Front Fog Lights
To replace the bulbs proceed as follows:
1. Turn the front wheels completely.
2. Use a suitable tool to remove the access door.
3. By pushing the electrical connector tab remove theelectrical connector. 4. Rotate the bulb counterclockwise, and then replace
the bulb.
5. Insert the new bulb in the socket, making sure the bulb is locked into place.
6. Reconnect the electrical connector.
7. Reinstall the access door.
Position Light/Daytime Running Light/Fog Light Access
1 — Screws
2 — Access Door
Fog Light Assembly
8
IN CASE OF EMERGENCY 295

Side Indicators on External Rear View Mirrors – If
Equipped
CAUTION!
The procedure is described as a guideline. For the
replacement of the lamp it is recommended that you
contact your authorized dealer.
To replace the bulb proceed as follows:
1. Remove the mirror cap on the outside rear view mirror.
2. Remove the transparent lens assembly as shown.
3. Remove the bulb socket and bulb from the transpar-ent lens assembly by rotating the socket counter-
clockwise.
4. Remove the bulb from the bulb socket by pulling the bulb straight out.
Mirror Cap
1 — Mirror Cover
2 — Side Indicator Lens
3 — Side Indicator Bulb Location
296 IN CASE OF EMERGENCY

5. Insert the new bulb, making sure that it is locked intoplace
6. Reinstall the socket in to the transparent lens assem- bly.
7. Reinstall the cover on the outside rear view mirror, making sure it is locked into place.
Rear Tail Lamps
Contain the following:
• Position lights
• Stop lights
• Direction indicator
• REVERSE lights To replace the bulbs proceed as follows:
1. Open the liftgate.
2. Using a suitable tool remove the tail lamp housing
screws as shown.
Tail Lamp Removal
8
IN CASE OF EMERGENCY 297

3. Remove the rear tail lamp, sliding it toward theoutside as shown.
4. Remove the screws and remove the rear tail lamp holder. 5. Replace the bulb as necessary.
Tail Lamp Removal
Rear Lamp Assembly
1 — Screws
298 IN CASE OF EMERGENCY

6. Insert the new bulb, making sure it is properlylocked.
7. Reassemble the lamp assembly on the rear tail lamp housing, tightening the screws.
8. Reposition the rear tail lamp on the vehicle. 9. Secure the rear tail lamp and reconnect the electrical
connector.
10. Finally close the liftgate.
3th Stop Lamp
The CHMSL is LED. For their replacement see your
authorized dealer.
License Plate Lights
To replace the bulbs proceed as follows:
1. Using a suitable tool remove the license plate lens.
Rear Tail Lamp Holder
1 — Running/Stop Lamp
2 — Direction Indicator Bulb
3 — Running/Stop Lamp
4 — Reverse Bulb
License Plate Light Location
8
IN CASE OF EMERGENCY 299

2. Remove the bulbs from the individual side contacts.
3. Insert the new bulbs, and ensure that they areproperly locked between the contacts.
4. Reinstall the license plate lens.
NOTE: If removal the license plate lens using a suitable
tool, be sure to cover the tip of the suitable with a cloth
so no damage is done to the lenses or the vehicle paint.
Replacing Interior Bulbs
Front Courtesy Light
To replace the bulbs proceed as follows:
1. Using a suitable tool remove the front courtesy light as shown.
License Plate Light
Front Courtesy Light Housing
300 IN CASE OF EMERGENCY

2. Release the retainer clips and bulb housing as shown.
3. Replace the bulbs by pulling straight out of bulbhousing. 4. Insert the new bulbs, making sure that they are
properly locked.
5. Reassemble the bulb housing and courtesy light housing making sure that they are properly locked.
6. Install the front courtesy light making sure that it is properly locked.
Front Courtesy Bulb Housing
1 — Retaining Clips
2 — Bulb Housing
Front Courtesy Bulb Housing
8
IN CASE OF EMERGENCY 301

Dome Light Vanity Mirror
To replace the bulbs proceed as follows:
1. Lift the cover of the mirror and pull out the visormirror light cover.
2. Replace the bulb, releasing it from the side contacts, and then insert the new bulb, making sure that it is
properly locked between the contacts.
3. Reinstall the visor mirror light cover making sure that it is properly locked.
4. Finally lower the visor mirror cover to the mirror. Dome Light Glove Compartment
To replace the bulb proceed as follows:
1. Open the glove compartment.
2. Place your fingers inside the light assembly, pull the
bulb to replace it.
3. Insert the new bulb, making sure it is properly locked.
Visor Mirror Cover
Bulb Removal/Installation
