2014 FIAT 500X Owners Manual

OWNER’S MANUAL
2017
2017 FIAT
® 500X
FIAT
®
500X
First Edition
Printed in U.S.A.
©2016 FCA US LLC. All Rights Reserved.
FIAT is a registered trademark of FCA Group
Marketing S.p.A., used under license by FCA US LLC.
17FB-126-AB

VEHICLES SOLD IN CANADAWith respect to any Vehicles Sold in Canada, the name FCA
US LLC shall be deemed to be deleted and the name FCA
Canada Inc. used in substitution therefore.DRIVING AND ALCOHOLDrunken driving is one of the most frequent causes of
accidents.
Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-
drinking driver, call a cab, a friend, or use public trans-
portation.
WARNING!
Driving after drinking can lead to an accident.
Your perceptions are less sharp, your reflexes are
slower, and your judgment is impaired when you
have been drinking. Never drink and then drive.
This manual illustrates and describes the operation of
features and equipment that are either standard or op-
tional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.
FCA US LLC reserves the right to make changes in design
and specifications, and/or make additions to or improve-
ments to its products without imposing any obligation
upon itself to install them on products previously manu-
factured.
Copyright © 2016 FCA US LLC

TABLE OF CONTENTSSECTIONPAGE
1INTRODUCTION
...............................................................3
2CUSTOMER ASSISTANCE
........................................................7
3GRAPHICAL TABLE OF CONTENTS
................................................13
4GETTING TO KNOW YOUR VEHICLE
...............................................19
5GETTING TO KNOW YOUR INSTRUMENT PANEL
.....................................119
6SAFETY
....................................................................153
7STARTINGANDOPERATING ....................................................211
8INCASEOFEMERGENCY.......................................................287
9MAINTAINING AND CARING FOR YOUR VEHICLE
....................................341
10TECHNICAL DATA
............................................................403
11MULTIMEDIA................................................................411
12 INDEX .....................................................................459
1
2
3
4
5
6
7
8
9
10 11
12

INTRODUCTION
CONTENTS
INTRODUCTION .......................4
 HOW TO USE THIS MANUAL .............4
 WARNINGS AND CAUTIONS .............5
VEHICLE MODIFICATIONS/ALTERATIONS . . .6
 ROLLOVER WARNING ..................6
1

INTRODUCTION
Congratulations on selecting your new vehicle. Be
assured that it represents precision workmanship, dis-
tinctive styling, and high quality.
This Owner’s Manual has been prepared with the
assistance of service and engineering specialists to
acquaint you with the operation and maintenance of
your vehicle. It is supplemented by Warranty Informa-
tion, and various customer-oriented documents. Please
take the time to read these publications carefully. Fol-
lowing the instructions and recommendations in this
manual will help assure safe and enjoyable operation of
your vehicle.
The enclosed Warranty Information lists the services
that FCA US LLC offers to its customers:
•The Warranty with terms and conditions for main-
taining its validity
• The range of additional services available to FCA US
LLC customers NOTE: After reviewing the owner information, it
should be stored in the vehicle for convenient refer-
encing and remain with the vehicle when sold.
When it comes to service, remember that your autho-
rized dealer knows your vehicle best, has factory-
trained technicians and genuine MOPAR® parts, and
cares about your satisfaction.
HOW TO USE THIS MANUAL
Consult the Table of Contents to determine which
section contains the information you desire.
Since the specification of your vehicle depends on the
items of equipment ordered, certain descriptions and
illustrations may differ from your vehicle’s equipment.
The detailed index at the back of this Owner’s Manual
contains a complete listing of all subjects.
Consult the following table for a description of the
symbols that may be used on your vehicle or through-
out this Owner’s Manual:
4 INTRODUCTION

WARNINGS AND CAUTIONS
This Owner ’s Manual containsWARNINGSagainst
operating procedures that could result in a collision,
bodily injury and/or death. It also contains CAU-
TIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner ’s
Manual, you may miss important information. Observe
all Warnings and Cautions.
1
INTRODUCTION 5

VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle
could seriously affect its roadworthiness and safety
and may lead to a collision resulting in serious
injury or death.
ROLLOVER WARNING
Utility vehicles have a significantly higher rollover rate
than other types of vehicles. This vehicle has a higher
ground clearance and a higher center of gravity than
many passenger vehicles. It is capable of performing
better in a wide variety of off-road applications. Driven
in an unsafe manner, all vehicles can go out of control.
Because of the higher center of gravity, if this vehicle is
out of control it may roll over while some other vehicles
may not.
Do not attempt sharp turns, abrupt maneuvers, or other
unsafe driving actions that can cause loss of vehicle
control. Failure to operate this vehicle safely may result
in a collision, rollover of the vehicle, and severe or fatal
injury. Drive carefully.Failure to use the driver and passenger seat belts
provided is a major cause of severe or fatal injury. In
fact, the U.S. government notes that the universal use of
existing seat belts could cut the highway death toll by
10,000 or more each year and could reduce disabling
injuries by two million annually. In a rollover crash, an
unbelted person is significantly more likely to die than
a person wearing a seat belt. Always buckle up.
Rollover Warning Label
6 INTRODUCTION
