2010 Peugeot 3008 Dag Owner's Manual

64
Heated seats control
With the engine running, the front seats
can be heated separately.

 Use the adjustment dial, placed on
the side of each front seat, to switch
on and select the level of heating re-
quired:

0
: Off.

1
: Low.

2
: Medium.

3
: High.
Head restraint height and angle
adjustment

 To raise the head restraint, pull it for-
wards and upwards at the same time.

 To remove the head restraint, press
the lug A and pull the head restraint
upwards.

 To put the head restraint back in
place, engage the head restraint
stems in the openings keeping them
in line with the seat back.

 To lower the head restraint, press
the lug A and the head restraint at
the same time.

 To adjust the angle of the head re-
straint, tilt its lower part forwards or
rearwards. The head restraint is fi tted with
a frame with notches which
prevents it from lowering; this
is a safety device in case of
impact.

The adjustment is correct when the upper edge of the head restraint is
level with the top of the head.
Never drive with the head restraints
removed; they must be in place and
adjusted correctly.
Lumbar adjustment

 Turn the dial to obtain the correct
lumbar position.

65
Folding the seat back

 Check that no object, either on or
underneath the seat, could hinder
its movement.

 To make the operation easier, place
the head restraint in the low position
or remove it (if the seat is in the fully
forward position).

 Lift the control, located behind the
seat, then guide the seat back for-
wards. When the seat back is in this position,
the seat behind it and the centre rear
seat must not be occupied.
This position, associated with that of the
rear seats, allows you to transport long
objects inside the vehicle.
The maximum weight on the seat is
30 kg.
Table position, front passenger seat
Returning the seat to the normal
position

 Lift the control, located behind the
seat, then guide the seat back rear-
wards until it locks.

66
Folding the seat from the boot
Each section of the bench seat (1/3 or
2/3) has its own control to release the
seat back and its seat cushion from the
boot.

 Check that nothing is preventing
the seat back from folding (head re-
straint, seat belts, ...),

 check also that no object on or un-
der the seat could hinder its move-
ment,

 pull the control from the boot.
REAR SEATS
Never drive with rear passen-
gers when the head restraints
are removed; the head re-
straints must be in place and in the
high position.
Rear head restraints
These have a high position (comfort
and safety) and a low position (rear vis-
ibility).
They can also be removed.
To remove a head restraint:

 pull the head restraint fully upwards,

 then, press the lug A .
Bench seat the left-hand (2/3) or right-
hand (1/3) section of which can be fold-
ed to adapt the boot load space.

67
The seat cushion lowers to be
covered by the seat back; this
leaves a fl at boot fl oor, if the
movable fl oor is in the intermediate
position.
Folding the seat from the rear
Check that no object, either on or un-
derneath the seat, could hinder its
movement.

 Move the corresponding front seat
forwards if necessary,

 check that the seat belt is positioned
correctly on the side of the seat
back,

 place the head restraints in the low
position or remove them if neces-
sary,

 pull the control 1 forwards to release
the seat back 2 which tilts easily
onto the seat cushion 3 .
Returning the seat back to its original position

 Put the seat back in the upright posi-
tion and secure it, the seat cushion
also returns to its original position,

 check that the red indicator, located
at the control 1 , is no longer visible,

 refi t the head restraints or put them
back in place.
When returning the rear seat back to
its original position, take care not to
trap the seat belts and ensure that their
buckles are positioned correctly.

68
The objects observed are, in
reality, closer than they ap-
pear.
Take this into account in order to cor-
rectly judge the distance of vehicles
approaching from behind.
MIRRORS
Door mirrors
Each fi tted with an adjustable mirror
glass permitting the lateral rearward vi-
sion necessary for overtaking or park-
ing. They can also be folded for parking
in confi ned spaces. Folding
- Automatic: lock the vehicle using
the remote control or the key.
- Manual: with the ignition on, pull control A rearwards.
The folding and unfolding of
the door mirrors using the
remote control can be deacti-
vated by a PEUGEOT dealer.
Fold the mirrors when putting your
vehicle through an automatic car
wash.
Adjustment
Unfolding
- Automatic: unlock the vehicle using the remote control or the key.
- Manual: with the ignition on, pull control A rearwards.
If the mirrors are folded using
control
A , they will not unfold
when the vehicle is unlocked.
Pull again on control A .

 Move control A to the right or to
the left to select the corresponding
mirror.

 Move control B in all four directions
to adjust.

 Return control A to the central
position.
Demisting - Defrosting
If your vehicle is fi tted with heated mir-
rors, the demisting-defrosting operates
with the engine running, by switching
on the heated rear screen (refer to the
"Rear screen demist-defrost" page).

69
Adjustment

 Adjust the mirror so that the glass
is directed correctly in the "day"
position.
As a safety precaution, the
mirrors must be adjusted to
reduce the "blind spot".
Manual day/night model
Day/night position

 Pull the lever to change to the "night"
anti-dazzle position.

 Push the lever to change to the nor-
mal "day" position.
Rear view mirror
Adjustable mirror providing a central
rearward view.
Equipped with an anti-dazzle system,
useful in poor light. In order to guarantee opti-
mum visibility during your ma-
noeuvres, the mirror lightens
automatically when reverse gear is
engaged.

Automatic day/night model
By means of a sensor, which measures
the light from the rear of the vehicle, this
system automatically and progressively
changes between the day and night
uses.
It has an anti-dazzle system which dark-
ens the mirror glass: this reduces any
driver discomfort caused by the light
beam of following vehicles, the sun...

70
STEERING WHEEL ADJUSTMENT

 When stationary , pull the control
lever to release the steering wheel.

 Adjust the height and reach to suit
your driving position.

 Push the control lever to lock the
steering wheel.
As a safety precaution, these
operations should only be car-
ried out while the vehicle is
stationary.

71
Unfolding the key
Unlocking the vehicle

 Press the open padlock to
unlock the vehicle.
Complete unlocking using the
remote control
REMOTE CONTROL KEY
System which permits central unlock-
ing or locking of the vehicle using the
lock or from a distance. It is also used to
locate and start the vehicle, as well as
providing protection against theft. Complete unlocking using the key

 Turn the key to the left in the driver's
door lock to unlock the vehicle.
Unlocking is confi rmed by rapid fl ashing
of the direction indicators for approxi-
mately two seconds.
According to version, the door mirrors
unfold at the same time.
Selective unlocking using the
remote control
Selective unlocking using the key

 Turn the key to the left in the driver's
door lock once to unlock the driver's
door only.

 Turn the key to the left in the driver's
door lock again to unlock the other
doors and the boot.
 Press the open padlock
once to unlock the driver's
door only.

 Press the open padlock again to un-
lock the other doors and the boot. Each unlocking is confi rmed by rapid
fl ashing of the direction indicators for
approximately two seconds.
According to version, the door mirrors
unfold at the same time as the fi rst
unlocking action.
The selective unlocking is only available
on versions fi tted with deadlocking.
The complete or selective
unlocking parameter is set
via the multifunction screen
confi guration menu.
Complete unlocking is activated by de-
fault.

 First press this button to
unfold the key.
