2008 MERCEDES-BENZ S600 Owner's Manual

144 Control systems
COMAND telephone*
Placing a call to a call list entry or
COMAND phone book entry
Call up a call list and select an entry
(
page 140).
or
Call up COMAND phone book and se-
lect an entry (
page 147).
Connecting a call: Press n.
Speed dialing
You can save telephone numbers in the
speed-dial preset locations on the mobile
phone and call up the speed-dial presets
(see mobile phone operating instructions).
You can also call up speed-dial numbers
using COMAND.Calling up speed-dial presets using the
COMAND controller
Switching screen to telephone
mode: Call up main telephone menu
(
page 139).
Entering number of a speed-dial pre-
set: Select all the digits in sequence.
Deleting individual digits:
Select) and briefly press n.
Deleting entire number:
Select) and press n until the
number is deleted.
Connecting a call (speed-dial pre-
sets 1 -99): Select “S”.
or
Connecting a call (speed-dial pre-
sets 100 - 999): Select “#” after the
digits
“S”.
In both cases, the telephone connects
the call to the saved telephone num-
ber. If the speed-dial memory contains
no telephone numbers, you will see a
corresponding message.
Deleting message: Press n.
Calling up speed-dial numbers using the
telephone keypad
Switching screen to telephone
mode: Call up main telephone menu
(
page 139).
Single-digit numbers: Press and hold
A- 9 buttons.
or
Single- and two-digit numbers: Enter
number using the A- 9 buttons.
Press s.
or
Three-digit numbers: Enter number
using the A- 9 buttons.
Press #, and then s.
In all three cases, COMAND connects
the call to the saved telephone num-
ber. If the speed-dial memory contains
no telephone numbers, you will see a
corresponding message.
iBy default, the mailbox number is preset in
the speed dial memory unless you have modified
it. For more information on the mailbox
(
page 139).
iOperation during call connection depends
on the speed-dial preset position called up.

145 Control systems
COMAND telephone*
Deleting message: Press n.
Functions during a single-call
connection
Illustration: telephone mode during a call
1Symbol for active telephone con-
nection (also visible in other operating
modes)
2Signal strength display
3To switch hands-free microphone on or
off
4Length of call display
5To send character strings
6To end a call
7Person you are callingSwitching the hands-free microphone
on or off
Switching screen to telephone
mode: Call up main telephone menu
(
page 139).
Switching off microphone:
Select “Mic OFF” and press n.
or
Press F shortcut button.
If the microphone is switched off,
the> symbol appears in the main ar-
ea.
Switching on microphone:
Select “Mic ON”.
or
Press F shortcut button.
The> symbol disappears.
Sending a character string via DTMF
Answering machines or other devices can
be controlled by character strings (e.g. for
remote query functions).
Sending character strings via the DTMF
menu
During a call, select “DTMF”.
The DTMF dialing display appears.
iThe name of the person you are speaking
with can only be seen in display 7 if his or her
telephone number and name have been saved in
the COMAND address book or phone book on
the mobile phone. The telephone number must
also be saved in the same way in which the per-
son you are talking to transmits it.
iThis function is not possible with every mo-
bile phone. If the mobile phone supports the
function, you can use it during the call connec-
tion and also during a call.


146 Control systems
COMAND telephone*
1Back to the call display
2Character entry
3To call up the phone book
Sending individual characters:
Rotateymz or slide omp and select
desired character.
Each character you select can be seen
in the main area and is sent immediate-
ly.
Sending a phone book entry as a
character string: Select “Name”.
Select desired phone book entry.
The entry is immediately sent as a char-
acter string.
Switching back to the call display:
Select “Y”.
Sending character strings via the tele-
phone keypad
Press corresponding button on tele-
phone keypad.
Each character you select is immedi-
ately sent.
Ending an active call
Ending a call: Select “4END” in the
call display.
or
Press t on the telephone keypad or
on the multifunction steering wheel.
The COMAND display will change to
the previously selected display, if appli-
cable.
Transferring a call
From the hands-free system to the
Bluetooth
® headset
The call transfer is controlled by pressing
the PTT button on the Bluetooth
® headset
(see headset operating instructions). Nor-
mally, it is sufficient to press the PTT but-
ton once, but under certain circumstances
you may have to press it a second time.
Once the call has been transferred to the
Bluetooth
® headset, all the functions will
be available to you which are described in
the “Functions during a single-call connec-
tion” section (
page 145).
Exception: “Switching the hands-free mi-
crophone on or off” function (
page 145).
iTelephone numbers containing the + char-
acter may impair the function.
iThe + character may impair the function.
iThe use of a Bluetooth® headset requires
Bluetooth® to be activated and the Bluetooth®
headset to be authorized (
page 239).


147 Control systems
COMAND telephone*
From the Bluetooth® headset to the
hands-free system
On most Bluetooth
® headsets, you press
the PTT button on the headset twice quick-
ly to transfer the call (see headset operat-
ing instructions).
From the hands-free system to the mo-
bile phone
If the mobile phone has a folding up-
per section: Flip upper section open.
Take mobile phone out of cradle.
The “No telephone inserted” message
appears on the COMAND display. Sub-
sequent operation is only possible us-
ing the mobile phone.From the mobile phone to the
hands-free system
Insert mobile phone into cradle.
Once the call has been transferred to
the hands-free feature, all the functions
will be available to you which are de-
scribed in the “Functions during a sin-
gle-call connection” section
(
page 145).
COMAND phone book
The COMAND phone book contains both
the COMAND address book entries and
mobile phone entries that have at least
one telephone number.
The COMAND address book entries are
permanently available even when a mobile
phone is not inserted in the cradle.
When the mobile phone is inserted in the
cradle, COMAND will read the phone book
entries in the mobile phone and compares
them with the COMAND address book en-
tries. If any of the telephone numbers of a phone
book entry in the mobile phone are the
same as an address book entry, COMAND
will only display the address book entry.
If the entries are not the same, the CO-
MAND phone book will show the phone
book entry in the mobile phone.
Calling up the COMAND phone book
Select “Telephone”
“Telephone”

“Telephone”
“Name”.
The COMAND phone book appears.


