1996 FORD ESCORT washer fluid

156
[IP32600(ALL)06/93]
Rear Window Wiper and Washer
(Available on wagons only)
[IP32630(ALL)09/95]
two third page art:0070259-A[IP32640(ALL)06/93]
To use the rear window wiper, push the right
side of the rear window wiper and washer
switch. Push the left side of the switch to turn
the rear window wiper off. To wash the rear
window, push in the button marked WASH.
Windshield washer fluid will stream onto the
rear window.
File:06ctipe.ex
Update:Tue Sep 19 14:46:28 1995

161 [SC01550(ALL)08/95]
To clean the windshield, push in the end of the
wiper knob. For a constant spray, keep the knob
pushed in. After you release the knob, the
wipers operate for two or three cycles before
turning off (if wipers were off) or retruning to
the interval setting selected.
[SC01600(ALL)08/95]
Do not try to clean the windshield when the
washer fluid container is empty or activate the
washers at any time for more than 15 seconds
continuously. This could damage the washer
pump system.
[SC01650(ALL)08/95]
RWARNING
In freezing weather, warm up the
windshield with the defroster before you
use the washer fluid. If you do not do
this, the washer solution may freeze on
the windshield and obscure your vision.
This may result in a collision, possibly
injuring you and others.
[SC01700(ALL)08/95]
For information about refilling the washer fluid
or replacing your windshield wiper blades, see
Windshield washer fluid and wipersin the Index.
File:07ctsce.ex
Update:Tue Sep 19 14:47:40 1995

287 %
*
[SV05840(ALL)04/95]
Cleaning the Engine
*
[SV05850(ALL)04/95]
A clean engine is more efficient because a
buildup of grease and dirt acts as an insulator,
keeping the engine warmer than normal.
*
[SV05860(ALL)07/95]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[SV05870(ALL)08/95]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[SV05880(ALL)07/95]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[SV05890(ALL)04/95]
q
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%
*
[SV06100(ALL)03/95]
Filling the Fuel Tank
[SV06110(ALL)01/92]
The fuel filler door can be opened by pulling on
the finger hold located on the rear edge of the
fuel filler door.
[SV06235(ALL)07/93]
For your convenience, a fuel filler door location
indicator is included in your instrument cluster.
It indicates which side of your vehicle contains
the fuel filler door.
[SV06275(ALL)08/95]
The fuel filler door is outside the vehicle on the
driver side near the back.
[SV06300(ALL)03/95]
1. Turn the ignition switch to the OFF position
and remove the key. To remove the fuel cap,
turn it counterclockwise.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

298
*
[SV17455(ALL)09/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[SV17460(ALL)09/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
[SV17475(ALL)05/94]
NOTE: Additional illumination may be needed
to see the coolant reservoir markings
clearly.
[SV17500(ALL)06/94]
one third page art:0070033-D
The engine coolant reservoir
[SV17560(ALL)08/95]
If the engine coolant has not been checked for a
long period of time the engine coolant reservoir
may eventually empty. If the engine coolant
reservoir empties, check the engine coolant level
in the radiator. Read the following instructions
before removing the radiator cap. If it is
necessary to fill the radiator, refer to theRefill
Capacitieschart later in this chapter.
*
[SV17565(ALL)09/95]
RWARNING
Failure to follow these instructions could
result in serious personal injury from hot
engine coolant or steam blowout and/or
damage to the engine cooling system or
engine.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

301
*
[SV19480(ALL)04/93]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep an engine coolant in your
engine that has a protection rating of at least
-20ÊF (-29ÊC), orwhatever protection rating is
appropriate for the climate in which you live.
*
[SV19900(ALL)02/95]
You may add water by itself only in an
emergency, but you should replace it with a
50/50 mixture as soon as possible.
*
[SV20000(ALL)01/95]
Have your dealer check the engine cooling
system for leaks if you have to add a quart
(liter) of engine coolant more than once a month.
%*
[SV20210(ALL)08/95]
Checking Hoses
*
[SV20220(ALL)01/93]
Inspect all engine and heater system hoses for
deterioration, leaks and loose clamps before
adding or replacing engine coolant. Make
whatever repairs or replacements are necessary
using Motorcraft parts or their equivalents.
%
*
[SV21700(ALL)03/95]
Windshield Washer Fluid and
Wipers
%*
[SV21800(ALL)03/95]
Washer Fluid
[SV22100(ALL)01/95]
The windshield washer reservoir is located in
the engine compartment.
*
[SV22350(ALL)05/95]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
%*
[SV22500(ALL)01/95]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

302(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOC's) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
[SV22600(ALL)03/95]
Washer Fluid for the Liftgate (Wagon only
Ð if equipped)
[SV22625(ALL)10/89]
one third page art:0000876-A
Location of the rear windshield washer reservoir
[SV22650(ALL)09/95]
The wagon's rear reservoir is located on the
passenger side of the storage compartment. You
must remove the access cover to find the washer
reservoir cap. The reservoir must be filled slowly
to allow air trapped in the reservoir to escape.
%*
[SV23200(ALL)03/95]
Wiper Blades
*
[SV23300(ALL)03/95]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Substances such as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

382 Index
Overdrive................ 226
Overseas offices............. 269
P
Parking brake
operation............... 235
Parts (see Motorcraft Parts)........ 347
PCV valve, specifications......... 347
Power door locks............ 170
Power features
door locks.............. 170
mirrors................ 184
moon roof.............. 174
windows............... 172
Power steering
dipstick............... 319
driving with power steering...... 232
fluid, checking and adding....... 319
fluid, refill capacity.......... 345
fluid, specifications.......... 348
Prop rod, hood............. 282
R
Radio (see Electronic sound systems) . . . 197
Rear axle
lubricant specification......... 349
Rear window.............. 172
washer reservoir........... 301
Refill capacities for fluids........ 345
Restraints, safety (see Safety restraints)
adult.................. 9
child.................. 58
head................. 177
infant................. 58
Roadside assistance........... 259
Roadside emergencies.......... 243
Rotating the tires............ 307
File:ctixe.ex
Update:Tue Sep 19 15:00:54 1995

386 Index
U
Used engine oil, disposal.....280, 300, 317
V
VECI (Vehicle Emission Control
Information) decal........... 342
Vehicle Identification Number (VIN) . . . 267
Vehicle loading
calculating the load.......... 241
understanding loading information . . . 240
Vehicle storage............. 350
Ventilating your vehicle
(see Climate control)......... 137
Viscosity (see Engine oil)......... 294
W
Warm engine, starting.......... 110
Warning lights (see Lights)......117, 135
Warranties
basic.................. 4
Canada................. 4
radio................. 222
Warranty Information Booklet....... 4
Washer fluid
rear window reservoir......... 302
reservoir............... 301
windshield.............. 301
Weight limits (GAWR, GVWR)...... 240
Wheel and tire matching......... 309
Wheel bearings, lubricant specifications . . 349
Wheel dollies (see Towing)........ 257
File:ctixe.ex
Update:Tue Sep 19 15:00:54 1995
