DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET703CRUISE CONTROL/SPEED LIMITER BUTTONS
STATUS DEFINITIONRESUME: R button pressed.
SUSPEND: 0 button pressed.
INCREASE: Increase button pressed.
DECREASE: Decrease button pressed.
INACTIVE: This status indicates that no button has been pressed.
NOTESSpecial notes:
Only perform these tests if the statuses do not correspond with the system
programming functions.
Use the Mégane II ph2, Scénic II ph2 Technical Note wiring diagram.
Conformity check with engine stopped and ignition on, or engine running, and engine coolant
temperature > 80°C
INACTIVEWhen that no button has been pressed.
In the event of a fault, consult the interpretation of status ET703.
SUSPEND'0' button pressed.
In the event of a fault, consult the interpretation of status ET703.
RESUMER button pressed.
In the event of a fault, consult the interpretation of status ET703.
EDC16C36_V44_ET703/EDC16C36_V4C_ET703/EDC16C36_V48_ET703/EDC16C36_V50_ET703/EDC16C36_V54_ET703/
EDC16C36_V58_ET703
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-250V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET703
CONTINUED 1
DECREASE
Decrease button pressed.
In the event of a fault, consult the interpretation of status ET703.
INCREASEIncrease button pressed.
In the event of a fault, consult the interpretation of status ET703.
Sensor electrical conformity
INACTIVEStatus ET703 becomes INACTIVE when none of the cruise control/speed limiter
buttons are pressed. These buttons are located on the steering wheel.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's frontal airbag (see MR 364 Mégane,
MR370 Scénic, Mechanical, 88C, Airbag and pretensioners, Driver's front
airbag, Removal - Refitting).
If status ET703 does not display INACTIVE,
– check the status of the cruise control/speed limiter +/- button and the condition of its
connector.
– check the status of the cruise control/speed limiter R/0 button and the condition of
its connector.
Repair if necessary.
INCREASEStatus ET703 becomes INCREASE when the + button of the cruise control/speed
limiter is pressed. This button is on the steering wheel, on the left-hand side.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's frontal airbag (see MR 364 Mégane,
MR370 Scénic, Mechanical, 88C, Airbag and pretensioners, Driver's front
airbag, Removal - Refitting)
If status ET703 does not display INCREASE, check the status of the +/- button of the
cruise control/speed limiter and the status of its connector. Repair if necessary.
Measure the resistance on the following connections while pressing the +
button (on the button tracks):
– Connection code 86G of component 331.
– Connection code 86M of component 331.
If the resistance is not approximately 300 Ω, check the continuity of the connection
when the button is not pressed.
If there is continuity, replace the +/- control button.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-251V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET703
CONTINUED 2
DECREASE
Status ET703 becomes DECREASE when the - button of the cruise control/speed
limiter is pressed. This button is on the steering wheel, on the left-hand side.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's frontal airbag (see MR 364 Mégane,
MR370 Scénic, Mechanical systems, 88C, Airbag and pretensioners, Driver's
front airbag, Removal - Refitting).
If status ET703 does not display DECREASE, check the status of the +/- button of the
cruise control/speed limiter and the status of its connector. Repair if necessary.
If there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair) repair the wiring, otherwise replace it.
Measure the resistance of the following connection whilst pressing the - button
(on the button tracks):
– Connection code 86G of component 331.
– Connection code 86M of component 331.
If the resistance is not approximately 100 Ω check the continuity of the connection
when the button is not pressed.
If there is continuity, replace the +/- control button.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-252V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET703
CONTINUED 3
SUSPEND
Status ET703 becomes SUSPEND when the 0 button of the cruise control/speed
limiter is pressed. This button is located on the steering wheel, to the right.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's frontal airbag (see MR 364 Mégane,
MR370 Scénic, Mechanical systems, 88C, Airbag and pretensioners, Driver's
front airbag, Removal - Refitting).
If status ET703 does not change to SUSPEND, check the status of the cruise control/
speed limiter R/0 button, and the status of its connector.
If there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair) repair the wiring, otherwise replace it.
Measure the resistance of the following connection whilst pressing the 0 button
(on the button tracks):
– Connection code 86G of component 331.
– Connection code 86M of component 331.
If the resistance is not approximately 0 Ω, replace the R/0 control button.
If there is continuity, replace the R/0 control button.
RESUMEStatus ET703 becomes RESUME when the R button of the cruise control/speed
limiter is pressed. This button is located on the steering wheel, to the right.
To carry out these checks and measurements in complete safety, observe the
recommendations for removing the driver's frontal airbag (see MR 364 Mégane,
MR370 Scénic, Mechanical systems, 88C, Airbag and pretensioners, Driver's
front airbag, Removal - Refitting).
If status ET703 does not change to RESUME, check the status of the cruise control/
speed limiter R/0 button, and the status of its connector. Repair if necessary.
If there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair) repair the wiring, otherwise replace it.
Measure the resistance on the following connection while pressing the R button
(on the button tracks):
– Connection code 86G of component 331.
– Connection code 86M of component 331.
If the resistance is not approximately 900 Ω check the continuity of the connection
when the button is not pressed.
If there is continuity, replace the R/0 control button.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-253V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET704
ET705BRAKE SWITCH NO. 1BRAKE SWITCH NO. 2
STATUS DEFINITIONACTIVE: This status indicates that the brake pedal is depressed.
