2008 TOYOTA FJ CRUISER Owners Manual

90
1−7. Safety information
Child restraint systems
Points to remember
Studies have shown that installing a child restraint on a rear seat is
much safer than installing one to the front passenger seat.

Choose a child restraint system appropriate to the age and size of
the child.
 For installation details, follow the instructions provided with the
child restraint system.
General installation instructions are provided in this manual.
(
P. 93)
Types of child restraints
Child restraint systems are clas sified into the following 3 types
according to the age and size of the child.
Infant seat
A child restraint system for a small child or baby must itself be prop
erly restrained on the seat with
the lap portion of the lap/shoulder
belt.
The laws of all 50 states of the U.S.A. and Canada now require the
use of child restraint systems.

91
1−7. Safety information
1
Before driving
Convertible seat
Booster seat
 When the child restraint system is not in use
Leave the child restraint system properly secured on the seat. Do not store
the restraint loosely on a passenger seat or in the luggage compartment.
 Selecting an appropriate child restraint system
Get an appropriate child restraint system for the child. If a child is too large
for a child restraint system, sit the child on a rear seat and use the vehicle’s
seat belt. (
P. 51)
CAUTION
 Child restraint precautions
 For effective protection in automobile accidents and sudden stops, a child
must be properly restrained, using a seat belt or child restraint system
depending on the age and size of the child. Holding a child in your arms is
not a substitute for a child restraint system. In an accident, the child can be
crushed against the windshield, or between you and the vehicle’s interior.

92 1−7. Safety information
CAUTION
 Child restraint precautions
 Toyota strongly urges the use of a proper child restraint system that con−
forms to the size of the child, installed on the rear seat. According to acci−
dent statistics, the child is safer when properly restrained in the rear seat
than in the front seat.
 Never install a rear−facing child restraint system on the front passenger
seat even if AIR BAG OFF indicator light is illuminated. In the event of an
accident, the force of the rapid inflation of the front passenger airbag can
cause death or serious injury to the child if the rear−facing child restraint
system is installed on the front passenger seat.
 A forward−facing child restraint system should allowed to be installed on
the front passenger seat only when it is unavoidable. Always move the
seat as far back as possible even if AIR BAG OFF indicator light is illumi−
nated, because the front passenger airbag could inflate with considerable
speed and force. Otherwise, the child may be killed or seriously injured.
 Do not use the seat belt extender when installing a child restraint system
on the front or rear passenger seat. If installing a child restraint system
with the seat belt extender connected to the seat belt, the seat belt will not
securely hold the child restraint system, which could cause death or seri−
ous injury to the child or other passengers in the event of collision.
 Do not allow the child to lean his/her head or any part of his/her body
against the door or the area of the sea t, front and rear pillars or roof side
rail from which the side airbags or curtain shield airbags deploy even if the
child is seated in the child restraint system. It is dangerous if the side air−
bags and curtain shield airbags inflate, and the impact could cause death
or serious injury to the child.
 Make sure you have complied with all installation instructions provided by
the child restraint manufacturer and that the system is properly secured. If
it is not secured properly, it may cause death or serious injury to the child
in the event of a sudden stop or accident.

93
1
1−7. Safety information
Before driving
Installing child restraints
Follow the child restraint system manufacturer’s instructions. Firmly
secure child restraints to the outside rear seats using a seat belt or a
child restraint lower anch
or belt. Attach the top strap when installing
a child restraint.
Seat belts equipped with a
child restraint locking mecha−
nism (ALR/ELR belts except
driver ’s seat belt) ( P. 51)
Child restraint lower anchor−
ages
Lower anchorages are pro−
vided for the outside rear
seats. (Buttons displaying the
location of the anchorages are
attached to the seats.)
Anchor bracket (for top strap)
Anchor brackets are provided
for all rear seats.

94 1−7. Safety information
Installing child restraints using a seat belt (child restraint lock function belt)
 Rear facing child seat
Infant seat/convertible seat
Place the child seat on the rear
seat facing the rear of the vehi−
cle.
Run the seat belt through the
child seat and insert the plate
into the buckle. Make sure that
the belt is not twisted.
Fully extend the shoulder belt
and then allow it to retract
slightly in order to activate the
ALR lock mode.
Lock mode allows the seat belt to
retract only.

95
1−7. Safety information
1
Before driving
While pushing the child seat
down into the rear seat, allow the
shoulder belt to retract until the
child seat is securely in place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
 Forward facing
Convertible seat
Place the child seat on the seat
facing the front of the vehicle.
Run the seat belt through the
child seat and insert the plate
into the buckle. Make sure that
the belt is not twisted.
Fully extend the shoulder belt
and then allow it to retract
slightly into the ALR lock mode.
Lock mode allows the seat belt to
retract only.

96 1−7. Safety information
While pushing the child seat into
the rear seat, allow the shoulder
belt to retract until the child seat
is securely in place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended
 Booster seat
Place the booster seat on the
seat facing the front of the vehi−
cle.
Sit the child in the booster seat.
Fit the seat belt to the booster
seat according to the manufac−
turer’s instructions and insert the
plate into the buckle. Make sure
that the belt is not twisted.
Check that the shoulder belt is
correctly positioned over the
child’s shoulder, and that the lap
belt is as low as possible.
(
P. 51)

97
1−7. Safety information
1
Before driving
Removing a child restraint installed with a seat belt
Push the buckle release button
and fully retract the seat belt.
Installation with child restraint lower anchorages
Type A
Widen the gap between
the seat cushion and
seatback slightly.
Latch the hooks of the
lower straps onto the
anchorages and tighten
the lower straps.
If the child restraint has a
top strap, the top strap
should be latched onto the
anchorages.
For owners in Canada:
The symbol on a child restraint
system indicates the presence of
a lower connector system.Canada
only
