG20190(ALL)06/94]
one third page art:0070160-B[LG20191(ALL)10/89]
Under any circumstances, if the pointer moves
past the upper limit of the normal band, the
engine is overheating and may result in engine
damage.
File:05ctlge.ex
Update:Tue Sep 19 14:44:43 1995

131
*
[LG20192(ALL)01/95]
If your engine coolant overheats:
*
[LG20193(ALL)03/95]
1. Pull off the road as soon as it is safely
possible.
*
[LG20194(ALL)01/95]
2. Turn off the engine.
*
[LG20195(ALL)05/95]
3. Let the engine cool.
*
[LG20196(ALL)03/95]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine. (SeeEngine coolantin the
Index.) If you do not follow these
instructions, you or others could be injured.
*
[LG20197(ALL)05/92]
5. Add as much coolant as your engine needs.
If the engine continues to overheat, have the
coolant system serviced.
[LG20200(E )12/89]The Sport Cluster
*
[LG20300(E )04/94]
The sport cluster has basically the same standard
warning lights and gauges as the standard
cluster, with the following additional features:
File:05ctlge.ex
Update:Tue Sep 19 14:44:43 1995

132 [LG20350(E )09/95]
full page art:0070058-GThe sport cluster
File:05ctlge.ex
Update:Tue Sep 19 14:44:43 1995

133 %
*
[LG22100(ALL)02/95]
Tachometer
[LG22150(ALL)10/89]
The tachometer tells you the approximate engine
revolutions per minute (how fast the engine is
running). The tachometer is on the right side of
the instrument cluster.
*
[LG22300(ALL)04/95]
Driving with the pointer in the red zone may
cause engine damage.
File:05ctlge.ex
Update:Tue Sep 19 14:44:43 1995

135
Instrument Panel Controls
%*
[IP00350(ALL)01/95]
The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
[IP00400(ALL)03/95]
The main controls for the climate control system,
lamps, clock, and radio are on the instrument
panel.
File:06ctipe.ex
Update:Tue Sep 19 14:46:28 1995

136 [IP00420(ALL)08/95]
full page art:0070016-HInstrument panel Ð typical equipment shown
