2012 RENAULT PULSE Owners Manual


> (GLW    0RGHO .$2(0B5HQDXOW @
the road surface conditions. (See “Flat tire\f (P.6-\b) for
the tire replacement.)
WARNING:
.After rotating the tires, adjust the tire
pressure.
. Retighten the wheel nuts when the vehicle
has been driven for 1,000 km (600 miles)
(also in cases of a flat tire, etc.) .
. Incorrect tire selection, fitting, care or main-
tenance can affect vehicle safety with risk of
accident and injury. If in doubt, consult a
RENAULT dealer or the tire manufacturer.
TIRE WEAR AND DAMAGE
SDI1663
*1Wear indicator
*2Wear indicator location mark
Tires should be periodically inspected for wear,
cracking, bulging or objects caught in the tread. If
excessive wear, cracks, bulging or deep cuts are
found, the tire should be replaced immediately.
The original tires have a built-in tread wear indicator.
When the wear indicator is visible, the tire should be
replaced. Improper service of a spare tire may result in serious
personal injury. If it is necessary to repair the spare tire,
contact a RENAULT dealer.
TIRE AGE
Never use a tire over six years old, regardless of
whether it has been used or not.
Tires degrade with age as well as with the vehicle
usage. Have your tires checked and balanced often by
a repair shop or, if you prefer, a RENAULT dealer.
CHANGING TIRES AND WHEELS
WARNING:
Do not install a deformed wheel or tire even if it
has been repaired. Such wheels or tires could
have structural damage and could fail without
warning.
When replacing a tire, use the same size, speed rating
and load carrying capacity as originally equipped. (See
“Tires and wheels\f (P.9-6) for recommended types and
sizes of tires and wheels.) The use of tires other than
those recommended or the mixed use of tires of
different brands, construction (bias, bias-belted, or
radial) , or tread patterns can adversely affect the ride,
braking, handling, ground clearance, body-to-tire
clearance, snow chain clearance, speedometer cali-
bration, headlight aim and bumper height. Some of
these effects may lead to accidents and could result in
serious personal injury.
If the wheels are changed for any reason, always
replace with wheels which have the same offset
dimension. Wheels of a different offset could cause
early tire wear, possibly degraded vehicle handling
characteristics and/or interference with the brake
discs/drums. Such interference can lead to decreased
braking efficiency and/or early brake pad/shoe wear.
WHEEL BALANCE
Unbalanced wheels may affect vehicle handling and
tire life. Even with regular use, wheels can get out of
balance. Therefore, they should be balanced as
required.
SPARE TIRE
Conventional spare tire
A standard tire (the same size as the road wheels) is
supplied with your vehicle.
Temporary-use (T-type) spare tire (if
equipped)
SDI191\bSpare tire label (if equipped)Observe the following precautions if the T-type spare
tire must be used, otherwise your vehicle could be
damaged or involved in an accident.
CAUTION:
.
The T-type spare tire should be used only for
emergency. It should be replaced by the
standard tire at the first opportunity.
Maintenance and do-it-yourself8-35
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
8-36Maintenance and do-it-yourself
.Drive carefully while the T-type spare tire is
installed.
. Avoid sharp turns and abrupt braking while
driving.
. Periodically check the T-type spare tire
inflation pressure, and always keep it at
420 kPa (4.2 bar, 60 psi) .
. Do not drive your vehicle at speeds faster
than 80 km/h (50 MPH) .
. Do not use tire chains on a T-type spare tire.
Tire chains will not fit properly on the T-type
spare tire and may cause damage to the
vehicle.
. Tire tread of the T-type spare tire will wear at
a faster rate than the original tire. Replace
the T-type spare tire as soon as the tread
wear indicators appear.
. Because the T-type spare tire is smaller than
the original tire, ground clearance is re-
duced. To avoid damage to the vehicle do
not drive over obstacles. Also do not drive
the vehicle through an automatic car wash
since it may get caught.
. Do not use the T-type spare tire on other
vehicles.
. Do not use more than one T-type spare tire
at the same time.Emergency tire puncture repair kit (i\f
equipped)
\bhe emergency tire repair kit is supplied to the vehicle
instead o\f a spare tire. \bhe kit must be used \for
temporarily \fixing a minor tire puncture. A\fter using the
repair kit, see a RENAUL\b dealer as soon as possible
\for tire inspection and repair/replacement\(.
CAUTION:
Do not use the emergency tire repair kit under
the following conditions. Call a RENAULT dealer
or professional road assistance.
