2008 TOYOTA FJ CRUISER park assist

1
2
3
4
5
6
7
3
24. Using other driving
systems ........................... 136
Cruise control ...................... 136
Intuitive parking assist......... 139
Four−wheel drive system
(4WD models with a manual
transmission) .................... 144
Four−wheel drive system
(4WD models with an
automatic transmission) .... 146
Active traction control
system .............................. 148
AUTO LSD system (2WD
models) ............................. 150
Rear differential lock
system .............................. 152
Clutch start cancel switch
(vehicles with a manual
transmission) .................... 155
Driving assist systems ........ 156
25. Driving information ........... 160
Off−road precautions ........... 160
Cargo and luggage ............. 165
Vehicle load limits ............... 168
Winter driving tips ............... 169
Trailer towing ...................... 172
Dinghy towing ..................... 182
31. Using the air conditioning
system and defogger...... 184
Air conditioning system ....... 184
Rear window defogger ........ 19032. Using the audio system ... 191
Audio system types ............ 191
Using the radio ................... 194
Using the CD player ........... 200
Playing back MP3 and
WMA discs ....................... 208
Optimal use of the audio
system .............................. 217
Operating the sub woofer ... 220
Changing display color
(type B only) ..................... 221
Using the AUX adapter....... 222
Using the steering wheel
audio switches.................. 224
33. Using the interior lights ... 226
Interior lights list ................. 226
 Interior lights.................... 227
34. Using the storage
features ........................... 228
List of storage features ....... 228
Glove box ......................... 228
Cup holders (front) ........... 229
Cup holders (rear) ............ 232
Bottle holders ................... 233
Auxiliary box ..................... 234
35. Other interior features ..... 235
Sun visors........................... 235
Vanity mirror ....................... 236
Clock .................................. 237
Outside temperature
display .............................. 238
Power outlet (12V DC) ....... 239
Power outlet
(if 115V AC equipped) ...... 240
Armrest ............................... 246
3Interior features

16
Pictorial indexInstrument panel
AUTO LSD switchP. 150
RR DIFF LOCK switchP. 152
A−TRAC switchP. 148
Power outlet main switch
P. 240
Intuitive parking assist
switch
P. 139
AUX adapterP. 222
SUB WOOFER switchP. 220
Power outletP. 239

111
2−1. Driving procedures
2
When driving
CAUTION
 When taking a nap in the vehicle
Always turn the engine off. Otherwise, you may accidentally move the shift
lever or depress the accelerator pedal, which could cause an accident or fire
due to engine overheating. Additionally, if the vehicle is parked in a poorly
ventilated area, exhaust gases may collect and enter the vehicle, leading to
death or a serious health hazard.
 When braking the vehicle
 When the brakes are wet, drive more cautiously.
Braking distance increases when the brakes are wet, and may cause one
side of the vehicle to brake differently than the other side. Also the parking
brake may not securely hold the vehicle.
 If the power brake assist function does not operate, do not follow other
vehicles closely and avoid downhills or sharp turns that require braking.
In this case, braking is still possible, but it will require more force on the
pedal than usual. Braking distance may also increase.
 Do not pump the brake pedal if the engine stalls.
Each push on the brake pedal uses up the reserve for the power−assisted
brakes.
 The brake system consists of 2 individual hydraulic systems: If one of the
systems fails, the other will still operate. In this case, the brake pedal
should be depressed more firmly than usual and braking distance
becomes longer.
Do not drive your vehicle with only a single brake system. Have your
brakes fixed immediately.

139
2−4. Using other driving systems
2
When driving
Intuitive par king assist (if equipped)
The distance to obstacles measured by the sensors is communi
cated via the buzzer when parallel parking or maneuvering into a
garage. Always check the surrounding area when using this system.
This system works when the engine switch is in the ON position and
the shift lever is in R.
 Back sensors
These sensors detect obsta−
cles behind the vehicle.

140 2−4. Using other driving systems
The distance and buzzer
When a sensor detects an obstacle, the buzzer sounds.  Intuitive parking assist switch
ON/OFF
When on, the buzzer sounds
to inform the driver that the
system is operational. At this
time, the indicator light will
come on.
Press the button to switch the
ON/OFF mode.
Distance shown
as4.9 to 3.3 ft.
(150 to 100 cm)3.3 to 1.6 ft.
(100 to 50 cm)1.6 ft.
(50 cm)
Buzzer Medium Fast Continuous

142 2−4. Using other driving systems
 Sensor detection information
 Certain vehicle conditions and the surrounding environment may affect
the ability of a sensor to correctly detect an obstacle. Particular instances
where this may occur are listed below.
There is dirt, snow or ice on a sensor.
A sensor is frozen.
A sensor is covered in any way.
The vehicle is leaning considerably to one side.
On an extremely bumpy road, on an incline, on gravel, or on grass.
The vicinity of the vehicle is noisy due to vehicle horns, motorcycle
engines, air brakes of large vehicles, or other loud noises producing
ultrasonic waves.
There is another vehicle equipped with parking assist sensors in the
vicinity.
A sensor is coated with a sheet of spray or heavy rain.
The vehicle is equipped with a fender pole or radio antenna.
A bumper or sensor receives a strong impact.
The vehicle is approaching a tall or right−angled curb.
In harsh sunlight or intense cold weather.
The area directly under the bumpers is not detected.
Objects lower than the sensors or thin stakes etc. may be detected ini−
tially, but as they draw closer, they may cease to be detected.
A towing hitch is mounted to the vehicle.
A non−genuine Toyota suspension (lowered suspension etc.) is
installed.
In addition to the examples above, there are instances in which, because of
their shapes, signs and other objects may be judged by a sensor to be closer
than they are.
 The shape of the obstacle may prevent a sensor from detecting it. Pay
particular attention to the following obstacles:
Wires, fences, ropes, etc.
Cotton, snow and other materials that absorb radio waves
Sharply−angled objects
Low obstacles
Tall obstacles with upper sections projecting outwards in the direction
of your vehicle

143
2−4. Using other driving systems
2
When driving
.
 Certification (Canada only)
This ISM device compiles with Canadian ICES−001.
CAUTION
 Caution when using the intuitive parking assist
Observe the following precautions.
Failure to do so may result in the vehicle being unable to be driven safely
and possibly cause an accident.
 Do not use the sensor at speeds in excess of 6 mph (10 km/h).

Do not attach any accessories within the sensor range.
NOTICE
 Notes when washing the vehicle
Do not apply intensive bursts of water or steam to the sensor area.
Doing so may result in the sensor malfunctioning.

312 4−3. Do−it−yourself maintenance
7 ECU−IG 10 AAnti−lock brake system, vehicle sta−
bility control system, traction con−
trol system, active traction control
system, AUTO LSD system, multi−
port fuel injection system/sequen−
tial multiport fuel injection system,
cruise control system, back door
lock system, shift lock system, mul−
tiplex communication system
8 IG1 15 ATurn signal lights, air conditioning
system, charging system, clutch
start cancel switch, anti−lock brake
system, traction control system,
active traction control system, vehi−
cle stability control system, AUTO
LSD system, back−up lights, intui−
tive parking assist, rear differential
lock system, power outlet, acces−
sory meter, meter and gauge
9 STA 7.5 AStarting system, clutch start cancel
switch, power outlet
10 TAIL 10 ATail lights, license plate lights, park−
ing lights, instrument panel light
control, illuminations
11 A C C 7 . 5 AShift lock system, outside rear view
mirrors, audio system, power out−
let, clock, accessory meter, multi−
plex communication system
12 POWER 30 A Power windows
FuseAmpereCircuit
