2016 FIAT 500X Owners Manual

Warnings And Cautions......................7
Warranty Information .....................4,13
Washer Adding Fluid ......................... .455
Washing Vehicle ......................... .470
Water Driving Through ....................... .347
Wheel And Wheel Trim .....................471
Wheel And Wheel Trim Care .................471
Wind Buffeting ....................... .131, 133
Windows .............................. .127
Windshield Defroster ...................111,265
Windshield Wiper Blades ....................453
Wiper Blade Replacement ...................453
Wipers, Intermittent ...................... .102
Wipers, Rain Sensitive ..................... .104
Wrecker Towing ......................... .419
12
INDEX 583

INSTALLATION OF RADIO TRANSMITTING
EQUIPMENT
Special design considerations are incorporated into this
vehicle’s electronic system to provide immunity to radio
frequency signals. Mobile two-way radios and telephone
equipment must be installed properly by trained person-
nel. The following must be observed during installation.
The positive power connection should be made directly
to the battery and fused as close to the battery as possible.
The negative power connection should be made to body
sheet metal adjacent to the negative battery connection.
This connection should not be fused.
Antennas for two-way radios should be mounted on the
roof or the rear area of the vehicle. Care should be used
in mounting antennas with magnet bases. Magnets may
affect the accuracy or operation of the compass on
vehicles so equipped.The antenna cable should be as short as practical and
routed away from the vehicle wiring when possible. Use
only fully shielded coaxial cable.
Carefully match the antenna and cable to the radio to
ensure a low Standing Wave Ratio (SWR).
Mobile radio equipment with output power greater than
normal may require special precautions.
All installations should be checked for possible interfer-
ence between the communications equipment and the
vehicle’s electronic systems.

First Edition
Printed in U.S.A.
FCA US LLC
©2015 FCA US LLC. All Rights Reserved.
FIAT is a registered trademark of Fiat Group Marketing
& Corporate Communication S.p.A., used under license by FCA US LLC.
16FB-126-AA
