2012 Lancia Flavia Owner handbook (in English)

178

7
MAINTAINING YOUR VEHICLE
 ENGINE COMPARTMENT — 2.4L . . . . . . . . . . . 181
 ONBOARD DIAGNOSTIC SYSTEM — OBD II . . . 182
 REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . 182
 MAINTENANCE PROCEDURES . . . . . . . . . . . . . 182  ENGINE OIL . . . . . . . . . . . . . . . . . . . . . . . . . 183
 ENGINE OIL FILTER . . . . . . . . . . . . . . . . . . . 184
 ENGINE AIR CLEANER FILTER . . . . . . . . . . 184
 MAINTENANCE-FREE BATTERY . . . . . . . . . 185
 AIR CONDITIONER MAINTENANCE . . . . . . . 186
 A/C AIR FILTER . . . . . . . . . . . . . . . . . . . . . . 186
 BODY LUBRICATION . . . . . . . . . . . . . . . . . . . 187
 WINDSHIELD WIPER BLADES . . . . . . . . . . . 188
 ADDING WASHER FLUID . . . . . . . . . . . . . . . 188
 EXHAUST SYSTEM . . . . . . . . . . . . . . . . . . . . 189
 COOLING SYSTEM . . . . . . . . . . . . . . . . . . . . 190
 BRAKE SYSTEM . . . . . . . . . . . . . . . . . . . . . . 193
 AUTOMATIC TRANSMISSION . . . . . . . . . . . . 194
 APPEARANCE CARE AND PROTECTIONFROM CORROSION . . . . . . . . . . . . . . . . . . . . 196
 CLEANING CENTER CONSOLE CUPHOLDERS . . . . . . . . . . . . . . . . . . . . . . . . 198
179

 CONVERTIBLE TOP CARE . . . . . . . . . . . . . . 198
 WEATHER STRIP CARE – SOFT AND HARDTOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
 FUSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200  INTEGRATED POWER MODULE . . . . . . . . . . 200
 VEHICLE STORAGE . . . . . . . . . . . . . . . . . . . . . 203
 REPLACEMENT BULBS . . . . . . . . . . . . . . . . . . 203
 BULB REPLACEMENT . . . . . . . . . . . . . . . . . . . 203  HEADLAMP . . . . . . . . . . . . . . . . . . . . . . . . . . 203
 FRONT TURN SIGNAL . . . . . . . . . . . . . . . . . . 204
 FRONT FOG LAMP . . . . . . . . . . . . . . . . . . . . 204
 REAR TURN SIGNAL LAMPS . . . . . . . . . . . . 205
 BACKUP LAMP . . . . . . . . . . . . . . . . . . . . . . . 205
 LICENSE PLATE LAMP . . . . . . . . . . . . . . . . . 205
 FLUID CAPACITIES . . . . . . . . . . . . . . . . . . . . . . 206
 FLUIDS, LUBRICANTS, AND GENUINE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
 ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
 CHASSIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
180

ENGINE COMPARTMENT — 2.4L1 — Engine Coolant Reservoir6 — Air Cleaner Filter
2 — Power Steering Fluid Reservoir 7 — Engine Oil Fill
3 — Brake Fluid Reservoir 8 — Coolant Pressure Cap
4 — Power Distribution Center (Fuses) 9 — Engine Oil Dipstick
5 — Integrated Power Module (Fuses) 10 — Washer Fluid Reservoir
181

