2008 TOYOTA FJ CRUISER load capacity

159
2−4. Using other driving systems
2
When driving
CAUTION
 The ABS does not operate effectively when
 The limits of the gripping performance have been exceeded.
The vehicle hydroplanes while driving at high speed on the wet or slick
road.
 Stopping distance when the ABS is
operating will exceed that of nor
mal conditions
The ABS is not designed to shorten the vehicle’s stopping distance. Always
maintain a safe distance from the vehicle in front of you in the following situ−
ations.
 When driving on dirt, gravel or snow−covered roads
When driving with tire chains
When driving over bumps in the road
When driving over roads with potholes or roads with uneven roads
When VSC is activated
The slip indicator flashes and a warning buzzer sounds. Always drive care−
fully. Reckless driving may cause an accident. Exercise particular care when
the indicator flashes and a buzzer sounds.
 TRAC may not operate effectively when
Directional control and power may not be achievable while driving on slip−
pery road surfaces, even if TRAC is operating.
Do not drive the vehicle in conditions where stability and power may be lost.
 Replacing tires
Make sure that all tires are of the same size, brand, tread pattern and total
load capacity. In addition, make sure that the tires are inflated to the appro−
priate tire pressure level.
The ABS and VSC will not function correctly if different tires are fitted on the
vehicle.
Contact your Toyota dealer for further information when replacing tires or
wheels.
 Handling of tires and suspension
Using tires with any kind of problem or modifying the suspension will affect
the driving assist systems, and may cause the system to malfunction.

165
2−5. Driving information
2
When driving
Cargo and luggage
Capacity and distribution
Cargo capacity depends on the total weight of the occupants.
(Cargo capacity) = (Total load capacity)
(Total weight of occupants)
Steps for Determining Correct Load Limit—
(1) Locate the statement “The co
mbined weight of occupants and
cargo should never exceed XXX kg or XXX lbs.” on your vehicle’s
placard.
(2) Determine the combined weight of the driver and passengers that
will be riding in your vehicle.
(3)Subtract the combined weight of the driver and passengers from
XXX kg or XXX lbs.
(4) The resulting figure equals the av
ailable amount of cargo and lug−
gage load capacity.
For example, if the “XXX” amount
equals 1400 lbs. and there will
be five 150 lb passengers in your vehicle, the amount of available
cargo and luggage load capacity is 650 lbs. (1400
750 (5 150)
= 650 lbs.)
(5) Determine the combined weight of luggage and cargo being
loaded on the vehicle. That weight may not safely exceed the
available cargo and luggage load
capacity calculated in Step 4.
Take notice of the following information about storage precau
tions, cargo capacity and load.
 Stow cargo and luggage in the luggage compartment whenever
possible.
Be sure all items are secured in place.

Be careful to keep the vehicle level. Placing the weight as far for−
ward as possible helps maintain vehicle balance.
 For better fuel economy, do not carry unnecessary weight.

166 2−5. Driving information
(6) If your vehicle will be towing a trailer, load from your trailer will be
transferred to your vehicle. Consult this manual to determine how
this reduces the available cargo
and luggage load capacity of your
vehicle.
Example on your vehicle
Cargo capacity
Total load capacity
When 2 people with the combined weight of 366 lb. (166 kg) are
riding in your vehicle, which has a
total load capacity of 1190 lb. (540
kg), the available amount of cargo and luggage load capacity will be
as follows:
1190 lb. 366 lb. = 824 lb. (540 kg 166 kg = 374 kg)
In this condition, if 3 more pa ssengers with the combined weight of
388 lb. (176 kg) get on, the available cargo and luggage load will be
reduced as follows:
824 lb. 388 lb. = 436 lb. (374 kg 176 kg = 198 kg)
As shown in the above example, if the number of occupants
increases, the cargo and luggage load equaling the combined weight
of the occupants who got on later,
by an amount. In other words, if an
increase in the number of occupants causes an excess of the total
load capacity (combined weight of occupants plus cargo and luggage
load), you must reduce the ca
rgo and luggage on your vehicle.

167
2−5. Driving information
2
When driving
CAUTION
Things that must not be carried in the luggage compartment
The following things may cause a fire if loaded in the luggage compart−
ment.
Receptacles containing gasoline
Aerosol cans
Storage precautions
Do not stack anything in the luggage compartment higher than the
seatbacks.
Such items may be thrown about and possibly injure people in the
vehicle during sudden braking or in an accident.
Do not drive with objects on top of the instrument panel.
They may interfere with the driver ’s field of view or move during sharp
acceleration or turning, thus impairing the driver ’s control of the vehi−
cle. In an accident they may injure the vehicle occupants.
Secure all items in the occupant compartment, as they may shift and
injure someone during an accident or sudden braking.
Never allow anyone to ride in the luggage compartment. It is not
designed for passengers. They should ride in their seats with their seat
belts properly fastened. Otherwise,
they are much more likely to suffer
death or serious bodily injury, in the event of sudden braking or a colli−
sion.
Capacity and distribution
Do not exceed the maximum axle weight rating or the total vehicle
weight rating.
Even if the total load of occupant’s weight and the cargo load is less
than the total load capacity, do no t apply the load unevenly. Improper
loading may cause deterioration of st eering or braking control which
may cause death or serious injury.

