2008 TOYOTA FJ CRUISER snow chains

159
2−4. Using other driving systems
2
When driving
CAUTION
 The ABS does not operate effectively when
 The limits of the gripping performance have been exceeded.
The vehicle hydroplanes while driving at high speed on the wet or slick
road.
 Stopping distance when the ABS is
operating will exceed that of nor
mal conditions
The ABS is not designed to shorten the vehicle’s stopping distance. Always
maintain a safe distance from the vehicle in front of you in the following situ−
ations.
 When driving on dirt, gravel or snow−covered roads
When driving with tire chains
When driving over bumps in the road
When driving over roads with potholes or roads with uneven roads
When VSC is activated
The slip indicator flashes and a warning buzzer sounds. Always drive care−
fully. Reckless driving may cause an accident. Exercise particular care when
the indicator flashes and a buzzer sounds.
 TRAC may not operate effectively when
Directional control and power may not be achievable while driving on slip−
pery road surfaces, even if TRAC is operating.
Do not drive the vehicle in conditions where stability and power may be lost.
 Replacing tires
Make sure that all tires are of the same size, brand, tread pattern and total
load capacity. In addition, make sure that the tires are inflated to the appro−
priate tire pressure level.
The ABS and VSC will not function correctly if different tires are fitted on the
vehicle.
Contact your Toyota dealer for further information when replacing tires or
wheels.
 Handling of tires and suspension
Using tires with any kind of problem or modifying the suspension will affect
the driving assist systems, and may cause the system to malfunction.

169
2−5. Driving information
2
When driving
Winter driving tips
Carry out the necessary preparations and inspections before driving
the vehicle in winter. Always drive the vehicle in a manner appropri
ate to the prevailing weather conditions.
 Prewinter preparations
 Use fluids that are appropriate to the prevailing outside tem−
peratures.
Engine oil
Engine coolant
Washer fluid
 Have a service technician inspect the level and specific grav−
ity of battery electrolyte.
Have the vehicle fitted with four snow tires or purchase a set
of tire chains for the rear tires.
Ensure that all tires are the same size and brand, and that chains
match the size of the tires.
 Before driving the vehicle
Perform the following according to the driving conditions.

Do not try to forcibly open a window, scrape an outside rear
view mirror surface or move a wiper or outside rear view mir−
ror that is frozen. Pour warm water over the frozen area to
melt the ice. Wipe away the water immediately to prevent it
from freezing.
To ensure proper operation of th e climate control system fan,
remove any snow that has accumulated on the air inlet vents
in front of the windshield.
Remove any ice that has accumulated on the vehicle chassis.

Periodically check for and remo ve any excess ice or snow
that may have accumulated in the wheel well or on the
brakes.

170 2−5. Driving information
Regulations on the use of snow chains
 Regulations regarding the use of tire chains vary according to loca−
tion and type of road. Always check local regulations before install−
ing chains.
 Install the chains on the rear tires.

Retighten the chains after driving 1/4 − 1/2 mile (0.5 − 1.0 km).
 Snow chain installation
Observe the following precautions when installing and removing chains.
Install and remove tire chains in a safe location.
Install tire chains on the rear tires only. Do not install tire chains on the
front tires.
 Install tire chains following the instructions provided in the accompanying
instructions.
 When driving the vehicle
Accelerate the vehicle slowly and drive at a reduced speed suit−
able to road conditions.
 When parking the vehicle
Park the vehicle and move the shift lever to P (automatic trans−
mission) or to 1 or R (manual transmission) without setting the
parking brake. The parking brak e may freeze up, preventing it
from being released.

171
2−5. Driving information
2
When driving
CAUTION
 Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failing to do so may result in a loss of vehicle control and cause death or
serious injury.
 Use tires of the size specified for your vehicle.
Maintain the recommended level of air pressure.
Do not drive in excess of 75 mph (120 km/h) regardless of the type of
snow tires being used.
 Snow tires should be installed on all wheels.
4WD models:
Do not mix tires of different makes, models, tread patterns or treadwear.
 Driving with snow chains
Observe the following precautions to reduce the risk of accidents.
Failing to do so may result in the vehicle being unable to be driven safely,
and may cause death or serious injury.
 Do not drive in excess of the speed limit specified for the tire chains being
used or 30 mph (50 km/h), whichever is lower.
Avoid driving on bumpy road surfaces or over potholes.
Avoid sudden turns and braking.

