SnOW cHAInS
In wintry conditions, snow chains
improve  traction   as   well   as   the
behaviour

  of   the   vehicle   when   braking.
 The

  snow   chains   must   be   fitted
only

  to   the   driving   wheels.
They

must

  never   be   fitted   to   "space-
saver"
  type   spare   wheels.
 T

ake   account   of   the   legislation   in
force in your country on the use
of

  snow   chains   and   the   maximum
running

  speed   authorised.Advice on installation
F

If
  you   have   to   fit   the   chains   during
a

  journey,   stop   the   vehicle   on   a   flat
surface

  on   the   side   of   the   road.
F

Apply
  the   parking   brake   and
position

  any   wheel   chocks   to
prevent

  movement   of   your   vehicle.
F

Fit the chains following the
instructions provided by the
manufacturer

.
F

Move of
f gently and drive for a
few
  moments,   without   exceeding
30

  mph   (50   km/h).
F

Stop
  your   vehicle   and   check   that
the snow chains are correctly
tightened.It

  is   recommended   that   before   you
leave,

  you   practise   fitting   the   snow
chains

  on   a   level   and   dry   surface.
Use only the chains designed to be
fitted
  to   the   type   of   wheel   fitted   to   your
vehicle:
For

  more   information   on   snow   chains,
contact a CITR

o Ë n dealer or a
qualified
  workshop.
o
riginal
tyre size Maximum
  link
size.
195/65

  R159
  mm
195/70
  R15
205/65
  R15
215/55
  R16
215/50
  R17
avoid driving on roads that have
been cleared of snow

, to avoid
damaging
  your   vehicle's   tyres   and   the
road

  surface.   If   your   vehicle   is   fitted
with

  alloy   wheels,   check   that   no   part   of
the

  chain   or   its   fixings   is   in   contact   with
the

  wheel   rim.
Snow chains
QUICk HELP
8

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
168
cHAnGInG A BuLB
type A
All   glass   bulb:   pull   gently
as

  it   is   fitted   by   pressure.
High pressure washing
Open the bonnet. T o   access   the   bulbs,  reach
  behind   the   headlamp   unit.
Carry out the operations in reverse
order
  to   refit   each   bulb   and   check   that
the

  bonnet   is   closed   securely.type c
Halogen

  bulb:   release   the
retaining

  spring   from   its
housing.
type B
Bayonet
  bulb:   press
on the bulb then turn it
anticlockwise.
Halogen
  bulbs   must   be   changed  with
  the   headlamp   off.   Wait   a   few
minutes

  (risk   of   serious   burns).
d
o not touch the bulb directly with your
fingers,
  use   lint-free   cloths.
It
  is   normal   for   condensation   to   form
inside

  the   headlamps.   Regular   use   of
the

  vehicle   eliminates   this   misting.The
  bulbs   must   be   changed   with
the ignition of

f or with the battery
disconnected.   Wait   approximately
3 minutes

  after   changing   the   bulb
before

  reconnecting   the   battery.
Check   that   the   lamps   operate   correctly
after

  each   operation.
When using this type of washing
on stubborn dirt, do not persist on
the   headlamps,   the   lamps   and   their
edges

  to   avoid   damaging   their   coating
and

  seals.
types of bulb
Various types of bulb are fitted to your vehicle.
 T o   remove   them:
type

d
Light

  emitting   diode
(LED):

  for   replacement
of

  the   daytime   running
lamps,

  contact   a
CITR

o Ë n dealer or a
qualified
  workshop.
Changing a bulb

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
169
3. d irection indicators
type B

,   PY21W   -   21W   (amber)
-

Remove
  the   cover   by   pulling   the
flexible

  rubber   tab.
-

T
urn   the   bulb   holder   a   quarter
turn

  anticlockwise.
-

Remove
  the   bulb   by   pressing
it lightly while turning it
anticlockwise.
-


Change
  the   bulb.
-

Ensure
  that   the   cover   is   refitted
correctly all round to assure
correct

  sealing.
2.
Sidelamps


type A

, W5W - 5W
-

Remove


the

cover

by

pulling

the

flexible


rubber

tab.
-

Remove


the

bulb

holder

fitted

by

pressure


by


pullin

g

the


connector

.
-

Change


the

bulb.
-

Ensure


that

the

cover

is

refitted

correctly all round to assure
correct


sealing.
FrOnt LAMPS
1. d ipped / Main beam headlamps
type

c , H4 - 55W
-

Remove
  the   centre   cover   by
pullin

g   the   flexible   rubber   tab.
-
d isconnect the electrical
connector.
-

Release
  the   retaining   tab.
-

Change
  the   bulb   taking   care
to

  align   the   metal   part   with   the
grooves

  on   the   lamp.
-

Reposition
  the   retaining   tab.
-

Ensure
  that   the   cover   is   refitted
correctly all round to assure
correct

  sealing.
Changing a bulb
QUICk HELP
8

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
170
4. Foglamps type
c , H1 - 55W
-

Remove
  the   three   clips   and   the
screw securing the wheelarch liner

,
located
  below   the   bumper.
-

Move
  the   wheelarch   liner   upwards.
-

Remove
  the   foglamp   by   removing
the screw

, which can be accessed
via the hole provided for this
purpose
  in   the   bumper,   using   a
T

orx
© 30 screwdriver.
-
 Unclip   the   foglamp   by   squeezing
the


clip   to   release   it.
-

Remove the foglamp from the outside.- Turn the yellow cover a 1/4 turn to open.- Separate the clips which secure
the base of bulb on each side to
release   the   bulb.
-