168
2−5. Driving information
Vehicle load limits
Total load capacity and seating capacity
These details are also described on the tire and loading information
label.(
P. 292)
CAUTION
Overloading the vehicle
Do not overload the vehicle.
It may not only cause damage to the ti
res, but also degrade steering and
braking ability, resulting in an accident.
Vehicle load limits include total load capacity, seating capacity,
towing capacity and cargo capacity.
 Total load capacity: 1190 lb. (540 kg)
Total load capacity means the combined weight of occupants,
cargo and luggage.
 Seating capacity: 5 occupants (Front 2, Rear 3)
Seating capacity means the ma ximum number of occupants
whose estimated average weight is 150 lb. (68 kg) per person.
Even if the number of occupants are within the seating capacity,
do not exceed the total load capacity.

Towing capacity: 5000 lb. (2265 kg)
Towing capacity means the maximum gross trailer weight (trailer
weight plus its cargo weight) that your vehicle is able to tow.

Cargo capacity
Cargo capacity may increase or decrease depending on the
weight and the number of occupants.

176 2−5. Driving information
CAUTION
 To avoid accident or injury
 The total trailer weight (trailer weight plus the weight of cargo) must not
exceed 5000 lb. (2265 kg)
If a trailer and cargo weight over 2000 lb. (907 kg), use a sway control
device with sufficient capacity.
 The gross combined weight (sum of your vehicle weight plus its load and
the total trailer weight) must not exceed the following.
2WD models
9200 lb. (4173 kg)
4WD models
9500 lb. (4309 kg)
Do not exceed the trailer hitch assembly weight, gross vehicle weight,
gross axle weight and trailer tongue load capacities.
 Never load more weight in the back than in the front of the trailer. About
60% of the load should be in the front half of the trailer, and the remaining
40% in the rear.
 The tow hitch receiver installed on your vehicle must never be used on
another vehicle.
Hitches
If you wish to install a trailer hitch, your Toyota dealer should be consulted.
Use only a hitch that conforms to the total trailer weight requirement.
Follow the directions supplied by the hitch manufacturer.
Lubricate the hitch ball with a light coat of grease.

Remove the trailer hitch whenever y ou are not towing a trailer to reduce
the possibility of additional damage caused by the hitch if your vehicle is
struck from behind.

289
4−3. Do−it−yourself maintenance
4
Maintenance and care
Routine tire inflation pressure checks
The tire pressure warning system doe s not replace routine tire inflation
pressure checks. Make su re to check tire inflation pressure as part of
your routine of daily vehicle checks.
Maximum load of tire
Check that the maximum load of the re placed tire is greater than 1/2 of
the Gross Axle Weight Ratings (GAWR) of either the front axle or the
rear axle, whichever is greater.
As for the maximum load of the tire, see the load limit at maximum cold
tire inflation pressure mentioned on the sidewall of the tire, and as for the
Gross Axle Weight Ratings (GAWR)
, see the Certification Label.
( P. 292, 363, 375).
Tire types
1 Summer tires
Summer tires are high−speed performance tires best suited to highway
driving under dry conditions. Since summer tires do not have the same
traction performance as snow tire
s, summer tires are inadequate for
driving on snow−covered or icy roads. For driving on snow−covered
roads or icy roads, the use of
snow tires is recommended. When
installing snow tires, be sure to replace all four tires.
2 All season tires
All season tires are designed to prov ide better traction in snow and to
be adequate for driving in most winter conditions, as well as for use
year round. All season tires, however, do not have adequate traction
performance compared with snow tires in heavy or loose snow. Also,
all season tires fall short in acceleration and handling performance
compared with summer tires in highway driving.
3Snow tires
For driving on snow−covered roads or icy roads, we recommend using
snow tires. If you need snow tires,
select tires of the same size, con−
struction and load capacity as the or iginally installed tires. Since your
vehicle has radial tires as original equipment, make sure your snow
tires also have radial construction. Do not install studded tires without
first checking local regulations for possible restriction. Snow tires
should be installed on all wheels. (
P. 169)

296
4−3. Do−it−yourself maintenance
Wheels
When replacing wheels
The wheels of your Toyota are equipped with sensors that allow the tire
pressure warning system sensors to provide advanced warning in the
event of a loss in tire inflation pressure. Whenever wheels are replaced,
the tire pressure warning valve and transmitter must be switched over
from the old wheels. (
P. 288) If a wheel is bent, cracked or heavily corroded, it should be
replaced.
Otherwise, the tire may separate from the wheel or cause loss of
handling control.
 Wheel selection
When replacing wheels, care should be taken to ensure that
they are equivalent to those removed in load capacity, diameter,
rim width, and offset.
Replacement wheels are available at your Toyota dealer.
Toyota does not recommend using:

Wheels of different sizes or types
Used wheels

Bent wheels that have been straightened

Aluminum wheel precautions (if equipped)
Use only Toyota wheel nuts and wrench designed for use with
your aluminum wheels.
 When rotating, repairing or changing your tires, check that the
wheel nuts are still tight after driving 1000 miles (1600 km).

Be careful not to damage the aluminum wheels when using
tire chains.
 Use only Toyota genuine balance weights or equivalent and a
plastic or rubber hammer when balancing your wheels.
