2008 MERCEDES-BENZ S600 Owner's Manual

336 Controls in detail
Locking and unlocking
Important notes on using KEYLESS-GO

You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(
page 332).
The starter switch is located under the
KEYLESS-GO button. Pull the
KEYLESS-GO button out in order to ac-
cess the starter switch.

You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with button ‹).
Warning!G
To prevent possible personal injury, always
keep hands and fingers away from the door
or trunk lid opening when closing a door or
the trunk. Be especially careful when small
children are around.
Before closing doors, make sure there is no
possibility of someone getting caught in a
door during closing.
iUSA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iCanada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iYou can also open and close the door win-
dows and tilt/sliding sunroof, or the tilt/ sliding
panel* using the SmartKey with KEYLESS-GO
(
page 385).
!If you cannot lock or unlock the vehicle with
the SmartKey with KEYLESS-GO, then either the
batteries in the SmartKey with KEYLESS-GO are
discharged, the SmartKey with KEYLESS-GO is
malfunctioning or the vehicle batteries are
drained.

Check the batteries in the SmartKey with
KEYLESS-GO and replace them if necessary
(
page 676).

Use the mechanical key to unlock the driv-
er’s door (
page 671) and trunk
(
page 672).

Use the mechanical key to lock the driver’s
door (
page 672) and the trunk
(
page 484).

Have the vehicle batteries and their connec-
tions checked (
page 692).
If the SmartKey with KEYLESS-GO is malfunc-
tioning, contact Roadside Assistance or an au-
thorized Mercedes-Benz Center.

337 Controls in detail
Locking and unlocking

Always carry the SmartKey with
KEYLESS-GO with you.

Never store the SmartKey with
KEYLESS-GO together with:

Electronic items such as a mobile
phone or another SmartKey with
KEYLESS-GO

Metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.

To lock or unlock the vehicle, the
SmartKey with KEYLESS-GO must be
located outside the vehicle within ap-
proximately 3 ft (1 m) of a door or the
trunk lid.

If the vehicle has been parked for more
than 72 hours, you must pull an outside
door handle in order to activate the
KEYLESS-GO function.

In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.

The KEYLESS-GO start/stop button
must be inserted in the starter
switch (
page 346).

The brake pedal must be firmly de-
pressed. Do not depress the accel-
erator.

If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle, the system may no longer recog-
nize the SmartKey with KEYLESS-GO.
The vehicle then cannot be locked or
the engine started via the KEYLESS-GO
system.

If the SmartKey with KEYLESS-GO is re-
moved from the vehicle (e.g. if passen-
ger exits the vehicle with the SmartKey
with KEYLESS-GO)

when pressing the KEYLESS-GO
start/stop button or trying to lock
the vehicle with the outside door handle the message “Key not recog-
nized” appears in the multifunction
display

with the engine running, the mes-
sage “Key not recognized” appears
in the multifunction display while
driving off
Find the SmartKey with KEYLESS-GO or
change its present location immediate-
ly (e.g. place it on the front passenger
seat or insert it in shirt pocket).

If you have started the engine with the
KEYLESS-GO start/stop button, you
can turn it off again with:

the KEYLESS-GO start/stop button

the SmartKey with KEYLESS-GO in-
serted in the starter switch, when
the automatic transmission is in
park positionP

338 Controls in detail
Locking and unlocking

Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle.
Possibility 1: (One SmartKey with
KEYLESS-GO in the vehicle, one
SmartKey with KEYLESS-GO outside
the vehicle):
If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, no message
appears in the multifunction display.
Possibility 2: (One SmartKey with
KEYLESS-GO in the vehicle, no
SmartKey with KEYLESS-GO outside
the vehicle):
When exiting and trying to lock the ve-
hicle, the message “Key still in vehicle”
appears in the multifunction display.
The vehicle will not be locked.Factory setting
1Outside door handleGlobal unlocking: Grasp an outside
door handle1.

All turn signal lamps flash once.

An acoustic signal sounds once
(if equipped and feature activated).

The locking knobs in the doors
move up.