ONBOARD DIAGNOSTIC
SYSTEM — OBD II
Your vehicle is equipped with a so-
phisticated onboard diagnostic sys-
tem called OBD II. This system moni-
tors the performance of the emissions,
engine, and automatic transmission
control systems. When these systems
are operating properly, your vehicle
will provide excellent performance
and fuel economy, as well as engine
emissions well within current govern-
ment regulations.
If any of these systems require service,
the OBD II system will turn on the
“Malfunction Indicator Light.” It will
also store diagnostic codes and other
information to assist your service
technician in making repairs. Al-
though your vehicle will usually be
drivable and not need towing, see
your dealer for service as soon as pos-
sible.
CAUTION!
 Prolonged driving with the “Mal-function Indicator Light” on
could cause further damage to the
emission control system. It could
also affect fuel economy and
driveability. The vehicle must be
serviced before any emissions
tests can be performed.
 If the “Malfunction Indicator
Light” is flashing while the engine
is running, severe catalytic con-
verter damage and power loss will
soon occur. Immediate service is
required.
REPLACEMENT PARTS
Use of genuine parts for normal/
scheduled maintenance and repairs is
highly recommended to ensure the de-
signed performance.
Damage or failures caused by the use
of parts which are not quality-
equivalent to genuine parts for main-
tenance and repairs will not be cov-
ered by the manufacturer’s warranty. MAINTENANCE
PROCEDURES
The pages that follow contain the
re-
quired maintenance services deter-
mined by the engineers who designed
your vehicle.
Besides those maintenance items
specified in the fixed maintenance
schedule, there are other components
which may require servicing or re-
placement in the future.
CAUTION!
 Failure to properly maintain your vehicle or perform repairs and
service when necessary could re-
sult in more costly repairs, dam-
age to other components or nega-
tively impact vehicle
performance. Immediately have
potential malfunctions examined
by an authorized dealership or
qualified repair center.
(Continued)
182

CAUTION!(Continued)
 Car maintenance should be done
at a LANCIA Dealership. For rou-
tine and minor maintenance op-
erations you wish to carry out
yourself, we do recommend you
have the proper equipment, genu-
ine LANCIA spare parts and the
necessary fluids; do not however
carry out these operations if you
have no experience.
 Your vehicle has been built with
improved fluids that protect the
performance and durability of
your vehicle and also allow ex-
tended maintenance intervals. Do
not use chemical flushes in these
components as the chemicals can
damage your engine, transmis-
sion, power steering or air condi-
tioning. Such damage is not cov-
ered by the New Vehicle Limited
Warranty. If a flush is needed be-
cause of component malfunction,
use only the specified fluid for the
flushing procedure. ENGINE OIL
Checking Oil Level
To assure proper engine lubrication of
your
vehicle's engine, the engine oil
must be maintained at the correct
level. The best time to check the en-
gine oil level is about five minutes
after a fully warmed engine is shut off.
Do not check oil level before starting
the engine after it has sat overnight.
Checking engine oil level when the
engine is cold will give you an incor-
rect reading.
Checking the oil while the vehicle is
on level ground and only when the
engine is hot, will improve the accu-
racy of the oil level readings. Maintain
the oil level between the range mark-
ings on the dipstick. Either the range
markings consist of a crosshatch zone
marked SAFE or a crosshatch zone
marked with MIN at the low end of
the range and MAX at the high end of
the range. Adding 1.0 Liter of oil
when the reading is at the low end of
the range marking will raise the oil
level to the high end of the range
marking.
CAUTION!
 Do not overfill the engine. Over- filling the engine will cause oil
aeration, which can lead to loss of
oil pressure and an increase in oil
temperature. This could damage
your engine. Also, be sure the oil
fill cap is replaced and tightened
after adding oil.
 Car maintenance should be done
at a LANCIA Dealership. For rou-
tine and minor maintenance op-
erations you wish to carry out
yourself, we do recommend you
have the proper equipment, genu-
ine LANCIA spare parts and the
necessary fluids; do not however
carry out these operations if you
have no experience.
Change Engine Oil
Refer to the “Maintenance Schedule”
for the proper maintenance intervals.
Engine Oil Selection
SAE Grade 5W-20 SELENIA K
POWER fully synthetic engine oil that
meets FIAT Qualification 9.55535
API SN, ILSAC GF-5 or equivalent.
183