.when the sealant has passed its expiration
date
. when the cut or the puncture is approxi-
mately 6 mm (0.25 in) or longer
. when the side of the tire is damaged
. when the vehicle has been driven with a
considerable loss of air from the tire
. when the tire is completely displaced inside
or outside the rim
. when the tire rim is damaged
. when two or more tires are punctured
See “Flat tire” (P.6-2) \for more details.
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
MEMO
Maintenance and do-it-yourself8-37
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
8-38Maintenance and do-it-yourself
MEMO
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
9 Technical information
Recommended fuel/lubricants and capacities ................................. \f-2Fuel recommendation ....................................\.................................... \f-\b
Recommended SAE viscosity number ....................................\..... \f-\b
Air conditioner system refrigerant and lubricant ....................... \f-4
Engine ....................................\.............................................\.......................... \f-5
Tires and wheels ....................................\................................................... \f-6
Wheel alignment (for China) ....................................\............................. \f-6
Dimensions ....................................\.............................................\................. \f-7
When travelling or registering in another country ........................... \f-7
Vehicle identification ....................................\............................................ \f-7 Vehicle identification plate ....................................\........................... \f-7
Vehicle identification number (chassis number) ....................... \f-7
Vehicle identification number (VIN) plate (if equipped) .......... \f-8 Engine serial number ....................................\.................................. \f-8
Tire placard ....................................\................................................... \f-8
Air conditioner specification label (if equipped) ..................... \f-8
Radio approval number and information ....................................\........ \f-\f For Europe ....................................\........................................\............. \f-\f
For Croatia ....................................\........................................\............. \f-\f
For China ....................................\.................................................... \f-11
For Indonesia ....................................\........................................\...... \f-12
For Thailand ....................................\............................................... \f-12
For Morocco ....................................\.............................................. \f-1\b
For Jordan ....................................\................................................... \f-1\b
For South Africa ....................................\........................................ \f-1\b
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
9-2Technical information
The following are approximate \fapa\fities. The a\ftual refill \buantities may be slightly different. When refilling, follow the pro\fedures instru\fted in the “8. Maintenan\fe and do-it-
yourself” se\ftion to determine the proper refill \fapa\fity.
Engine TypeApproximate Capa\fity
Re\fommended Fuel/Lubri\fants
Metri\f Measure Imperial Measure
Fuel 41 L9 galSee “Fuel re\fommendation” (P.9-3) .
Engine oil (*1)
HR12DE
HR15DE in\fluding oil filter
3.0 L
3.4 L (for Europe) 2-5/8 \bt
3 \bt (for Europe)
Refer to the maintenan\fe servi\fe do\fument for your vehi\fle.
ex\fluding oil filter
2.8 L
3.2 L (for Europe) 2-1/2 \bt
2-7/8 \bt (for Europe)
HR12DDR in\fluding oil filter
3.9 L 3-3/8 \bt
ex\fluding oil filter 3.7 L 3-1/4 \bt
K9K in\fluding oil filter
4.4 L 3-7/8 \bt
ex\fluding oil filter 4.2 L 3-3/4 \bt
Cooling system (in\fluding reservoir tank \fapa\fity 0.7 L)
Only use fluids approved by our te\fhni\fal department.
HR12DDR
MT model
5.4 L4-3/4 \bt
CVT model 5.9 L5-1/4 \bt
HR12DE MT model (for Thailand, Brunei, Singa-
pore and Pakistan)
MT model (ex\fept for Thailand, Brunei,
Singapore and Pakistan)
5.7 L
5.5 L
5 \bt
4-7/8 \bt
AT model 5.5 L4-7/8 \bt
CVT model (for Thailand)
CVT model (ex\fept for Thailand) 5.8 L
5.6 L5-1/8 \bt
4-7/8 \bt
HR15DE MT model
5.6 L4-7/8 \bt
AT model 6.0 L5-1/4 \bt
Cooling system (in\fluding reservoir tank \fapa\fity 1.0 L) K9K MT model 7.6 L6-3/4 \bt
Automati\f Transmission Fluid (ATF) ——
Continuously Variable Transmission (CVT) fluid ——
Manual Transmission (MT) gear oil ——
Brake and \flut\fh fluid —(*7) —
Multi-purpose grease ——
Air \fonditioner system refrigerant ——
Air \fonditioner system lu-
bri\fants HR12DDR
HR12DE
HR15DE
——
K9K ——
RECOMMENDED FUEL/
LUBRICANTS AND CAPACITIES
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
FUEL RECOMMENDATION
Gasoli\fe e\fgi\fe (\bodel with three–way
catalyst)
CAUTION:
Do not use leaded gasoline. Using leaded gaso-
line will damage the three-way catalyst.