The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if:

neither a door nor the trunk is opened

the central locking/unlocking switch is
not activated
iYour vehicle may be equipped with an
acoustic lock and unlock confirmation signal fea-
ture. If your vehicle is equipped with this feature
and the feature is activated, an acoustic signal
will sound when the vehicle is locked or unlocked
using the SmartKey with KEYLESS-GO.
To determine whether or not your vehicle is
equipped with this feature, contact an autho-
rized Mercedes-Benz Center. If equipped and
you wish to activate or deactivate the feature, or
adjust its signal volume, also contact an autho-
rized Mercedes-Benz Center.
iThe vehicle could inadvertently be unlocked
if the SmartKey with KEYLESS-GO is within 3 ft
(1 m) of the vehicle and:

an outside door handle is splashed with wa-
ter, or

you attempt to clean an outside door handle.

339 Controls in detail
Locking and unlocking
Global locking: Close all doors and
touch outside of door handle1. Do
not keep your hand in the door handle
recess.
With the trunk and both doors closed:

All turn signal lamps flash three
times.

An acoustic signal sounds three
times (if equipped and feature acti-
vated).

The locking knobs in the doors
move down.

The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you, grasp the driv-
er’s outside door handle only the driver’s
door and the fuel filler flap unlocks.
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 335)
flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:
Unlocking driver’s door and fuel fill-
er flap: Grasp the driver’s outside door
handle.

All turn signal lamps flash once.

An acoustic signal sounds once
(if equipped and feature activated).
For more information, see “Factory
setting” (
page 338).

The locking knob in the driver’s
door moves up.

The anti-theft alarm system is dis-
armed.
Global unlocking: Grasp any outside
door handle other than the driver’s out-
side door handle.

All turn signal lamps flash once.

An acoustic signal sounds once
(if equipped and feature activated).

The locking knobs in the doors
move up.

The anti-theft alarm system is dis-
armed.
iVehicles with trunk opening/closing
system*:
You can also lock the vehicle using the
KEYLESS-GO locking/closing switch
(
page 482).


340 Controls in detail
Locking and unlocking
Global locking: Close all doors and
touch outside of door handle1
(
page 338). Do not keep your hand in
the door handle recess.
With the trunk and both doors closed:

All turn signal lamps flash three
times.

An acoustic signal sounds three
times (if equipped and feature acti-
vated).

The locking knobs in the doors
move down.

The anti-theft alarm system is
armed.
Restoring to factory setting: Press
and hold buttonsŒ and‹ si-
multaneously for about 5 seconds until
battery check lamp5 (
page 335)
flashes twice.Checking batteries in the SmartKey or
SmartKey with KEYLESS-GO*
Press button‹ orŒ.
The battery check lamp (
page 332)
or (
page 335) comes on briefly to in-
dicate that the SmartKey or SmartKey
with KEYLESS-GO batteries are in or-
der.Loss of the SmartKey or SmartKey with
KEYLESS-GO*
If you lose your SmartKey, SmartKey with
KEYLESS-GO or mechanical key, you
should do the following:
Have the SmartKey or SmartKey with
KEYLESS-GO deactivated by an autho-
rized Mercedes-Benz Center.
Report the loss of the SmartKey,
SmartKey with KEYLESS-GO or the me-
chanical key immediately to your car
insurance company.
Have the mechanical lock replaced if
necessary.
Any authorized Mercedes-Benz Center will
be glad to supply you with a replacement.
iVehicles with trunk opening/closing
system*:
You can also lock the vehicle using the
KEYLESS-GO locking/closing switch
(
page 482).
!If the battery check lamp does not come on
briefly during check, the SmartKey or SmartKey
with KEYLESS-GO batteries are discharged.
Replace the batteries (
page 676).
You can obtain the required batteries at any au-
thorized Mercedes-Benz Center.
iIf the batteries are checked within signal
range of the vehicle, pressing button‹ or
Πwill lock or unlock the vehicle accordingly.