148 Control systems
COMAND telephone*
Illustration: a phone book with name dis-
play and smart speller activated
1Category symbol
2Upper entry from address book (with-
out category symbol)
3Symbol + for several telephone num-
bers (subentries) under the main entry
4Symbol for summarized entries
from the mobile phone with the same
name but different telephone numbers
5Smart speller
6Voice entry symbol
7To close the phone bookEntries with category symbol 1 come
from the mobile phone. The following cate-
gory symbols are possible:

= symbol for “Mobile” category

= symbol for “Home” category

= symbol for “Work” category

= symbol for “Fax” category

= symbol for “Pager” category

= symbol for “Main” category or for
unknown category or for phone entries
that are saved on the SIM card of a
GSM mobile phone
Entries without a category symbol or with
the symbol come from the COMAND
address book.
Entries with the symbol contain a voice
entry. Voice entries can be added to the
address book (
page 232). This function
is available in vehicles with Voice Control*.Switching between the smart speller
and the list
Switching from the smart speller to
the list: Slide mq repeatedly or press
n until the smart speller is hidden.
or
Rotate ymz or slide omp and
select?.
The smart speller is hidden.


149 Control systems
COMAND telephone*
Illustration: list of phone book entries with
name display and hidden smart speller
1Back to smart speller
2To switch phone book display (“123” or
“ABC”)
3Symbol + for several telephone num-
bers (subentries) under the main entry,
subentry list is closed
4To call up options
5Symbol / for open subentry list
6List of phone book entries
7Subentry list with category symbols
and telephone numbersSwitching from the list to the smart
speller: Select “Back” from the list.
or
Press back button L in the center
console (
page 86).
Changing phone book display in the
list: Select “123” or “ABC”.
The screen changes to telephone num-
ber or name display.Closing the COMAND phone book
In the smart speller, select “Back”.
or
Press back button L in the center
console (
page 86).
Selecting an entry in the COMAND
phone book
Selecting entries using the smart speller
Switch from the list to the smart speller
if necessary.
Changing smart speller language:
Select !.
Select desired language.
iThe following options are available under
“Options” menu item 4:

Displaying details about an entry
(
page 150)

Creating a new entry in the address book
(
page 151)

Deleting an entry (page 152)

Saving a phone book entry from mobile
phone in the address book (
page 152)

Adding a telephone number to an address
book entry (
page 154)


150 Control systems
COMAND telephone*
Changing smart speller character
set: Select #.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.
Entering characters: Select the char-
acters of the entry you are searching
for one by one.
Deleting individual characters: Se-
lect ) and briefly press n.
Each time you enter or delete a charac-
ter, the closest match will be displayed
at the top of the list.
Deleting an entire entry: Select )
and press and hold n until the entry is
deleted.
Canceling search: Switch from the
smart speller to the list.
The entry at the top of the list is auto-
matically highlighted.Selecting using the list
If necessary, switch from the smart
speller to the list.
Rotate ymz or slide qmr until the de-
sired entry is highlighted.
Selecting subentries
S e l e c t a n e n t r y w i t h t h e + symbol and
press n.
The + symbol changes to / and the
subentries are displayed.
Rotate ymz or slide qmr until the de-
sired subentry is highlighted.
Displaying details of an entry
COMAND can also show a shortened entry
in its entirety. For entries featuring suben-
tries, the detailed view is only available for
the subentries and not for the main entry.
Select entry (page 149).
Select “Options”
“Details”.
The detailed view appears.
Closing detailed view: Slide qmr or
omp or press n or back button L
in the center console (
page 86).
Starting to dial the number of an entry
Select entry (page 149).
Press n.
or
Press s on the telephone keypad.
A list appears if the entry contains sub-
entries.
Select desired subentry.
Press n again.
or
Press s on the telephone key-
pad.


151 Control systems
COMAND telephone*
Assigning a New Entry in the Address
Book
Select “Options”
“New Entry” in the
COMAND phone book list.
Selecting a number category:
Select a category, e.g. “Home”.
Selecting a telephone category:
Select a category, e.g. “Land Line”.
Confirming selection: Select “Save”.
The input menu appears with the data
fields.1Data field
2Input mark (cursor)
3Input charactersChanging data field: Slide qmr re-
peatedly until desired data field is high-
lighted.
or
Select [ or ] repeatedly until de-
sired data field is highlighted.
Entering data into a field: Select all
characters one by one from the input
characters line 3.
Toggling upper and lower case for
the input characters: Select & or
(.
Changing language for the input
characters: Select !.
Select desired language.
Changing character set for the input
characters: Select #.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.
Displaying special characters as in-
put characters: Select !
“Sym-
bols”.
Returning input characters to nor-
mal characters: Select !
the
desired language.
Moving cursor in the data field:
SelectY or Z.
iThis function is used to create a new entry in
the address book and to enter the data (first
name, last name and telephone number) manu-
ally.