The engine oil filler cap also shows the
recommended engine oil viscosity for
your vehicle. For information on en-
gine oil filler cap location, refer to
“Engine Compartment” in “Main-
taining Your Vehicle” for further in-
formation.
Synthetic Engine Oils
You may use synthetic engine oils pro-
vided the recommended oil quality
requirements are met, and the recom-
mended maintenance intervals for oil
and filter changes are followed.
Materials Added To Engine Oil
Do not add any supplemental materi-
als, other than leak detection dyes, to
the engine oil. Engine oil is an engi-
neered product and its performance
may be impaired by supplemental ad-
ditives.
Disposing Of Used Engine Oil And
Oil Filters
Care should be taken in disposing of
used engine oil and oil filters from
your vehicle. Used oil and oil filters,
indiscriminately discarded, can pres-
ent a problem to the environment.
Contact your authorized dealer, ser-vice station, or governmental agency
for advice on how and where used oil
and oil filters can be safely discarded
in your area.
ENGINE OIL FILTER
The engine oil filter should be re-
placed with a new filter at every en-
gine oil change.
Engine Oil Filter Selection
The manufactur
er's engines have a
full-flow type disposable oil filter. Use
a filter of this type for replacement.
The quality of replacement filters var-
ies considerably. Only high-quality
filters should be used to assure most
efficient service. LANCIA engine oil
filters are high-quality oil filters and
are recommended.
ENGINE AIR CLEANER
FILTER
Refer to the “Maintenance Schedule”
for the proper maintenance intervals.
WARNING!
The air induction system (air
cleaner, hoses, etc.) can provide a
measure of protection in the case of
engine backfire. Do not remove the
air induction system (air cleaner,
hoses, etc.) unless such removal is
necessary for repair or maintenance.
Make sure that no one is near the
engine compartment before starting
the vehicle with the air induction
system (air cleaner, hoses, etc.) re-
moved. Failure to do so can result in
serious personal injury.
Engine Air Cleaner Filter
Selection
The quality of replacement engine air
cleaner filters varies considerably.
Only high quality filters should be
used to assure most efficient service.
LANCIA engine air cleaner filters are
a high quality filter and are recom-
mended.
184

MAINTENANCE-FREE
BATTERY
The top of the maintenance-free bat-
tery is permanently sealed. You will
never have to add water, nor is peri-
odic maintenance required.
NOTE:
The battery is stored in a compart-
ment behind the left front fender
and is accessible without remov-
ing the tire and wheel. Remote bat-
tery terminals are located in the
engine compartment for jump-
starting. Refer to “Jump-Starting
Procedures” in “What To Do In
Emergencies” for further informa-
tion.
To access the battery, turn the steering
wheel fully to the right and remove
the inner fender shield.
WARNING!
 Battery fluid is a corrosive acidsolution and can burn or even
blind you. Do not allow battery
fluid to contact your eyes, skin, or
clothing. Do not lean over a bat-
tery when attaching clamps. If
acid splashes in eyes or on skin,
flush the area immediately with
large amounts of water.
 Battery gas is flammable and ex-
plosive. Keep flame or sparks
away from the battery. Do not use
a booster battery or any other
booster source with an output
greater than 12 Volts. Do not al-
low cable clamps to touch each
other.
 Battery posts, terminals, and re-
lated accessories contain lead and
lead compounds. Wash hands af-
ter handling.
CAUTION!
 It is essential when replacing thecables on the battery that the
positive cable is attached to the
positive post and the negative
cable is attached to the negative
post. Battery posts are marked
positive (+) and negative (-) and
are identified on the battery case.
Cable clamps should be tight on
the terminal posts and free of cor-
rosion.
 If a “fast charger” is used while
the battery is in the vehicle, dis-
connect both vehicle battery
cables before connecting the char-
ger to the battery. Do not use a
“fast charger” to provide starting
voltage.
185
