2008 TOYOTA FJ CRUISER load capacity

365
6−1. Specifications
6
Vehicle specifications
Lubrication system
*: 5W−30 is an oil that provides optimal levels of fuel efficiency.
Oil viscosity

The 5W portion of the oil viscosity rating indicates the characteristic
of the oil which allows cold startab ility. Oils with a lower value before
the W allow for easier starting of the engine in cold weather.
 The 30 in 5W−30 indicates the oil
viscosity when the oil is at its
operating temperature. An oil with a higher viscosity may be better
suited if the vehicle is operated at high speeds, or under extreme
load condition.
Oil capacity
drain and refill
(Reference)
With filter
Without filter5.5 qt. (5.2 L, 4.6 Imp.qt.)
5.2 qt. (4.9 L, 4.3 Imp.qt.)
Oil grade ILSAC multigrade engine oil
Recommended oil
viscosity
Use Toyota approved “Toyota Genuine Motor
Oil” or equivalent to satisfy the grade and
viscosity shown below.
Outside temperature

380 6−1. Specifications
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation,
or excessive loading, either
separately or in combination, can cause heat buildup and possible
tire failure.
Glossary of tire terminology
Tire related term Meaning
Cold tire inflation
pressureTire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which a
tire may be inflated, shown on the sidewall of
the tire
Recommended
inflation pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weightThe combined weight (in excess of those
standard items which may be replaced) of
transmission, power steering, power brakes,
power windows, power seats, radio and heater,
to the extent that these items are available as
factory−installed equipment (whether installed
or not)
Curb weightThe weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded
vehicle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

381
6−1. Specifications
6
Vehicle specifications
Tire related term Meaning
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows
Occupant distributionDistribution of occupants in a vehicle as
specified in the third column of Table 1
* below
Production options
weightThe combined weight of installed regular
production options weighing over 5 lb. (2.3 kg)
in excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
RimA metal support for a tire or a tire and tube
assembly upon which the tire beads are seated
Rim diameter
(Wheel diameter)Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designationThe industry manufacturer’s designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity)The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicle’s designated seating
capacity
Vehicle maximum load
on the tireThe load on an individual tire that is determined
by distributing to each axle its share of the
maximum loaded vehicle weight, and dividing
by two
Vehicle normal load
on the tireThe load on an individual tire that is determined
by distributing to each axle its share of curb
weight, accessory weight, and normal
occupant weight (distr
ibuted in accordance
with Table 1
* below), and dividing it by two

385
6−1. Specifications
6
Vehicle specifications
*:Table 1 Occupant loading and distri bution for vehicle normal load
for various designated seating capacities
Tire related term Meaning
Tr ea dThat portion of a tire that comes into contact
with the road
Tread ribA tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear
indicators(TWI)
The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel−holding fixtureThe fixture used to hold the wheel and tire
assembly securely
during testing
Designated seating
capacity, Number of
occupants
Vehicle normal load,
Number of occupantsOccupant distribution
in a normally loaded
vehicle
2 through 4 2 2 in front
5 through 10 32 in front, 1 in second
seat
11 through 15 52 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 72 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

397
Alphabetical index
Fuel door .................................... 64
Fuel filler door ........................... 64
Fuel pump shut off system .... 328
Fuses
Fuses.................................... 303
Locations ...................... 307, 311
Gas station information .......... 408
Gauges ..................................... 124
Glass hatch ................................ 41
Glove box ................................. 228
Head restraints
Adjusting ................................ 49
Headlights
Replacing light bulbs ............ 315
Switch ................................... 131
Wattage ................................ 371
Hood ......................................... 273
Hooks
Cargo net.............................. 250
Shopping bag ....................... 251
I/M test ...................................... 268
Identification
Engine .................................. 363
Tire ....................................... 376
Vehicle.................................. 363
Ignition switch ......................... 114
Illuminated entry system ........ 226
Immobilizer system ................... 68
Indicator lights ........................ 127
Initialization
Items to initialize ................... 388
Inside rear view mirror.............. 58
Interior lights
Switch ................................... 227
Wattage ................................ 371
Instrument panel light
control.................................... 125
Intuitive parking assist ........... 139Jack
Positioning the jack ............... 342
Replacing the wheel .............. 340
Jack handle .............................. 342
Keyless entry.............................. 30
Keys
Engine switch ........................ 114
If you lose your keys ............. 352
Ignition switch........................ 114
Key battery ............................ 301
Keyless entry........................... 30
Key number ............................. 28
Keys ........................................ 28
Reminder buzzer ................... 336
Wireless remote control
key .................................. 28, 30
License plate lights
Replacing light bulbs ............. 319
Switch.................................... 131
Wattage ................................. 371
Light bulbs
Replacing .............................. 314
Wattage ................................. 371
Lights
Automatic light off system ..... 132
Headlights switch .................. 131
Instrument panel light control
dial ...................................... 125
Interior light switch ................ 227
Replacing light bulbs ............. 314
Turn signal lights switch ........ 121
Wattage ................................. 371
Limited slip differential............ 150
Load capacity ........... 165, 168, 362
Lock steering column ................ 57
Luggage storage box............... 248
Luggage compartment
features................................... 249
G
H
I
J
K
L

