2008 MERCEDES-BENZ S600 Owner's Manual

728 Technical data
Fuels, coolants, lubricants, etc.
Engine oils
Engine oils are specifically tested for their
suitability in our engines and durability for
our service intervals. Therefore, only use
approved engine oils and oil filters
required for vehicles with Maintenance
System. For a listing of approved engine
oils and oil filters, refer to the Factory
Approved Service Products pamphlet
(USA only), or contact an authorized
Mercedes-Benz Center.Engine oil additives
Air conditioning refrigerant
R-134a (HFC) refrigerant and special PAG
lubricating oil are used in the air condition-
ing system.
Brake fluid
Only brake fluid approved by
Mercedes-Benz is recommended. Any au-
thorized Mercedes-Benz Center will pro-
vide you with additional information.
!Using engine oils and oil filters of
specification other than those expressly
required for the Maintenance System, or chang-
ing of oil and oil filter at change intervals longer
than those called for by the Maintenance System
will result in engine or emission control system
damage not covered by the Mercedes-Benz Lim-
ited Warranty.
Please follow Maintenance System recommen-
dations for scheduled oil changes. Failure to do
so will result in engine or emission control sys-
tem damage not covered by the Mercedes-Benz
Limited Warranty.
!Do not blend oil additives with engine oil.
They may damage the engine. Damage or mal-
functions resulting from blending oil additives
are not covered by the Mercedes-Benz Limited
Warranty.
!Never use R-12 (CFC) or mineral-based lu-
bricating oil. Otherwise damage to the system
will occur.
Warning!G
During vehicle operation, the boiling point of
the brake fluid is continuously reduced
through the absorption of moisture from the
atmosphere.
Under extremely strenuous operating condi-
tions, this moisture content can lead to the
formation of bubbles in the system, thus re-
ducing the system’s efficiency.
Therefore, the brake fluid must be replaced
regularly. Refer to your vehicle’s Mainte-
nance Booklet for replacement interval.

729 Technical data
Fuels, coolants, lubricants, etc.
Premium unleaded gasolineFuel requirements
Only use premium unleaded fuel:

The octane number (posted at the
pump) must be 91 min. It is an average
of both the Research Octane Number
(RON) and the Motor Octane Number
(MON): (RON+MON)/2. This is also
known as the ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates
such as ethanol, IPA, IBA and TBA can be
used provided the ratio of any one of these
oxygenates to gasoline does not exceed
10%; MTBE must not exceed 15%.
The ratio of methanol to gasoline must not
exceed 3% plus additional co-solvents.
Using mixtures of ethanol and methanol is
not allowed. Gasohol, which contains
10% ethanol and 90% unleaded gasoline,
can be used.
These blends must also meet all other fuel
requirements, such as resistance to spark
knock, boiling range, vapor pressure, etc.Warning!G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious per-
sonal injury.
Never allow sparks, flame or smoking mate-
rials near gasoline!
Turn off the engine before refueling.
Whenever you are around gasoline, avoid in-
haling fumes and skin or clothing contact,
extinguish all smoking materials.
Direct skin contact with fuels and the inha-
lation of fuel vapors are damaging to your
health.
!To maintain the engine’s durability and per-
formance, premium unleaded gasoline must be
used. If premium unleaded gasoline is not avail-
able and low octane fuel is used, follow these
precautions:

Have the fuel tank only partially filled with
unleaded regular gasoline and fill up with
premium unleaded gasoline as soon as
possible.

Avoid full throttle driving and abrupt acceler-
ation.

Do not exceed an engine speed of 3 000 rpm
if the vehicle is loaded with a light load such
as two persons and no luggage.

Do not exceed 2/3 of maximum accelerator
pedal position if the vehicle is fully loaded or
operating in mountainous terrain.

730 Technical data
Fuels, coolants, lubricants, etc.
Gasoline additives
A major concern among engine manufac-
turers is carbon build-up caused by gaso-
line. Mercedes-Benz recommends only the
use of quality gasoline containing additives
that prevent the build-up of carbon depos-
its.
After an extended period of using fuels
without such additives, carbon deposits
can build up especially on the intake valves
and in the combustion area, leading to en-
gine performance problems such as:

Warm-up hesitation

Unstable idle

Knocking/pinging

Misfire

Power lossIn areas where carbon deposits may be en-
countered due to lack of availability of gas-
olines which contains these additives,
Mercedes-Benz recommends the use of
additives approved by us for use on
Mercedes-Benz vehicles. Refer to the Fac-
tory Approved Service Products pamphlet
(USA only) or contact an authorized
Mercedes-Benz Center for a listing of ap-
proved product(s). Follow directions on
product label.
Do not blend other fuel additives with fuel.
This only results in unnecessary cost and
may be harmful to the engine operation.
Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which pro-
vides:

Corrosion protection

Freeze protection

Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -22°F (-30°C) and corro-
sion protection.
If the antifreeze mixture is effective to
-22°F (-30°C), the boiling point of the cool-
ant in the pressurized cooling system is
reached at approximately 266°F (130°C).
!Damage or malfunction resulting from poor
fuel quality or from blending additional fuel addi-
tives other than those tested and approved by us
for use on Mercedes-Benz vehicles are not cov-
ered by the Mercedes-Benz Limited Warranty.!Add premixed coolant solution only. Adding
water and MB 325.0 Anticorrosion/Antifreeze
separately from each other, could cause engine
damage not covered by the Mercedes-Benz Lim-
ited Warranty.

