2008 TOYOTA FJ CRUISER Owners Manual

367
6−1. Specifications
6
Vehicle specifications
Differential
Automatic transmission
*: The fluid capacity is the quantity of reference. If replacement is necessary,
contact your Toyota dealer.
Oil capacityFront
(4WD models)
Vehicles with a manual transmission
1.5 qt. (1.4 L, 1.2 Imp.qt.)
Vehicles with an automatic transmission
1.7 qt. (1.6 L, 1.4 Imp.qt.)
Rear
Vehicles with a rear differential lock
3.1 qt. (2.9 L, 2.6 Imp.qt.)
Vehicles without a rear differential lock
3.2 qt. (3.0 L, 2.6 Imp.qt.)
Oil type and
viscosityFront
(4WD models)Hypoid gear oil API GL−5
Vehicles with an automatic transmission
SAE75W−85
Vehicles with a manual transmission
Above 0
F (−18C): SAE90
Below 0
F (−18
C): SAE80W or 80W−90
RearHypoid gear oil API GL−5
Above 0 F (−18C): SAE90
Below 0
F (−18
C): SAE80W or 80W−90
Fluid capacity
*11.3 qt. (10.7 L, 9.4 Imp.qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
 Automatic transmission fluid type
Using automatic transmission fluid other than “Toyota Genuine ATF WS”
may cause deterioration in shift quality, locking up of your transmission
accompanied by vibration, and ultimately damage the automatic
transmission of your vehicle.

368 6−1. Specifications
Manual transmission
Clutch
Transfer (4WD models)
Gear oil capacity (Reference) 1.9 qt. (1.8 L, 1.6 Imp.qt.)
Gear oil type Gear oil API GL−4 or GL−5
Recommended gear oil viscosity SAE 75W−90
Clutch free play 0.2 0.6 in. (5
15 mm)
Fluid type FMVSS No. 116 DOT 3 or SAE J1703
Oil capacity
Vehicles with an automatic transmission
1.1 qt. (1.0 L, 0.9 Imp.qt.)
Vehicles with a manual transmission
1.5 qt. (1.4 L, 1.2 Imp.qt.)
Oil type
Vehicles with an automatic transmission
Hypoid gear oil API GL−4 or GL−5
Vehicles with a manual transmission
Hypoid gear oil API GL−5
Recommended oil viscosity SAE 75W−90

369
6−1. Specifications
6
Vehicle specifications
Brakes
*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N,
50 kgf) with the engine running.
*2: Parking brake lever travel when pulled with a force of 44.1 lbf (196 N, 20.0
kgf).
Chassis lubrication
Steering
Pedal clearance*12.1 in. (54 mm) Min.
Pedal free play 0.04 0.24 in. (1
6 mm)
Brake pad wear limit
0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake lever travel
*25 — 7 clicks
Fluid type FMVSS No. 116 DOT 3 or SAE J1703
Propeller shafts Spider
Slide yokeLithium base chassis grease, NLGI No.2
Molybdenum — disulfide lithium base
chassis grease, NLGI No.2 or lithium
base multipurpose grease, NLGI No.2
Free play
Less than 1.2 in. (30 mm)
Power steering fluid typeAutomatic transmission fluid DEXRON
®II or
III

370 6−1. Specifications
Tires and wheels
Tire size P265/75R16 114T, P265/70R17 113S
Tire inflation pressure
(Recommended cold tire
inflation pressure)Front tires:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Rear tires:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Spare tire:
32 psi (220 kPa, 2.2 kgf/cm
2 or bar)
Wheel size 16 7 J, 17
7 1/2 J
Wheel nut torque 85 ft⋅lbf (113 N⋅m, 11.5 kgf⋅m)