341 Controls in detail
Locking and unlocking
Opening doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Locking knob
2Inside door handleFront doors
Pull on door handle2 on the respec-
tive front door to open door.
If door was locked, locking knob1 will
move up.
Rear doors
Pull up locking knob1 on the respec-
tive rear door to unlock door.
Pull on door handle2 on the respec-
tive rear door to open door.
iIf the vehicle has previously been locked
with the SmartKey or KEYLESS-GO*, opening a
door from the inside will trigger the anti-theft
alarm system.
To cancel the alarm, do one of the following:

Insert the SmartKey or SmartKey with
KEYLESS-GO* in the starter switch.

Press button Œ or ‹ on the SmartKey
or SmartKey with KEYLESS-GO*.
In vehicles with KEYLESS-GO*:

Grasp an outside door handle.
The SmartKey with KEYLESS-GO* must be
within 3 ft (1 m) of the vehicle.

Press the KEYLESS-GO* start/stop button
(
page 346).
The SmartKey with KEYLESS-GO* must be
inside the vehicle.
iIf you hear a warning signal you have forgot-
ten to switch off the headlamps before opening
the driver’s door.
In addition the message “Please switch off
lights” appears in the multifunction display.
Switch off the headlamps.
!Failure to switch off the headlamps when
leaving the vehicle may result in a discharged
battery.

342 Controls in detail
Locking and unlocking
Power closing assist for doors and
trunk lid
It is not necessary to slam the door or
trunk lid closed. An electrical power-assist-
ed mechanism draws doors and trunk lid
closed quietly and automatically once door
and trunk lid has been latched. When the
electrical power-assisted mechanism has
stopped, doors and/or trunk can be
re-opened.
Power closing assist for doors: Press
the doors gently past the initial engage
position into the lock.
The doors close automatically.
Power closing assist for trunk lid:
Press the trunk lid gently into its lock.
The trunk closes automatically.For more information on closing the trunk
lid, see “Closing trunk” (
page 480).
Automatic central locking
The doors and the trunk automatically lock
when the ignition is switched on and the
wheels are turning at vehicle speeds of ap-
proximately 9 mph (15 km/h) or more. The
locking knobs in the doors move down.
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
You can deactivate the automatic locking
using the COMAND system (
page 245).
Warning!G
To prevent possible personal injury, always
keep hands and fingers away from the door
or trunk lid opening when closing a door or
the trunk. Be especially careful when small
children are around.
In case of danger, pull the inside or outside
door handle, or pull the trunk lid handle.
To prevent personal injury, never actuate
the closing assist mechanism by tampering
with the door or trunk lid latch.
Warning!G
Only drive with the doors closed. Otherwise,
one or more of the doors could open while
the vehicle is in motion, putting you and/or
others at risk.
Warning!G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.
These fumes may be damaging to your
health.
iThe doors are designed to unlock automati-
cally after an accident if the force of the impact
exceeds a preset threshold.
The vehicle locks automatically when the ignition
is switched on and the wheels are turning at ve-
hicle speeds of approximately 9 mph (15 km/h)
or more. You could therefore lock yourself out
when the vehicle

is pushed or towed

is on a test stand

343 Controls in detail
Locking and unlocking
Locking and unlocking from the inside
You can lock or unlock the doors and the
trunk from the inside using the central
locking or unlocking switch. This can be
useful, for example, if you want to lock the
vehicle before starting to drive.
The fuel filler flap will not be locked or un-
locked with the central locking or unlock-
ing switch, respectively.1Central unlocking switch
2Central locking switch
Locking: Press switch ‹.
If the front passenger door is closed,
the vehicle locks.
Unlocking: Press switch Œ.
The vehicle unlocks.
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
iYou can open a locked door from inside at
any time. Open door only when conditions are
safe to do so.
If the vehicle was previously centrally locked
with the SmartKey or with KEYLESS-GO*, it will
not unlock using the central unlocking switch.
If the vehicle was previously locked with the cen-
tral locking switch:

and the SmartKey or SmartKey with
KEYLESS-GO* is set to factory settings, the
complete vehicle is unlocked when a door is
opened from the inside

and the SmartKey or SmartKey with
KEYLESS-GO* is set to selective settings,
only the door opened from the inside is un-
locked