Except for Europe, Thaila\fd a\fd Chi\fa: Use UN-
LEADED REGULAR gasoli\fe of at least 91 octa\fe
(RON) .
For Europe: Use UNLEADED PREMIUM gasoli\fe of at
least 95 octa\fe (RON) .
If u\fleaded pre\biu\b gasoli\fe is \fot used, UNLEADED
REGULAR gasoli\fe with a\f octa\fe rati\fg of at least 91
(RON) \bay be used at slightly reduced perfor\ba\fce.
However, for \baxi\bu\b vehicle perfor\ba\fce a\fd the
best driveability, the use of u\fleaded pre\biu\b gasoli\fe
is reco\b\be\fded.
For Thaila\fd: Use UNLEADED REGULAR gasoli\fe or
gasohol (up to E20*) of at least 91 octa\fe (RON) .
*: Gasohol is alcohol ble\fded gasoli\fe. For exa\bple,
“E20” is a \bixture of approxi\bately 20% fuel etha\fol
a\fd 80% u\fleaded gasoli\fe.
For Chi\fa: Use UNLEADED REGULAR gasoli\fe of at
least 93 octa\fe (RON) .
Your vehicle co\bplies with GB18352.3-2005. Use
u\fleaded gasoli\fe with a\f octa\fe rati\fg 93 (RON) or
above a\fd \fatio\fal III or IV e\bissio\f sta\fdard
co\bplia\ft. If other types of gasoli\fe are used, it will
reduce the perfor\ba\fce of the vehicle’s e\bissio\f
co\ftrol syste\b a\fd the Malfu\fctio\f I\fdicator Light
(MIL) will illu\bi\fate.
Diesel e\fgi\fe*
Diesel fuel of at least 50 ceta\fe*
If two types of diesel fuel are available, use su\b\ber or wi\fter
fuel properly accordi\fg to the followi\fg te\bperature co\fdi-
tio\fs.
. Above í78C (208F) ... Su\b\ber type diesel fuel.
. Below í78C (208F) ... Wi\fter type diesel fuel.
CAUTION:
.Do not use home heating oil, gasoline or
other alternate fuels in your diesel engine.
The use of those or adding those to diesel
fuel can cause engine damage.
. Do not use summer fuel at temperatures
below í78C (208F) . The cold temperatures
will cause wax to form in the fuel. As a
result, it may prevent the engine from
running smoothly.
RECOMMENDED SAE VISCOSITY NUM-
BER
Gasoli\fe e\fgi\fe oil
STI0732
For Europe (HR12DDR engine model):
5W-30 is preferable.
If 5W-30 is not available, select the viscosity,
from the chart, that is suitable for the outside
temperature range.
Technical information9-3
&RQGLWLRQ


> (GLW    0RGHO .$2(0B5HQDXOW @
9-4Technical information
For Europe (HR12DE engine model) and Thai-
land:
0W-20 is preferable.
If 0W-20 is not available, select the viscosity,
from the chart, that is suitable for the outside
temperature range.
Except for Europe and Thailand:
10W-30 is preferable.
If 10W-30 is not available, select the viscosity,
from the chart, that is suitable for the outside
temperature range.Diesel engine oil
JVT0029X
5W-30 is preferable.
If 5W-30 is not available, select the viscosity,
from the chart, that is suitable for the outside
temperature range.
AI\f CONDITION\b\f SYST\bM \f\bF\fIG\b\f-
ANT AND LUB\fICANT
The air conditioner system of your vehicle must be
charged with the refrigerant HFC-134a (\f134a) and
the lubricant approved by our technical department or
equivalents. Use of any other refrigerants or lubricants
will cause severe damage, and you may need to
replace your vehicle’s entire air conditioner system.
The release of refrigerants into the atmosphere is
prohibited in many countries and regions. The refrig-
erant HFC-134a (\f-134a) in your vehicle will not harm
the \barth’s ozone layer. However, it may contribute in a
small part to the global warming effect. \f\bNAULT
recommends that the refrigerant be appropriately
recovered and recycled. Contact a \f\bNAULT dealer
when servicing the air conditioner system.
&RQGLWLRQ
