PASSENGER COMPARTMENT
SDI2576
For all models
JVC\f\f23X
For Stop/Start (Idling Stop) System (if equipped)
CAUTION:
Never use a fuse of a higher or lower amperage
rating than that specified on the fuse box cover.
This could damage the electrical system or
cause a fire.
If \bny electric\bl equipment does not oper\bte, check for
\bn open fuse.1. Be sure the ignition switch is in the “OFF”
position.
2. Be sure the he\bdlight switch is in the “OFF” position.
3. Remove the fuse box cover
*1with \b suit\bble
tool.
4. Loc\bte the fuse th\bt needs to be repl\bced.
5. Remove the fuse using the fuse puller
*2.
SDI1754
6. If the fuse is open*A, repl\bce it with \b new fuse*B.
If the new fuse \blso opens, \bfter inst\blling, h\bve the
electric\bl system checked, \bnd if necess\bry rep\bired,
by \b RENAULT de\bler.
Extended stor\bge fuse switch (if equipped)
SDI27\f5
If \bny electric\bl equipment does not oper\bte, remove
the extended stor\bge fuse switch \bnd check for \bn
open fuse.
Maintenance and do-it-yourself8-27
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
8-28Maintenance and do-it-yourself
NOTE:
The extended storage fuse switch is used for
long term vehicle storage. If the extended
storage fuse switch is broken, it is not necessary
to replace it. Remove the fuse from the switch
then replace only the fuse to the fuse box.
How to remove the extended storage fuse
switch:
1. To remove the extended storage \fuse swit\bh, besure the ignition swit\bh is in the “OFF” or “LOCK”
position.
2. Be sure the headlight swit\bh is in the “OFF” position.
3. Remove the \fuse box \bover.
4. Pin\bh the storage \fuse swit\bh and pull it in the dire\btion o\f the arrow.HEADLIGHTS
Fog may temporarily \form inside the lens o\f the exterior
lights in the rain or in a \bar wash. A temperature
di\f\feren\be between the inside and the outside o\f the
lens \bauses the \fog. This is not a mal\fun\btion. I\f large
drops o\f water \bolle\bt inside the lens, \bonta\bt a
RENAULT dealer.
Repla\bing halogen headlight bulb
The halogen headlight is a semi-sealed beam type
whi\bh uses repla\beable headlight (halogen) bulbs.
They \ban be repla\bed \from inside the engine \bompart-
ment without removing the headlight assembly.
CAUTION:
.High-pressure halogen gas is sealed inside
the bulb. The bulb may break if the glass
envelope is scratched or the bulb is dropped.
JVM0109X
1. Dis\bonne\bt the battery negative \bable.
2. Dis\bonne\bt the ele\btri\bal \bonne\btor
*A\from the
rear end o\f the bulb.
3. Pull o\f\f the rubber \bap
*B.
4. Push and turn the retaining pin
*Cto loosen it.
5. Remove the headlight bulb. Do not shake or rotate the bulb when removing it.
6. Install the new bulb in the reverse order o\f removal.
LIGHTS
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
CAUTION:
.When handling the bulb, do not touch the
glass envelope.
. Use the same number and wattage as
originally installed:
Halogen headlight model
High beam bulb: 60W (H4)
Low beam bulb: 55W (H4)
. Do not leave the bulb out of the headlight
reflector for a long period of time as dust,
moisture and smoke may enter the headlight
body and affect the performance of the
headlight.
Aiming adjustment is not necessary if only the \ful\fs
are replaced. When aiming adjustment is necessary\b
contact a RENAULT dealer.
EXTERIOR LIGHTS
Item Wattage (W)
Front turn signal light 21
Front clearance light 5
Front fog light (if equipped) 55
Side turn signal light 5
Rear com\fination lights Turn signal light 21
Stop/Tail light 21/5
Reverse light 21
Rear fog light (if equipped) 21
High-mounted stop light LED* or 16
License plate light 5
INTERIOR LIGHTS
Item
Wattage (W)
Room light 5
Cargo light (if equipped) 5
*: See a RENAULT dealer for replacement.
Maintenance and do-it-yourself8-29
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
8-30Maintenance and do-it-yourself
LIGHT LOCATIONS
JVM0110X
1\f Inte\bio\b light
2\f F\bont fog light (if equipped)
3\f F\bont tu\bn signal light
4\f Clea\bance light
5\f Headlight
6\f Side tu\bn signal light
7\f Stop/tail light
8\f High-mounted stop light (Model with \bea\bspoile\b)
9\f High-mounted stop light (Model without \bea\b spoile\b)
10\f Rea\b tu\bn signal light
11\f Reve\bse light o\b Rea\b fog light (if equipped)*
12\f License plate light
*: Fo\b the Left-Hand D\bive (LHD) model\f On the Right-
Hand D\bive (RHD) model, the \bea\b fog light is located
on the opposite side\f
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
Replacement procedures
SDI18\f5
: RE\bOVE
: INSTALL
All other lights are either type A, B, C or D. When
replacing a bulb, first remove the lens and/or cover.
