2013 Peugeot 508 RXH Owner's Manual

4
135
Driving




Head-up display
a smoked strip in the field of vision of the driver so that they do not have to take their eyes off
th
e road.
1
.Head-up display on.
2. Head-up display off (long press).3.
Brightness adjustment. 4.
Display height adjustment.
Buttons
Once the system has been activated, thefollowing information is grouped together in the
head-up display:A.The speed of your vehicle. B. Cruise control/speed limiter information.


Displays during operation
C.
Navigation information (depending on
version) which appears in blue while in electric mode.
For more information on the navigation system, refer to the "Audio andtelematic" section.


This system operates when the hybrid system is active
and retains its settings on switching off the ignition.

136
Driving
)With the engine running, press button 1 toactivate the system and deploy the strip. )Press and hold button 2
to deactivate the
system and retract the strip.
The activated/deactivated state is saved and restored on restar ting the engine.
Activation / Deactivation
) With the engine running, adjust the
brightness of the information displayedusing buttons 3 :


- the "sun" to increase the brightness,

- the "moon" to decrease the brightness.





Brightness adjustment


We recommend that adjustments are made using these buttons only when the vehicle is stationary. When stationary or while driving, no objects
should be placed around the strip (or in itsrecess) so as to not impede deployment of the strip and its correct operation.


In certain extreme weather conditions (rain and/or snow, bright sunshine, ...) the head-up display may not be legibleor may suffer temporary interference. Some sunglasses may hamper readingof the information.
To clean the strip, use a clean, soft cloth (such as a spectacles cloth or microfibre cloth). Do not use a dry or abrasive cloth or detergent or solventproducts as these could scratch thestrip or damage the non-reflectivecoating.

Height adjustment
)With the engine running, adjust the display
to the desired height using buttons 4 :
- up to move the display up,
- down to move the display down.

4
137
Driving








Memorising speeds
This memorising of speeds applies to both the speed limiter and the cruise control.
You can memorise u
p to 5 speeds in the system.
By default, some speeds are already memorised.)Go to the main menu in the instrument
panel screen by pressing the "CONFIG"button.)Select the "Personalisation-configuration" menu and confirm.
To select a memorised speed:)press and hold the "+" or
" -" button; the system stopsat the nearest memorisedspeed,
For safety reasons, the driver mustcarry out these operations when stationary, using the instrument panel screen.These operations are only possible when stationary.


Operation
)
Select the "Vehicle parameters" menu andconfirm.)
Select the "Driving assistance" line and conform.)
Select the "Speeds memorised" line andconfirm.)
Modify the speed. )
Select " OK" and confirm to save the
modifications.

Selection
)
press and hold again the "+ " or " - " button toselect another memorised speed.
A reminder of the speed and the state of thesystem (on / off) is displayed in the instrument
panel.

138
Driving





Speed limiter
exceeding the speed programmed by the driver.
When the programmed speed limit is reached, pressing the accelerator pedal no longer has any effect unless it is pressed firmly,
which allows you to temporarily exceed theprogrammed speed.
To return to the programmed speed, simply
slow down to a speed below the programmed speed by releasing the accelerator.
The speed limiter is switched onmanuall
y:
it requires a programmed speed of at least
20 mph (30 km/h).
The speed limiter is
switched off by manual foperation of the control.
The pro
grammed speed remains in the memorywhen the ignition is switched off.

The speed limiter cannot, in any circumstances,replace the need to obser ve speed limits, nor can it replace the need for vigilance and responsibility on the par t of the driver.
This information also appears in the head-up display.
For more information, refer to the "Head-up display" section. 1.Speed limiter mode selection button
2. Programmed value decrease button3.
Programmed value increase button4.Suspend/restore speed limiter (pause)5.Speed limiter off button


Steering mounted controls

The programmed information is grouped
together in the instrument panel screen.

Displays in the instrument panel
A.Speed limiter on / pause indicationB.Speed limiter mode selection indicationC.Programmed speed value

4
139
Driving
) Press 1, the speed limiter mode is
activated but remains paused.
You do not have to switch the speed limiter
on in order to set the speed.
) Set the speed value by pressingbutton 2or 3(e.g.: 55 mph (90 km/h)).


Programming


Exceeding the programmed speed
Pressing the accelerator pedal to exceed the programmed speed will not have
any effect unless you press the pedal firmlypast the ypoint of resistance.e The speed limiter is deactivated temporarily and the programmed speed,
which is still displayed, flashes.
Returning to the programmed speed, by means of intentional or unintentional
deceleration of the vehicle, automatically cancels the flashing of the
programmed speed.

Off / Return to normal
driving
)
Press 5, the speed limiter is deactivated.


