2008 TOYOTA FJ CRUISER Owners Manual

383
6−1. Specifications
6
Vehicle specifications
Tire related term Meaning
Innerliner separationThe parting of the innerliner from cord material
in the carcass
Intended outboard
sidewall(a)The sidewall that contains a whitewall, bears
white lettering, or bears manufacturer,
brand, and/or model name molding that is
higher or deeper than the same molding on
the other sidewall of the tire, or
(b)The outward facing sidewall of asymmetrical
tire that has a particular side that must
always face outward when mounted on a
vehicle
Light truck (LT) tireA tire designated by its manufacturer as
primarily intended for use on lightweight trucks
or multipurpose passenger vehicles
Load ratingThe maximum load that a tire is rated to carry
for a given inflation pressure
Maximum load ratingThe load rating for a tire at the maximum
permissible inflation pressure for that tire
Maximum permissible
inflation pressureThe maximum cold inflation pressure to which
a tire may be inflated
Measuring rimThe rim on which a tire is fitted for physical
dimension requirements
Open spliceAny parting at any junction of tread, sidewall, or
innerliner that extends to cord material
Outer diameter The overall diameter of an inflated new tire
Overall widthThe linear distance between the exteriors of
the sidewalls of an inflated tire, including
elevations due to labeling, decorations, or
protective bands or ribs
Passenger car tireA tire intended for use on passenger cars,
multipurpose passenger vehicles, and trucks,
that have a gross vehicle weight rating
(GVWR) of 10,000 lb. or less

384 6−1. Specifications
Tire related term Meaning
Ply A layer of rubber−coated parallel cords
Ply separationA parting of rubber compound between
adjacent plies
Pneumatic tireA mechanical device made of rubber,
chemicals, fabric and steel or other materials,
that, when mounted on an automotive wheel,
provides the traction and contains the gas or
fluid that sustains the load
Radial ply tireA pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread
Reinforced tireA tire designed to operate at higher loads and
at higher inflation pressures than the
corresponding standard tire
Section widthThe linear distance between the exteriors of
the sidewalls of an inflated tire, excluding
elevations due to labeling, decoration, or
protective bands
SidewallThat portion of a tire between the tread and
bead
Sidewall separationThe parting of the rubber compound from the
cord material in the sidewall
Snow tireA tire that attains a traction index equal to or
greater than 110, compared to the ASTM E−
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F−1805−00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow−and Ice−Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i mThe rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire

385
6−1. Specifications
6
Vehicle specifications
*:Table 1 Occupant loading and distri bution for vehicle normal load
for various designated seating capacities
Tire related term Meaning
Tr ea dThat portion of a tire that comes into contact
with the road
Tread ribA tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear
indicators(TWI)
The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel−holding fixtureThe fixture used to hold the wheel and tire
assembly securely
during testing
Designated seating
capacity, Number of
occupants
Vehicle normal load,
Number of occupantsOccupant distribution
in a normally loaded
vehicle
2 through 4 2 2 in front
5 through 10 32 in front, 1 in second
seat
11 through 15 52 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 72 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

386
6−2. Customization
Customizable features
ItemFunctionDefault settingCustomized
setting
Wireless
remote con−
trol
(
P. 30)Wireless remote control ON OFF
Unlocking operationDriver ’s door
unlocked in
one step, all
doors
unlocked in
two stepsAll doors
unlocked in
one step
Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked60 seconds0 seconds
30 seconds
120 seconds
Operation signal
(Emergency flashers)ON OFF
Door lock buzzer ON OFF
Panic function ON OFF
Buzzer sounds when
pushing LOCK with any
door not closed
ON OFF
Your vehicle includes a variety of electronic features that can be per
sonalized to your preferences.
Programming these preferences
requires specialized equipment and may be performed by an autho
rized Toyota dealership.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

387
6−2. Customization
6
Vehicle specifications
Door lock
(
P. 33)Unlocking using a keyDriver ’s door
unlocked in
one step, all
doors
unlocked in
two stepsAll doors
unlocked in
one step
Automatic
light off sys−
tem
(
P. 131)Time elapsed before
headlights automati−
cally turn off after doors
are closed30 seconds0 seconds
60 seconds
90 seconds
Illumination
(
P. 226)Time elapsed before
lights turn off15 seconds7.5 seconds
30 seconds
Operation after the
engine switch is turned
to the LOCK positionON OFF
Operation when the
doors are unlockedON OFF
Seat Belt
Reminder
Buzzer
(
P. 334)Vehicle speed linked
seat belt reminder
buzzer
ON OFF
ItemFunctionDefault settingCustomizedsetting

388
6−2. Customization
Items to initialize
ItemWhen to initialize Reference
Engine oil maintenance
dataAfter changing engine oil
P. 278
The following items must be init ialized for normal system operation
in cases such as after the battery is
reconnected, or maintenance is
performed on the vehicle.

390
Repor ting safety defects for U.S. owners
If you believe that your vehicle has a defect which could cause a
crash or could cause injury or
death, you should immediately
inform the National Highway Traffic Safety Administration (NHTSA)
in addition to notifying Toyota Motor
Sales, U.S.A., Inc. (Toll−free:
1−800−331−4331).
If NHTSA receives similar complaints, it may open an investigation,
and if it finds that a safety defec t exists in a group of vehicles, it
may order a recall and remedy campaign. However, NHTSA can−
not become involved in individ
ual problems between you, your
dealer, or Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may call the Vehicle Safety Hotline toll−free
at 1−888−327−4236 (TTY: 1−800−424−9153); go to http://www.safer
car.gov
; or write to: Administrator, NHTSA, 400 Seventh Street,
SW., Washington, DC 20590. You can also obtain other informa−
tion about motor vehicle safety from http://www.safercar.gov.

392
Abbreviation list
Abbreviation/Acronym list
ABBREVIATIONS MEANING
2WDTwo Wheel Drive
4WD Four Wheel Drive
ABS Anti−Lock Brake System
ACC Accessory
AI−SHIFT Artificial Intelligence shifting
ALR Automatic Locking Retractor
A−TRAC Active Traction Control
AUTO LSD Automatic Limited Slip Differential
CRS Child Restraint System
E/M English/U.S. Customary System and metric
ECU Electronic Control Unit
EDR Event Data Recorder
ELR Emergency Locking Retractor
GAWR Gross Axle Weight Rating
GVWR Gross Vehicle Weight Rating
I/M Emission inspection and maintenance
INT Intermittent
LED Light Emitting Diode
LT Light truck
M + S Mud + Snow
MMT Methylcy clopentadienyl Manganese Tricarbonyl
MTBE Methyl Tertiary Butyl Ether
OBD On Board Diagnostics
RES Resume
RR DIFF LOCK Rear differential lock
SRS Supplemental Restraint System
TIN Tire Identification Number
