2011 RENAULT SCENIC Engine And Peripherals EDC16C36 Workshop Manual

13B-241V9 MR-372-J84-13B450$131.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET415
CONTINUED 1
STATUS 7
Inconsistency between the request and the vehicle speed.
STATUS 8Automatic transmission in defect mode.
STATUS 9Vehicle speed monitoring.
STATUS 10Monitoring by the injection computer.
Sensor electrical conformity
Note:
Cruise control can be activated when the vehicle speed exceeds 18 mph (30 km/h).
Status ET415 displays the various reasons for deactivation of the cruise control/speed limiter function, due to a
driver request or the external environment (e.g. STATUS 1).
IMPORTANT
Clear the fault memory by running command RZ001 Fault memory to reset this status to NONE.
WITHOUT
This status is present on the diagnostic tool if:
the computer has been reinitialised,
the computer has been reprogrammed.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-242V9 MR-372-J84-13B450$131.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET415
CONTINUED 2
STATUS 1
Traction control request
If the vehicle is fitted with a traction control system, the cruise control function is
deactivated every time the ABS computer calls for traction control.
Status ET415 becomes STATUS 1 when driving with the cruise control active
(ET042 Cruise control/Speed limiter: CRUISE CONTROL) and traction control is
requested.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If status ET415 becomes STATUS 1 with no traction control request (see 38C, Anti-
lock Braking System).
STATUS 2Brake pedal depressed
The cruise control function is deactivated when the brake pedal is depressed.
Status ET415 becomes STATUS 2, when driving, with cruise control active (ET042
Cruise control/Speed limiter: CRUISE CONTROL) and the brake pedal depressed.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If status ET415 becomes STATUS 2 without pressing the brake pedal, consult the
interpretation of statuses ET704 and ET705 Brake switch No. 1 and No. 2.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-243V9 MR-372-J84-13B450$131.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET415
CONTINUED 3
STATUS 3
Clutch pedal depressed
Manual gearbox ONLY
The cruise control function is deactivated when the gearbox is no longer coupled to
the engine (clutch pedal depressed).
Status ET415 becomes STATUS 3 when driving with cruise control active
(ET042 Cruise control/speed limiter: CRUISE CONTROL) and the clutch pedal is
depressed.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If status ET415 becomes STATUS 3 without the clutch pedal being depressed,
consult the interpretation of status ET405 Clutch pedal switch.
If the vehicle is fitted with an automatic transmission:
Test the multiplex network: check the configuration of the multiplex network in relation
to the vehicle's technical specification, especially the configuration of the automatic
transmission computer (see 88B, Multiplexing).
STATUS 4Cancel button pressed
The cruise control/speed limiter function is deactivated whenever the suspend button
is pressed.
Status ET415 becomes STATUS 4, when driving when:
– Either the cruise control is active, or
– the speed limiter is active
– and when the "0" button is pressed by the driver.
This action deactivates the Cruise control/Speed limiter.
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If status ET415 becomes STATUS 4 without pressing the 0 button, consult the
interpretation of status ET703 Cruise control/speed limiter buttons and run fault-
finding on the R/0 control button located on the steering wheel, to the right.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-244V9 MR-372-J84-13B450$131.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET415
CONTINUED 4
STATUS 5
Cruise control or speed limiter monitoring
This status appears when the vehicle brakes or decelerates sharply without the
injection computer receiving a signal that the brake pedal switch has been pressed.
If status ET415 is STATUS 5, consult the interpretation of statuses:
– ET042 Cruise control/speed limiter
– ET703 Cruise control/speed limiter buttons
– ET704 Brake switch No. 1
– ET705 Brake switch No. 2
to test the cruise control/speed limiter system components and find the defective
component.
Also, check the operation of the accelerator pedal, and use the diagnostic tool to
check the presence of a fault connected with this component. Deal with them if
necessary.
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If status ET415 changes to STATUS 5, deal with faults present or stored in the
injection computer.
If the fault is still present, contact the Techline.
STATUS 6Gear lever in neutral (manual gearbox) or the neutral position (automatic
gearbox)
Status ET415 becomes STATUS 6, when driving with cruise control active
(ET042: Cruise control/speed limiter: CRUISE CONTROL) and:
– if the driver puts the gear lever in neutral position on a manual gearbox without
declutching or,
– if the gear lever is put in neutral on an automatic transmission.
This deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If status ET415 becomes STATUS 6 without shifting the gear lever into neutral on a
manual gearbox without declutching, or into the neutral position on an automatic
transmission, test the ABS computer and check the configuration of the tyre size
stored in the computer.
If the configuration is correct, contact the Techline.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-245V9 MR-372-J84-13B450$132.mif
13B
ET415
CONTINUED 5
STATUS 7
Inconsistency between the request and the vehicle speed
Status ET415 changes to STATUS 7 if the computer detects too great a difference
between the speed requested by the driver and the vehicle speed.
This could occur when driving with cruise control active (ET042 Cruise control/
speed limiter: CRUISE CONTROL) and when there is a significant difference.
This inconsistency deactivates cruise control.
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If status ET415 changes to STATUS 7 when on flat or even terrain, contact the
Techline.
STATUS 8Automatic transmission in defect mode.
Status ET415 becomes STATUS 8 when driving with cruise control active (ET042:
Cruise control/speed limiter: CRUISE CONTROL) and if the automatic
transmission is in defect mode.
This signal is conveyed on the multiplex line and deactivates the cruise control.
Carry out a multiplex network test, then run fault finding on the automatic transmission
computer.
Deal with any present or stored faults (see 23A, Automatic transmission).
Clear the automatic transmission computer memory by running command RZ001
Fault memory.
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If STATUS 8 is still present, contact the Techline.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
DIESEL INJECTION
Fault finding – Interpretation of statuses
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-246V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET415
CONTINUED 6
STATUS 9
Vehicle speed monitoring
Status ET415 becomes STATUS 9 if the vehicle speed received by the computer is
invalid or absent.
This signal is conveyed on the multiplex line and deactivates the cruise control.
Carry out a multiplex network test, then run fault finding on the ABS computer.
Deal with any present or stored faults (see 38C, ABS, interpretation of faults).
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If STATUS 9 is still present, contact the Techline.
STATUS 10Monitoring by the injection computer.
Status ET415 becomes STATUS 10 when driving with cruise control active (ET042
Cruise control/speed limiter: CRUISE CONTROL) if the injection computer detects
a fault anywhere in the engine management system, or an engine speed that is too
high or too low.
This signal is conveyed on the multiplex line and deactivates the cruise control.
Carry out a multiplex network test, then run fault finding on the injection computer.
Deal with any present or stored faults (see 13B, Diesel injection, interpretation of
faults).
Reinitialise status ET415 on the injection computer by running command RZ001
Fault memory.
If STATUS 10 is still present, contact the Techline.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-247V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET651EGR PROGRAMMING CUT-OFF
NOTESNone.
NONENo EGR cut-off, the EGR valve is working properly in accordance with the
computer programs.
STATUS 1, 5, 6, 7,
9, 10, 12, 13, 15,
19, 23, 24Switch off the engine and wait for the diagnostic tool message (maximum time
8minutes): Communication lost with computer: EDC16C36, check the tool
connection and computer power supply.
Switch the ignition on and check for faults.
Check the battery voltage with the engine switched off and the engine running.
If no faults are present or stored, restart the vehicle and test at idle speed.
Do not accelerate too much and reach an engine speed that is too high.
STATUS 3, 14, 16Accelerate above idle speed for a few seconds.
STATUS 2Check that the clutch pedal status (ET405 Clutch pedal switch) is not ACTIVE, and
that the vehicle has stopped completely.
EDC16C36_V44_ET651/EDC16C36_V4C_ET651/EDC16C36_V48_ET651/EDC16C36_V50_ET651/EDC16C36_V54_ET651/
EDC16C36_V58_ET651
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-248V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET651
CONTINUED
STATUS 4, 17
Check for present and stored faults, and repair.
STATUS 8Reset the EGR offsets by referring to the interpretation of command SC036
"Reinitialise the programming" and select "EGR valve".
STATUS 11, 22Allow the engine to heat up until this cut-off disappears.
STATUS 18Check that the regeneration of the particle filter in progress has completely finished.
STATUS 20Allow the engine to cool until this cut-off disappears.
STATUS 21Too low atmospheric pressure, the EGR valve is disabled.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58