400
Alphabetical index
Intuitive parking assist
switch .................................. 139
Headlights switch .................. 131
Light switch ........................... 131
Power door lock switch ........... 33
Power window switch .............. 62
Rear differential lock
switch .................................. 152
Turn signal lights ................... 121
Window lock switch ................. 62
Wiper and washer ......... 133, 135
Tachometer............................... 124
Tail lights
Replacing light bulbs ............. 318
Switch.................................... 131
Wattage ................................. 371
Theft deterrent system
Engine immobilizer system ..... 68
Theft prevention labels ............ 70
Theft prevention labels.............. 70
Tire inflation pressure ............. 370
Tire information
Glossary ................................ 380
Size ....................................... 377
Tire identification number ...... 376
Uniform tire quality grading ... 378
Tires
Chains ................................... 170
Checking ............................... 287
If you have a flat tire .............. 340
Identification number ............. 376
Inflation pressure................... 370
Inflation pressure sensor ....... 288
Information ............................ 375
Replacing ...................... 287, 340
Rotating tires ......................... 287
Size ....................................... 370
Snow tires ............................. 170
Spare tire............................... 341
Tire pressure warning
system ........................ 287, 337
Warning light ......................... 334Tools ......................................... 340
Total load capacity .................. 168
Towing
Dinghy towing ....................... 182
Emergency towing ................ 322
Trailer towing ........................ 172
Traction control system .......... 156
TRAC ......................................... 156
Trip meter ................................. 124
Turn signal lights
Lever ..................................... 121
Replacing light bulbs ............. 315
Switch ................................... 121
Wattage................................. 371
Vanity mirrors .......................... 236
Vehicle identification
number ................................... 363
Vehicle stability control .......... 156
Voltmeter .................................. 124
VSC ........................................... 156
Warning buzzers
Key reminder......................... 336
Seat belt reminder................. 334
Warning lights
ABS ....................................... 332
Airbag system ....................... 332
Anti−lock brake system .......... 332
Automatic transmission fluid
temperature ........................ 332
Brake system ........................ 331
Charging system ................... 332
Driver’s seat belt ................... 334
Electronic engine control
system ................................ 332
Engine oil replacement ......... 334
Front passenger occupant
classification system ........... 332
Front passenger’s seat belt... 334
Low brake fluid ...................... 331
Low engine oil pressure ........ 332
T
V
W

401
Alphabetical index
Low fuel level........................ 334
Low tire inflation pressure .... 334
Malfunction indicator lamp.... 332
Open door ............................ 334
Seat belt ............................... 334
Seat belt pretensioner
system................................ 332
SRS ...................................... 332
SRS airbag system............... 332
Tire pressure ........................ 334
Tire pressure warning
system................................ 334
Unengaged “Park” ................ 332
VSC/TRAC ........................... 332
Washer
Checking .............................. 286
Preparing and checking
before winter ...................... 169
Switch ........................... 133, 135
Washing and waxing............... 258
Weight
Cargo capacity ..................... 165
Load limits ............................ 168
Weight .................................. 362
Wheels...................................... 296
Window glasses ................. 41, 62
Window lock switch .................. 62
Windows
Power windows ...................... 62
Rear window defogger ......... 190
Washer ......................... 133, 135
Windshield wipers........... 133, 135
Wireless remote control key
Replacing the battery ........... 301
Wireless remote control.......... 30
Winter driving tips................... 169
WMA disc ................................. 208