Slow down sufficiently before entering a curve to ensure that vehicle con−
trol is maintained.
NOTICE
 Repairing or replacing snow tires
Request repairs of and obtain replacement snow tires from Toyota dealers or
legitimate tire retailers.
This is because the removal and attachment of snow tires affects the opera−
tion of the tire pressure warning valves and transmitters.
 Fitting tire chains
The tire pressure warning valves and transmitters may not function correctly
when tire chains are fitted.

5
When trouble arises
337 5−2. Steps to take in an emergency
If the tire pressure warning system is inoperative
The tire pressure warning system may become inoperative in the follow−
ing conditions:
(When the condition be
comes normal, the system will work properly.)
If tires not equipped with tire pressure warning valves and transmit−
ters are used.
If the ID code on the tire pressure warning valves and transmitters is
not registered in the tire pressure warning computer.
If electronic devices or facilities us ing similar radio wave frequencies
are nearby.
If a radio set at similar frequencies is in use in the vehicle.
If a window tint that affects the radio wave signals is installed.
If there is a lot of snow or ice on the vehicle, in particular around the
wheels or wheel housings.
If non−genuine Toyota wheels are used.
If tire chains are used.
If the spare tire is in a location subject to poor radio wave signal
reception.
If the tire inflation pressure is more than 73 psi (500 kPa, 5.1 kgf/cm2
or bar) or higher.
If the tire pressure warning light comes on after blinking for 1
minute frequently
If the tire pressure warning light comes on after blinking for 1 minute fre−
quently when the engine switch is
turned to the ON position, have it
checked by your Toyota dealer.
 After changing the engine oil (U.S.A. only)
Make sure to reset the oil maintenance data. ( P. 278)
 Customization that can be configured at Toyota dealer
The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features
P. 386)

400
Alphabetical index
Intuitive parking assist
switch .................................. 139
Headlights switch .................. 131
Light switch ........................... 131
Power door lock switch ........... 33
Power window switch .............. 62
Rear differential lock
switch .................................. 152
Turn signal lights ................... 121
Window lock switch ................. 62
Wiper and washer ......... 133, 135
Tachometer............................... 124
Tail lights
Replacing light bulbs ............. 318
Switch.................................... 131
Wattage ................................. 371
Theft deterrent system
Engine immobilizer system ..... 68
Theft prevention labels ............ 70
Theft prevention labels.............. 70
Tire inflation pressure ............. 370
Tire information
Glossary ................................ 380
Size ....................................... 377
Tire identification number ...... 376
Uniform tire quality grading ... 378
Tires
Chains ................................... 170
Checking ............................... 287
If you have a flat tire .............. 340
Identification number ............. 376
Inflation pressure................... 370
Inflation pressure sensor ....... 288
Information ............................ 375
Replacing ...................... 287, 340
Rotating tires ......................... 287
Size ....................................... 370
Snow tires ............................. 170
Spare tire............................... 341
Tire pressure warning
system ........................ 287, 337
Warning light ......................... 334Tools ......................................... 340
Total load capacity .................. 168
Towing
Dinghy towing ....................... 182
Emergency towing ................ 322
Trailer towing ........................ 172
Traction control system .......... 156
TRAC ......................................... 156
Trip meter ................................. 124
Turn signal lights
Lever ..................................... 121
Replacing light bulbs ............. 315
Switch ................................... 121
Wattage................................. 371
Vanity mirrors .......................... 236
Vehicle identification
number ................................... 363
Vehicle stability control .......... 156
Voltmeter .................................. 124
VSC ........................................... 156
Warning buzzers
Key reminder......................... 336
Seat belt reminder................. 334
Warning lights
ABS ....................................... 332
Airbag system ....................... 332
Anti−lock brake system .......... 332
Automatic transmission fluid
temperature ........................ 332
Brake system ........................ 331
Charging system ................... 332
Driver’s seat belt ................... 334
Electronic engine control
system ................................ 332
Engine oil replacement ......... 334
Front passenger occupant
classification system ........... 332
Front passenger’s seat belt... 334
Low brake fluid ...................... 331
Low engine oil pressure ........ 332