JV\b\f111XClearance light
JV\b\f\f\f4XFront turn signal lightJV\b\f1\f7XFront fog light (if equipped)
Maintenance and do-it-yourself8-31
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
8-32Maintenance and do-it-yourself
JVM0100XSide turn signal light
JVM0112XRear combination light
JVM0108XLicense plate light
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
JVM0008XHigh-mounted stop light (model with rear spoiler)
CAUTION:
Do not reuse the packing on the back of the
high-mounted stop light. When installing, the
packing must be replaced with a new one.
To replace the high-\founted \btop light bulb:
1. Re\fove the light with a \buitable tool.
2. Re\fove the bulb \bocket and then replace thebulb. 3. Replace the packing
*A.
4. In\btall in the rever\be order of re\foval.
SDI2391Room light
JVM0007XCargo light (if equipped)To replace the cargo light bulb:
1. Re\fove the light
*Awith a \buitable tool. 2. Re\fove the cover
*B.
3. Replace the bulb.
Maintenance and do-it-yourself8-33
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
8-34Maintenance and do-it-yourself
If you have a flat tire, see \fFlat tire” (\b.6-2) .
TIRE INFLATION \bRESSURE
\beriodically check the pressure of the tires, including
the spare. An incorrect tire pressure may adversely
affect tire life and vehicle handling. The tire pressure
should be checked when tires are COLD. Tires are
considered COLD after the vehicle has been parked
for 3 or more hours, or driven less than 1.6 km (1 mile) .
COLD tire pressures are shown on the tire placard.
(See \fVehicle identification” (\b.9-7) for the location of
the tire placard.)
Insufficient pressure can lead to an overheating of the
tire and subsequent internal damage. At high speeds,
this could result in tread separation and even bursting
of the tire.
TY\bES OF TIRES
CAUTION:
When changing or replacing tires, be sure all
four tires are of the same type (that is, summer,
all season or snow) and construction. A RE-
NAULT dealer may be able to help you with
information about tire type, size, speed rating
and availability.
Replacement tires may have a lower speed rating than
the factory equipped tires, and they may not match the
potential maximum vehicle speed. Never exceed the
maximum speed rating of the tire.
All season tires
RENAULT specifies all season tires on some models to
provide good performance all year, including snowy
and icy road conditions. All season tires are identified
by ALL SEASON and/or M&S on the tire sidewall.
Snow tires have better snow traction than all season
tires and may be more appropriate in some areas.
Summer tires
RENAULT specifies summer tires on some models to
provide superior performance on dry roads. Summer
tire performance is substantially reduced in snow and
ice. Summer tires do not have the tire traction rating
M&S on the tire sidewall.
If you plan to operate your vehicle in snowy or icy
conditions, RENAULT recommends the use of snow or
all season tires on all four wheels.
Snow tires
If snow tires are needed, it is necessary to select tires
equivalent in size and load rating to the original
equipment tires. If you do not, it can adversely affect
the safety and handling of your vehicle.
Generally, snow tires have lower speed ratings than
factory equipped tires and may not match the potential
maximum vehicle speed. Never exceed the maximum
speed rating of the tire. If you install snow tires, they
must be the same size, brand, construction and tread
pattern on all four wheels.
For additional traction on icy roads, studded tires may
be used. However, some states and provinces prohibit
their use. Check local, state and provincial laws before
installing studded tires. Skid and traction capabilities
of studded snow tires on wet or dry surfaces may be
poorer than that of non-studded snow tires.
TIRE CHAINS
Use of tire chains may be prohibited according to
location. Check the local laws before installing tire
chains. When installing tire chains, make sure that they
are of proper size for the tires on your vehicle and are
installed according to the chain manufacturer’s in-
structions.
Use chain tensioners when recommended by the tire
chain manufacturer to ensure a tight fit. Loose end links
of the tire chains must be secured or removed to
prevent the possibility of whipping action damage to
the fenders or underbody. If possible, avoid fully
loading your vehicle when using tire chains. In addition,
drive at a reduced speed. Otherwise, your vehicle may
be damaged and/or vehicle handling and performance
may be adversely affected.
Tire chains must be installed only on the front wheels
and not on the rear wheels. Never install tire chains on
a T-type spare tire (TEM\bORARY USE ONLY) . Do not
use the chains on dry roads.
TIRE ROTATION
SDI1662
RENAULT recommends that tires be rotated every
10,000 km (6,000 miles) . However, the timing for tire
rotation may vary according to your driving habits and
TIRES AND WHEELS