On a steep descent or in the event of sharp acceleration, the speed limiter willnot be able to prevent the vehicle from exceeding the programmed speed.
The use of mats not approved byPEUGEOT may adversely affect the normal operation of the accelerator pedal and impede the operation of the
speed limiter.
Mats approved by PEUGEOT have a third fixing in the area of the pedals to avoid any risk of interference with thepedals.
In the event o
f a speed limiter fault, the speed
is cleared resulting in flashing of the dashes.
Have it checked by a PEUGEOT dealer or a qualified workshop.


Operating fault

You can then change the programmed speed using buttons 2
and 3
:


- by + or - 1 mph (km/h) = shor t press,

- by + or - 5 mph (km/h) = long press,

- in steps of + or - 5 mph (km/h) = maintained press. )Switch the speed limiter on by pressing button 4 . )Suspend the speed limiter by pressing button 4: the screen confirms the suspension with "Pause".)Switch the speed limiter back on by pressing button 4
again.

140
Driving





Cruise control
speed of the vehicle at the value programmed
by the driver, without any action on the
accelerator pedal. The cruise control is switched on
manually: itrequires:
- a minimum vehicle speed of 25 mph(40 km/h),
- the engagement of 2nd gear or higher,
- position A
.
Cruise control is switched off
manually or by fpressing the brake pedal or on triggering of theESC system for safety reasons.
It is possible to exceed the programmed speed
temporarily by pressing the accelerator pedal.
To return to the pro
grammed speed, simply release the accelerator pedal.
Switching off the ignition cancels any programmed speed value. 1
.Cruise control mode selection button
2. Speed programming / programmed value decrease button 3.
Speed programming / programmed value
increase button 4.Cruise control suspension / resume button (pause)5.Cruise control off button


Steering mounted controls
The cruise control cannot, in any circumstances,replace the need to observe speed limits,
nor can it replace the need for vigilance and responsibility on the par t of the driver.
This information also appears in the head-up display.
For more information, refer to the "Head-up display" section. The pro
grammed information is grouped
together in the instrument panel screen.

Displays in the instrument panel
A.Cruise control on / pause indicationB.Cruise control mode selection indication
C.Programmed speed value

4
141
Driving
) Press 1, the cruise control is activated but remains paused.
)
Set the programmed speed by
accelerating to the required speed,
then press button 2or 3(e.g.: 70 mph (11 0 k m / h)).

Programming

You can then change the programmed speed using buttons 2
and 3
:


- by + or - 1 mph (km/h) = shor t press,

- by + or - 5 mph (km/h) = long press,

- in steps of + or - 5 mph (km/h) = maintained press. )Pause the cruise control by pressing button 4
: the screenconfirms the suspension with with "Pause".)Switch the cruise control back on by pressing button 4again.


Exceeding the programmed speed

Intentional or unintentional exceeding of the programmed speed results in flashing of this speed on the display.
Return to the programmed speed, by means of intentional or unintentional
deceleration of the vehicle, automatically cancels the flashing of the speed.
When the cruise control is switched on,be careful if you maintain the pressure on one of the programmed speedchanging buttons: this may result in avery rapid change in the speed of your vehicle.
Do not use the cruise control on slippery roads or in heavy traffic. On a steep descent, the cruise control will not be able to prevent the vehicle from exceeding the programmed speed.
To avoid any risk of jamming of the pedals:


- ensure that the mat is positioned correctly,

- never fit one mat on top of another.
In the event o
f a cruise control fault, the speed
is cleared resulting in flashing of the dashes.
Have it checked by a PEUGEOT dealer or a qualified workshop.


Operating fault

Off / Return to normal drivin
g
)Press 5 ; cruise control mode is deactivated The screen returns to
the distance recorder.

142
Driving
This system indicates the proximity of an
obstacle (person, vehicle, tree, gate, etc.) which comes within the field of detection of sensorslocated in the bumper.Certain types of obstacle (stake, roadworks cone, etc.) detected initially will no longer be detected at the end of the manoeuvre due to
the presence of blind spots.






Parking sensors


This function cannot, in any circumstances, take the place of the vigilance and responsibility of the driver.
The s
ystem is switched on by engaging reversegear. This is accompanied by an audible signal.
The system is switched off when you exit reverse gear.


Rear parking sensors


Audible assistance

The proximity information is given by an
intermittent audible signal, the frequency of which
increases as the vehicle approaches the obstacle.
The sound emitted b
y the speaker (right or left)
indicates the side on which the obstacle is located.
When the distance between the vehicle and
t
he obstacle becomes less than approximatelythirty centimetres, the audible signal becomes continuous.



Visual assistance
This supplements the audible signal bydisplaying bars in the multifunction screen
which move progressively nearer to the vehicle.
When the obstacle is near, the "Danger"symbol is displayed in the screen.