INACTIVE: This status indicates that the brake pedal is released.
NOTESSpecial notes:
Only perform these tests if the statuses do not correspond with the system
programming functions.
Note:
Statuses ET704 and ET705 should change status at the same time. If they are
inconsistent, consult the interpretation of fault DF228 Brake signal.
Use the Mégane II ph2, Scénic II ph2 Technical Note wiring diagram.
Conformity check with engine stopped and ignition on, or engine running, and engine coolant
temperature > 80°C
ACTIVEBrake pedal depressed.
A brake signal non-conformity may cause the engine to race during gear changes.
In the event of a fault, apply the interpretation of statuses ET704 Brake contact no. 1
and ET705 Brake contact no. 2.
INACTIVEBrake pedal released.
A brake signal non-conformity may cause the engine to race during gear changes.
In the event of a fault, apply the interpretation of statuses ET704 Brake contact no.1
and ET705 Brake contact no. 2.
EDC16C36_V44_ET704/EDC16C36_V4C_ET704/EDC16C36_V48_ET704/EDC16C36_V50_ET704/EDC16C36_V54_ET704/
EDC16C36_V58_ET704/EDC16C36_V44_ET705/EDC16C36_V4C_ET705/EDC16C36_V48_ET705/EDC16C36_V50_ET705/
EDC16C36_V54_ET705/EDC16C36_V58_ET705
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-254V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET704
ET705
CONTINUED
Sensor electrical conformity
ACTIVE
or
INACTIVEIf the brake lights are working:
check the continuity and the absence of interference resistance on the following
connection:
– Connection code 5A between components 160 and 120/645/119.
If there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair) repair the wiring, otherwise replace it.
If the brake lights are not operational, check:
– the condition and fitting of the brake switch,
– the status and conformity of the fuse for the brake lights.
– the conformity of the values in the following table:
Disconnect the switch and carry out the following checks:
for MEGANE II and SCENIC II with ESP
Continuity between
connectionsInsulation between
connections
Switch engaged
(Brake pedal released)5A and BPT 65G and SP17
Switch released
(Brake pedal
depressed)65G and SP17 5A and BPT
Replace the switch if the values obtained are not correct.
For MEGANE II and SCENIC II without ESP
Continuity between
connectionsInsulation between
connections
Switch engaged
(Brake pedal released)5A and BPT 65A and SP17
Switch released
(Brake pedal
depressed)65A and SP17 5A and BPT
Replace the switch if the values obtained are not correct.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-255V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET706
ET707
ET708
ET709
ET710
ET711
ET712
ET713
ET714
ET715STORED ENGINE STATUS NO. 1
STORED ENGINE STATUS NO. 2
STORED ENGINE STATUS NO. 3
STORED ENGINE STATUS NO. 4
STORED ENGINE STATUS NO. 5
STORED ENGINE STATUS NO. 6
STORED ENGINE STATUS NO. 7
STORED ENGINE STATUS NO. 8
STORED ENGINE STATUS NO. 9
STORED ENGINE STATUS NO. 10
STATUS DEFINITIONThese statuses indicate the engine status in the event of a regeneration failure when
driving.
NOTESSpecial notes:
For Vdiag 48:
Interpret these parameters only if DF312 Speed request is present or stored.
Conformity check with engine stopped and ignition on, or engine running, and engine coolant
temperature > 80°C
This status indicates the engine status in the event of a regeneration failure when driving:
NONE, + AFTER IGNITION, RUNNING, STOPPED.
Each STATUS between ET706 and ET715 corresponds to the engine status during a regeneration failure for which
the mileage is saved by PR794 Stored regeneration failure No. 1 to PR803 Stored regeneration failure No. 10
(for example, PR797 Stored regeneration failure No. 4 is related to ET709 Stored engine status No. 4).
EDC16C36_V48_ET706/EDC16C36_V48_ET707/EDC16C36_V48_ET708/EDC16C36_V48_ET709/EDC16C36_V48_ET710/
EDC16C36_V48_ET711/EDC16C36_V48_ET712/EDC16C36_V48_ET713/EDC16C36_V48_ET714/EDC16C36_V48_ET715/
EDC16C36_V50_ET706/EDC16C36_V50_ET707/EDC16C36_V50_ET708/EDC16C36_V50_ET709/EDC16C36_V50_ET710/
EDC16C36_V50_ET711/EDC16C36_V50_ET712/EDC16C36_V50_ET713/EDC16C36_V50_ET714/EDC16C36_V50_ET715/
EDC16C36_V58_ET706/EDC16C36_V58_ET707/EDC16C36_V58_ET708/EDC16C36_V58_ET709/EDC16C36_V58_ET710/
EDC16C36_V58_ET711/EDC16C36_V58_ET712/EDC16C36_V58_ET713/EDC16C36_V58_ET714/EDC16C36_V58_ET715
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-256V9 MR-372-J84-13B450$132.mif
DIESEL INJECTION
Fault finding – Interpretation of statuses13B
ET706
ET707
ET708
ET709
ET710
ET711
ET712
ET713
ET714
ET715
CONTINUED
RUNNING
If the STATUS is RUNNING, the regeneration failed because:
– the customer's driving did not generate enough heat,
– an engine management system component is defective.
STOPPED
If the STATUS is STOPPED, regeneration has failed due to engine cut-off.
+ AFTER
IGNITION FEEDPOWER LATCH
NONENo failed regeneration is present.
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58
