MANUAL TRANSAXLE Differential Assembly / Speed-
- ometer Driven Gear Assembly22-45
TFYOO4Q
The numerals @to @ indicate
the tightening sequence.
9
SPEEDOMETER DRIVEN GEAR ASSEMBLY
DISASSEMBLY AND REASSEMBLY
3. INSTALLATION OF TAPER ROLLER BEARINGInstall the taper roller bearings on both sides of the
differential case.
CautionWhen press-fitting the bearings, push the inner race
only.
1.INSTALLATION OF BOLTS
Apply specified adhesive to the entire threads of the bolts
and quickly tighten in the order shown to specified torque.
Specified adhesive: 3M Stud Locking Part No. 4170 or
equivalent
CautionIf a bolt is reused, remove traces of oil adhesive
completely from the threads.MZ2MNAE
Disassembly steps
I. O-ringl *2. Spring pin
l *3. Speedometer driven gear4. Oil seal
5. Sleeve201078
201075
SERVICE POINTS OF REASSEMBLY3. INSTALLATION OF SPEEDOMETER DRIVEN GEAR
Apply gear oil sparingly to the speedometer driven gear
shaft and insert the shaft.
2. INSTALLATION OF SPRING PIN
Install the spring pin in such a way that its slit does not facethe gear shaft.
J
TSB RevisionI

22-46MANUAL TRANSAXLE - Clutch Housing Assembly
CLUTCH HOUSING ASSEMBLYM22MPAM
DISASSEMBLY AND REASSEMELY
iJ15-22Nm
II- 15 ft.lbs.
/
1443q 15-
m16----@20-27Nm
15- 19ft.lbs.
2100019
Disassembly steps
1.Bolt
2. Select lever assembly
3. Select lever shoe
4. Interlock plate bolt
5.Gasket
4~ l a6. Lock pin+* I)* 7. Spring pin8. Neutral return spring
9.Stopper body10.Control finger11.Interlock plate12. Neutral return spring assembly13.Control shaft14. Control shaft boot
l * 15. Oil seal
l *16.Needle
bearingI)+ 17. Needle bearing
; 98: F:;tch housing
20.Return
spring21. Stopper plate
22. Spring pin
1 TSB Revision1

MANUAL TRANSAXLE - Clutch Housing Assembly22-47
1
Oil sealSocketwrench
SERVICE POINTS OF DISASSEMBLY6. REMOVAL OF LOCK PIN
Drive out the lock pin from the control finger using the pin
punch.
CautionWhen removing the lock pin, turn the control lever to
such position that the lock pin will not contact the
clutch housing.7. REMOVAL OF SPRING PIN
Drive out the spring pin from the stopper body using the pin
punch.
Caution
When removing the spring pin, pull the control shaft inthe direction illustrated so that the spring pin will not
contact the clutch housing.
SERVICE POINTS OF REASSEMBLY
17.16. INSTALLATION OF NEEDLE BEARINGSInstall the needle bearing flush with the surface A of the
clutch housing.
15. INSTALLATION OF OIL SEALInstall the control shaft oil seal using a socket wrench.
7. INSTALLATION OF SPRING PIN
/ 6. LOCK PIN
(I) Install new spring pin and lock pin using the special tool.
CautionDo not reuse the spring pin and lock pin.
(2) Install the spring pin with its slit at right angle to the
control shaft center.
TSB Revision

22-48MANUAL TRANSAXLE - General Information
MANUAL TRANSAXLE
GENERAL INFORMATION~M22BAAV I\,i ~
Ist-2nd speed synchronizer assembly
Transaxle case
3rd-4th speed synchronizer assembly
Input shaft 5th speed gear
Center shaft
\Front differential
Viscous couplingCenter differentral
Reverse idler
‘gear
TFMOllO
TSB Revision

MANUAL TRANSAXLE - Specifications
SPECIFICATIONS
22-49
MZZCA-B
iGENERAL SPECIFICATIONS
L
Items
Model
Applicable engine
Type
Gear ratio
1 St
2nd
3rd
4th
5th
Reverse
Reduction ratio
Primary
Front differential
Transfer
Speedometer gear ratio (driven/drive)
Oil quantityliters (qts.)
Transaxle
Transfer
Specifications
W5MGl-0-FNBR
6G72-DOHC (Turbo)
5-speed transaxle floor shift
3.071
1.739
1.103
0.823
0.659
3.076
1.375
2.888
0.814
27136
2.4(2.5)
0.27(.29)
LLUBRICANTSMUCD-B
Items
Specified lubricants1 Quantity lit. (qts.)I
classification GL4 or higher
1 Transfer oil seal lip
a:
TSB Revision

22-50MANUAL TRANSAXLE - Special T.ools
SPECIAL TOOLSMZZDA-B
foreign object entry
TSB Revision

MANUAL TRANSAXLE - Service Adjustment Procedures22-51SERVICE ADJUSTMENT PROCEDURES
TRANSMISSION OIL LEVEL INSPECTIONM22FBAE2
Refer to GROUP 00
- Maintenance Service.
TRANSMISSION OIL REPLACEiVlENTMUFCAJ
(I) Position vehicle on a flat level and remove filler and drainplugs to drain transmission oil.
(2) Pour in fresh transmission oil through filler port.
Transmission oil: Hypoid gear oil, SAE 75W-85W con-
forming to API classification GL-4 or
higherTransaxle: 2.4 liters (2.5 qts.)
Transfer: 0.27 liters
(.29 qts.)
(3) After checking to be sure that the oil level is the specifiedlevel, tighten the filler plug at the specified torque.
1 TSB Revision

22-52 MANUAL TRANSAXLE - Service Adjustment Procedures
DRIVE SHAFT OIL SEALS REPLACEMENTMZZFDAJ)(I) Disconnect the drive shaft from the transaxle.
(Refer to GROUP 26
- Drive Shaft.)
(2) Remove the transfer assembly.ij(3) Using a flat-tip
(-) screwdriver, remove the oil seal.
L.H. side\
For L.H.
Dust seal.
For R.H.(4) Install the oil seals using the following procedure:Using the special tool, tap the oil seal into the transaxle.
Note that there are two types of oil seals, one for R.H. and
the other for L.H., and the shape of each type is different,
as shown.
(5) Drive shaft
011 seal must be installed in the direction shown.(6)
$4~1~ a coatrng of the transmission oil to the lip of the oil
Transmission oil: Hypoid gear oil, SAE
75W-90 or
75W-85W conforming to API classi-fication GL-4 or higher
wision