731 Technical data
Fuels, coolants, lubricants, etc.
The coolant solution must be used year
round to provide the necessary corrosion
protection and increase boil-over protec-
tion. Refer to Maintenance Booklet for re-
placement interval.
Coolant system design and coolant used
determine the replacement interval. The
replacement interval published in the
Maintenance Booklet is only applicable if
MB 325.0 Anticorrosion/Antifreeze solu-
tion or other Mercedes-Benz approved
products of equal specification are used to
renew the coolant concentration or bring it
back up to the proper level.
For information on other Mercedes-Benz
approved products of equal specification,
refer to the Factory Approved Service
Products pamphlet (USA only) or contact
an authorized Mercedes-Benz Center.
To provide important corrosion protection,
the solution must be at least 50% anticor-
rosion/antifreeze (equivalent to freeze
protection to approximately –35°F
[–37°C]).If you use a solution that is more than 55%
anticorrosion/antifreeze (freeze protec-
tion to approximately –49°F [–45°C]), the
engine temperature will increase due to
the lower heat transfer capability of the so-
lution. Therefore, do not use more than
this amount of anticorrosion/ antifreeze.
If the coolant level is low, water and
MB 325.0 Anticorrosion/Antifreeze
should be used to bring it up to the proper
level (have cooling system checked for
signs of leakage).
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality, con-
sult an authorized Mercedes-Benz Center.Anticorrosion/antifreeze
Your vehicle contains a number of alumi-
num parts. The use of aluminum compo-
nents in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be specifical-
ly formulated to protect the aluminum
parts. Failure to use such anticorrosion/
antifreeze coolant will result in a signifi-
cantly shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
Mercedes-Benz 325.0 Anticorrosion/
Antifreeze agent.
Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Center for service.

732 Technical data
Fuels, coolants, lubricants, etc.
Anticorrosion/antifreeze quantity
ModelApproximate freeze protection
– 35°F (– 37°C)– 49°F (– 45°C)
S 550
S 550 4MATICVehicles without rear passenger
compartment climate control*6.08 US qt. (5.75 l)6.71 US qt. (6.35 l)
Vehicles with rear passenger com-
partment climate control*6.97 US qt. (6.60 l)7.66 US qt. (7.25 l)
S 600 (main cooling system)7.34 US qt. (6.95 l)8.08 US qt. (7.65 l)
S 600 (low temperature cooling system)1.37 US qt. (1.3 l)1.51 US qt. (1.43 l)
S 63 AMG6.0 US qt. (5.6 l)7.0 US qt. (6.16 l)
S 65 AMG (main cooling system)7.4 US qt. (7.0 l)8.14 US qt. (7.7 l)
S 65 AMG (low temperature cooling system)1.64 US qt. (1.55 l)1.81 US qt. (1.71 l)

733 Technical data
Fuels, coolants, lubricants, etc.
Windshield washer system and
headlamp cleaning system
Both the windshield washer system and
headlamp cleaning systems are supplied
from the windshield washer reservoir.
The windshield washer reservoir has a ca-
pacity of approximately 6.87 US qt (6.5 l).
Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer solvent/
antifreeze, depending on ambient tem-
peratures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:

1 part “MB SummerFit” to 100 parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] water).
For temperatures below freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and commercially avail-
able premixed windshield washer sol-
vent/antifreeze:

1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent).Warning!G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.

734

735 Index
A
ABC* 442
Messages in display 626
Setting vehicle level 443
ABS 66
Indicator lamp 29, 66, 598
Messages in display 628
Accelerator position, automatic
transmission 406
Accessory weight 576
Accident 394
Active headlamps 371
Adaptive Brake Lights
(S 600 and USA only) 68
Adaptive Damping System
(Airmatic) 440
Additional turn signals 679
Address book (COMAND) 224
Calling up 224
Changing an entry 229
Creating an entry 225
Deleting an entry 226
Details about an entry 228
Displaying details about an entry in the
phone book on the mobile
phone 229Importing data 234
Making a call 231
Menu overview 224
Searching for an entry 226
Starting route guidance 231
Voice entry 232
Address book (Voice Control*) 306
ADS (Airmatic) 440
Air bags 42
Children 57
Front 45
Front passenger front air bag
indicator lamp 50
OCS 47
Safety guidelines 44
Side impact 46
Window curtain 46
Air conditioning, Refrigerant 727, 728
Air distribution
Adjusting 478
Adjusting (COMAND) 253
Air pressure 576
Air pressure see Tire inflation pressure
Air recirculation mode 474
Air vents 468Air volume
Adjusting 472, 478
Adjusting (COMAND) 253
Airmatic 440
Messages in display 642
Setting vehicle level 441
Alarm
Audible alarm and flashing exterior
lamps (Panic alarm) 65
Alarm system see Anti-theft alarm system
Alignment bolt (vehicle tool kit) 668, 689
Ambient lighting
COMAND menu 247
AMG menu (Control system
instrument cluster) 273
AMG vehicles
Manual shift program mode 413
Antiglare
Rear view mirrors 363
Anti-theft systems 81
Alarm, visual and audible 81
Anti-theft alarm system 81
Immobilizer 81
Aquaplaning see Hydroplaning
Armrest 495, 496
