2008 TOYOTA FJ CRUISER odometer

124
2−2. Instrument cluster
Gauges and meters
The following gauges, meters and displays illuminate when the
engine switch is in the ON position.
Tachometer
Displays the engine speed in revolutions per minute.
Speedometer
Displays the vehicle speed.
Vo l t m e t e r
Displays the charge state.
Engine coolant temperature gauge
Displays the engine coolant temperature.
Fuel gauge
Displays the quantity of fuel remaining in the tank.
Odometer/trip meter switching and trip meter resetting button
Switches between odometer and trip meter displays. Pushing and hold−
ing the button will reset the trip meter when the trip meter is being dis−
played.

125
2−2. Instrument cluster
2
When drivingOdometer and trip meter display button
Pressing this button switches between odometer and trip meter dis−
plays.
Odometer
Trip meter A
*
Trip meter B*
*:Pushing and holding the button
will reset the trip meter.
Instrument panel light control
The brightness of the instrument panel lights can be adjusted.
Brighter
Darker
With the dial turned fully up, the
intensity of the instrument panel
lights will not be reduced even
when the tail lights/headlights are
turned on.
Odometer/trip meter
Odometer:
Displays the total distance the vehicle has been driven.
Trip meter:
Displays the distance the vehicle has been driven since the meter was
last reset. Trip meters A and B can be used to record and display differ−
ent distances independently.

278 4−3. Do−it−yourself maintenance
 After changing the engine oil (U.S.A. only)
The oil change system should be reset. Perform the following procedures:
Turn the engine switch off with the odometer reading shown.( P.
124)
Turn the engine switch to the ON position while holding down the
trip meter reset button.
Continue to press and hold the button until the odometer displays
000000.
If the system fails to reset, the light will continue flashing.
CAUTION
 Used engine oil
 Used engine oil contains potentially harmful contaminants which may
cause skin disorders such as inflammation or skin cancer, so care should
be taken to avoid prolonged and repeated contact. To remove used engine
oil from your skin, wash thoroughly with soap and water.
 Dispose of used oil and filters only in a safe and acceptable manner. Do
not dispose of used oil and filters in household trash, in sewers or onto the
ground. Call your Toyota dealer, service station or auto parts store for
information concerning recycling or disposal.
 Do not leave used engine oil within the reach of children.
NOTICE
 To prevent serious engine damage
Check the oil level on regular basis.
When replacing the engine oil
Be careful not to spill engine oil on the vehicle components.
Avoid overfilling, as the engine could be damaged.
Check the oil level on the dipstick every time you refill the vehicle.

Be sure the engine oil filler cap is properly tightened.

398
Alphabetical index
Maintenance
Do−it−yourself maintenance ... 269
General maintenance ............ 265
Maintenance data.................. 362
Maintenance requirements.... 263
Vehicle exterior ..................... 258
Vehicle interior ...................... 260
Malfunction indicator lamp ..... 332
Manual air conditioning
system .................................... 184
Manual transmission ............... 119
Meter
Accessory meter ................... 130
Instrument panel light
control ................................. 125
Meters ................................... 124
Mirrors
Inside rear view mirror............. 58
Side mirrors ............................. 59
Vanity mirrors ........................ 236
MP3 disc ................................... 208
Odometer .................................. 124
Offroad precautions
Driving ................................... 162
Vehicle .................................. 160
Oil
Engine oil .............................. 275
Warning light .................. 332,334
Opener
Hood...................................... 273
Outside rear view mirror
illumination lights
Replacing light bulbs ............. 319
Switch.................................... 131
Wattage ................................. 371
Outside rear view mirrors
Adjusting and folding ............... 59
Outside temperature
display .................................... 238
Overheating, Engine ................ 356Parking assist .......................... 139
Parking brake ........................... 122
Parking lights
Replacing light bulbs ............. 317
Switch ................................... 131
Wattage................................. 371
Power outlet ..................... 239, 240
Power steering
Fluid ...................................... 282
Power windows .......................... 62
Radiator ............................ 274, 280
Radio ......................................... 194
Rear seat
Folding down........................... 44
Removing rear seat bottom
cushions ............................... 45
Rear side marker lights
Replacing light bulbs ............. 318
Switch ................................... 131
Wattage................................. 371
Rear turn signal lights
Lever ..................................... 121
Replacing light bulbs ............. 318
Switch ................................... 121
Wattage................................. 371
Rear window............................... 41
Rear window defogger ............ 190
Replacing
Key battery ............................ 301
Fuses .................................... 303
Light bulbs............................. 314
Tires ............................... 287,340
Wheels .................................. 296
Rear differential lock
system .................................... 152
Rear step bumper ...................... 40
Rear window wiper .................. 135
Reporting safety defects for
U.S. owners ............................ 390
M
O
P
R