371
6−1. Specifications
6
Vehicle specifications
Light bulbs
A: HB2 halogen bulbs
B: Single end bulbs
C: Wedge base bulbs (clear)
D: Wedge base bulbs (amber)
E: Double end bulbs
Light BulbsBulb No.WTy p e
ExteriorHeadlights — 60/55 A
Front turn signal/
parking and front side
marker lights— 21/5 B
Outside rear view
mirror illumination
lights—5 C
Rear turn signal lights 5674 21 D
Stop/tail and rear side
marker lights7443 21/5 C
Back−up lights 921 18 C
License plate lights — 5 C
Interior
Front interior light 8 E
Rear interior light 8 E

372
6−1. Specifications
Fuel infor mation
 Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your Toyota has a fuel tank opening that
only accommodates the special nozzle on unleaded fuel pumps.
 If premium gasoline is not available
If 91 rating gasoline cannot be obtained, you may use unleaded gasoline
with an octane rating as low as 87 (Research Octane Number 91).
 If your engine knocks
 Consult your Toyota dealer.
You may occasionally notice light knocking for a short time while
accelerating or driving uphill. This is normal and there is no need for
concern.
 Gasoline quality
In very few cases, driveability problems may be caused by the brand of
gasoline you are using. If driveability problems persist, try changing the
brand of gasoline. If this does not correct the problem, consult your Toyota
dealer.
 Gasoline quality standards
 Automotive manufacturers in the US, Europe and Japan have developed
a specification for fuel quality called World−Wide Fuel Charter (WWFC)
that is expected to be applied worldwide.
 The WWFC consists of four categories that are based on required
emission levels. In the US, category 4 has been adopted.
The WWFC improves air quality by lowering emissions in vehicle fleets,
and customer satisfaction through better performance. Your vehicle must use only unleaded gasoline.
Premium unleaded gasoline with an
octane rating of 91 (Research
Octane Number 96) or higher required for optimum engine
performance.
At minimum, the gasoline you us e should meet th e specifications
of ASTM D4814 in the U.S.A. and CGSB3.5−M93 in Canada.

373
6−1. Specifications
6
Vehicle specifications
 Toyota recommends the use of gasoline containing detergent additives
 Toyota recommends the use of gasoline that contains detergent additives
to avoid build−up of engine deposits.
All gasoline sold in the US contains detergent additives to clean and/or
keep clean intake systems.
 Toyota recommends the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains
oxygenates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is
available in many areas.
Toyota recommends the use of cleaner burning gasoline and appropriately
blended reformulated gasoline. These types of gasoline provide excellent
vehicle performance, reduce vehicle emissions and improve air quality.
 Toyota does not recommend blended gasoline
 Toyota allows the use of oxygenate blended gasoline where the
oxygenate content is up to 10% ethanol or 15% MTBE.
If you use gasohol in your Toyota, be sure that it has an octane rating no
lower than 91.
 Toyota does not recommend the use of gasoline containing methanol.
Toyota does not recommend gasoline containing MMT
Some gasoline contains octane enhancing additive called MMT
(Methylcyclopentadienyl Manganese Tricarbonyl).
Toyota does not recommend the use of gasoline that contains MMT. If fuel
containing MMT is used, your emission control system may be adversely
affected.
The malfunction indicator lamp on the instrument cluster may come on. If
this happens, contact your Toyota dealer for service.

374 6−1. Specifications
NOTICE
 Notice on gasoline quality
 Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s three−way catalytic
converters causing the emission control system to malfunction.
 Do not use gasohol other than that stated here.
Other gasohol may cause fuel system damage or vehicle performance
problems.
 Use of unleaded gasoline with an octane rating lower than 91 may result in
engine knocking. Persistent knocking can lead to engine damage and
should be corrected by refueling with higher octane unleaded gasoline.
 Fuelrelated poor driveability
If after using a different type of fuel, poor driveability is encountered (poor
hot starting, vaporization, engine knocking, etc.), discontinue the use of that
type of fuel.
 When refueling with gasohol
Take care not to spill gasohol.
It can damage your vehicle’s paint.