Remove
  the   bulb   by   pulling,
keeping

  it   straight.
-

Insert the new bulb, reposition the
clips around the base of the bulb
and carry out the operations in
reverse

  order   to   put   the   lamp   unit
and

  the   bumper   back   in   position.
SIdE rEPEAtE r
type A,   WY5W   -   5W   (amber)
-
Push the repeater towards the rear
and disengage it by pullin

g the
front.
-

Contact a CITR
o Ë n dealer to
obtain a new repeater which is a
sealed
  component.
-

T
o   refit,   engage   the   repeater
towards the rear and bring it
towards

  the   front.
cOurtESY LAMPS
type A, 12V5W - 5W
-
Unclip the lens by sliding a
screwdriver in the slots on each
side

  of   the   courtesy   lamp.
-

Pull
  the   bulb   out   and   change   it.
-

Clip the lens in its housing and
ensure

  that   it   is   secured   correctly.
Front /
r ear
Changing a bulb

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
171
rEAr LAMPS
This procedure requires the use of the spanner supplied with the tools for
changing  a   wheel.
When
  refitting,   take   care   to
reposition the tabs and the supply
wire correctly to avoid trapping


the
  wire.
a

fter changing the rear direction
indicator
  bulb,   the   reinitialisation   time
is
  above   2   minutes.
-
Move aside the 4 tabs then extract
the
  bulb   holder.
-

Remove
  the   faulty   bulb   by
pressing it lightly while turning it
anticlockwise.
-


Change
  the   bulb.
When
  removing   the   lamp   unit:
-

with
  tailgate,   pull   the   lamp   unit
towards the centre of the vehicle,
-


with
  hinged   doors,   pull   the   lamp
unit

  towards   you.
For

more

information

concerning

the
 bulbs,

refer

to

the

"Types

of

bulb".
1.

Brake lamps / sidelamps


type B

,

P21/5W

-

21/5W
2.
d
irection indicators
type B

,

PY21W

-

21W

(amber)
3.
r
eversing lamps
type B

, P21W - 21W
4.

Foglamps


type B

, P21W - 21W
High pressure jet washing When using this type of washing
on stubborn dirt, do not persist on
the

headlamps,

the

other

lamps

and


their

edges

to

avoid

damaging

their


coating

and

seals. Chapter
  9,   "Changing   a   wheel"
section.
-


Identify the faulty bulb, then open
the

  rear   doors   to   180°.
Chapter
  3,   "Access"   section.
-

Remove
  the   two   fixing   bolts   using
the

  spanner   provided.
-

Pull
  the   lamp   unit   from   the   outside.
-

Holding
  the   lamp,   disconnect   the
electrical

  connector.
Changing a bulb
QUICk HELP
8

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
172
nuMBEr PLAtE LAMPS
- Unscrew  the   two   nuts.
-
Push
  the   pins.
-

If necessary
, disconnect the
connector
  to   remove   the   lamp.
-

Change
  the   bulb.
With tailgate
-
d
isengage the plastic lens using a
screwdriver.
-

Change


the

bulb.
-

Replace the plastic lens and press
on


it.
tHIrd BrAKE LAMP
type A ,   W16W   -   16W
With hinged doors
-

Unclip


the

interior

trim.
-
d
isconnect the connector by
moving

aside

its

tab.
-

T

urn

the

bulb

holder

a

quarter

turn

anticlockwise.
-


Change


the

bulb.
-

Put


the

bulb

holder

back

in

place

and


reconnect

the

connector.
-

Put


the

trim

back

in

place.type A
, W5W - 5W
Changing a bulb

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
173
cHAnGInG A FuSE
The fuseboxes are located:
-
in the lower dashboard on the left-
hand side (behind the cover),
-


under
  the   bonnet   (near   the   battery).
The
  information   given   concerns   only
those fuses which can be changed by
the user using the tweezer

, located
behind the dashboard storage
compartment
  on   the   right-hand   side.
For

  any   other   work,   visit   a   CITROËN
dealer

  or   a   qualified   workshop.
removing and fitting a fuse
Always replace a failed fuse with
a fuse of the same rating.
Motor

trade

technicians:

for

complete


information

on

the

fuses

and relays, refer to the "Repair
Manual"


diagrams

via

the

dealer
 network.
CITR
o
Ë
n
will not accept responsibility
for the cost incurred in repairing
your vehicle or for rectifying the
malfunctions

resulting

from

the

installation of accessories not
supplied


and

not

recommended

by

the

CITROËN


network

and

not

installed

in accordance with its instructions,
in


particular

when

the

combined

consumption


of

all

of

the

additional

equipment


connected

exceeds

10 millia

mperes. Before replacing a fuse, the cause of
the

incident

must

be

identified

and

rectified.
●


Use


the

tweezer.
Changing a fuse
QUICk HELP
8

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
174
dASHBOArd FuSES
Tilt the cover to gain access to the
fuses.Fuses
F Amperes  Aa
llocation
1 15 Rear wiper
2 - Spare
3 5
a

irbag
4 10 Air
  conditioning,   diagnostic   socket,   mirror   control,
headlamp

  beam
5 30 Electric windows
6 30Locks
7 5Rear
  courtesy   lamp,   front   map   reading   lamp,   roof
console
8 20 Audio

  equipment,   screen,   tyre   under-inflation
detection,

  alarm   and   siren
9 30Front
  and   rear   12V   socket
10 15 Central
  column
11 15 Low current ignition switch
12 15 Rain and sunshine sensor, airbag
13 5 Instrument
  panel
14 15 Parking
  sensors,   digital   air   conditioning   controls,
hands-free

  phone   kit
15 30 Locks
16 - Spare
17 40Rear
  screen/mirrors   demist/defrost
Changing a fuse
