1996 FORD ESCORT Owners Manual

298
*
[SV17455(ALL)09/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[SV17460(ALL)09/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
[SV17475(ALL)05/94]
NOTE: Additional illumination may be needed
to see the coolant reservoir markings
clearly.
[SV17500(ALL)06/94]
one third page art:0070033-D
The engine coolant reservoir
[SV17560(ALL)08/95]
If the engine coolant has not been checked for a
long period of time the engine coolant reservoir
may eventually empty. If the engine coolant
reservoir empties, check the engine coolant level
in the radiator. Read the following instructions
before removing the radiator cap. If it is
necessary to fill the radiator, refer to theRefill
Capacitieschart later in this chapter.
*
[SV17565(ALL)09/95]
RWARNING
Failure to follow these instructions could
result in serious personal injury from hot
engine coolant or steam blowout and/or
damage to the engine cooling system or
engine.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

299
*
[SV17570(ALL)09/95]
1. Before you remove the radiator cap, turn the
engine off and let it cool. Even when the
engine is cool, be careful when you remove
the radiator cap.
*
[SV17580(ALL)09/95]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly
counterclockwise to the first stop.
*
[SV17590(ALL)09/95]
3. Step back while the pressure releases.
*
[SV17600(ALL)09/95]
4. When you are sure that all the pressure has
been released, use the cloth to press, turn,
and remove cap.
*
[SV17610(ALL)09/95]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
*
[SV18100(ALL)08/95]
Adding Engine Coolant
*
[SV18300(ALL)09/95]
RWARNING
Never remove the coolant recovery cap
while the engine is running or hot.
*
[SV18950(ALL)08/95]
To find out how much engine coolant mixture
your vehicle's coolant system can hold, seeRefill
capacities for fluidsin the Index.
*
[SV19350(ALL)02/95]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km). It is not
necessary and not recommended to use
supplemental coolant additives in your gasoline
powered vehicle. These additives may harm
your engine cooling system. Follow the
recommended service interval for changing your
engine coolant.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

300
*
[SV19450(ALL)04/94]
NOTE: When you change or add engine
coolant, it is important to maintain
your engine coolant concentration
between 40%(-11ÊF [-24ÊC]) and 60%
(-62ÊF [-52ÊC]),depending on your local
climate conditions. Below 40% you will
lose freeze protection and above 60%
your engine may overheat on a warm
day.
*
[SV19452(ALL)03/95]
NOTE: The use of an improper coolant may
void your warranty for the engine
cooling system. Use only a premium,
nationally recognized brand name
engine coolant. Do not use alcohol,
methanol antifreeze or engine coolant
mixed with alcohol or methanol
antifreeze. If you do not use the proper
coolant, the aluminum engine on your
vehicle will corrode.
*
[SV19455(ALL)02/94]
Ford Motor Company expressly authorizes the
Ford Rotunda engine coolant recycling process
and chemicals. Use only Ford Rotunda recycled
engine coolant or an equivalent non-Ford
Rotunda recycled engine coolant that is certified
by the supplier to meet Ford specification
ESE-M97B44-A.
%*
[SV19456(ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV19460(ALL)03/95]
Use Ford Premium Cooling System Fluid
E2FZ-19549-AA (in Canada, Motorcraft CXC-8-B)
or an equivalent engine coolant that meets Ford
Specification ESE-M97B44-A.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

301
*
[SV19480(ALL)04/93]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep an engine coolant in your
engine that has a protection rating of at least
-20ÊF (-29ÊC), orwhatever protection rating is
appropriate for the climate in which you live.
*
[SV19900(ALL)02/95]
You may add water by itself only in an
emergency, but you should replace it with a
50/50 mixture as soon as possible.
*
[SV20000(ALL)01/95]
Have your dealer check the engine cooling
system for leaks if you have to add a quart
(liter) of engine coolant more than once a month.
%*
[SV20210(ALL)08/95]
Checking Hoses
*
[SV20220(ALL)01/93]
Inspect all engine and heater system hoses for
deterioration, leaks and loose clamps before
adding or replacing engine coolant. Make
whatever repairs or replacements are necessary
using Motorcraft parts or their equivalents.
%
*
[SV21700(ALL)03/95]
Windshield Washer Fluid and
Wipers
%*
[SV21800(ALL)03/95]
Washer Fluid
[SV22100(ALL)01/95]
The windshield washer reservoir is located in
the engine compartment.
*
[SV22350(ALL)05/95]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
%*
[SV22500(ALL)01/95]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

302(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOC's) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
[SV22600(ALL)03/95]
Washer Fluid for the Liftgate (Wagon only
Ð if equipped)
[SV22625(ALL)10/89]
one third page art:0000876-A
Location of the rear windshield washer reservoir
[SV22650(ALL)09/95]
The wagon's rear reservoir is located on the
passenger side of the storage compartment. You
must remove the access cover to find the washer
reservoir cap. The reservoir must be filled slowly
to allow air trapped in the reservoir to escape.
%*
[SV23200(ALL)03/95]
Wiper Blades
*
[SV23300(ALL)03/95]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Substances such as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

303
*
[SV23400(ALL)09/95]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear water. Do
not use fuel, kerosene, paint thinner, or other
solvents to clean your wiper blades. These will
damage your blades.
[SV23450(ALL)07/93]
Inspect the wiper arm pivots on a regular basis
to ensure that the wiper arms move freely.
Lubricate the pivot points if necessary.
[SV23475(ALL)08/93]
half page art:0070198-A
Wiper arm pivot points
[SV23500(ALL)03/95]
To make reaching the wiper blades easy, simply
turn the ignition switch to the ON position and
turn the wipers on. Wait for them to reach a
vertical position and turn the ignition to OFF.
Do not move the wipers manually. Manually
moving the wipers across the windshield may
damage them.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

304
*
[SV23600(ALL)03/01]
Wiper blade replacement
*
[SV23700(ALL)09/95]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent.
[SV23750(ALL)08/93]
NOTE: There are two different length wiper
blades on your vehicle. The driver-side
wiper blade is 20 inches (50 cm) long,
and the passenger-side wiper blade is
17 inches (45 cm) long. Ensure that you
install the correct size wiper blade in
the correct location.
[SV23755(ALL)08/95]
To replace the wiper blades:
[SV23760(ALL)08/95]
1. Pull the wiper arm away from the
windshield and lock into the service position.
[SV23765(ALL)08/95]
2. Turn the blade at an angle from the wiper
arm. Push the lock pin with a screwdriver to
relase the blade and pull the wiper blade
down toward the windshield to remove it
from the arm.
[SV23770(ALL)08/95]
3. Attach a new wiper blade to the wiper arm
and press it into place until you hear it click.
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

305 [SV23775(ALL)08/95]
two third page art:0032367-A
Replacing the wiper blades
