2008 MERCEDES-BENZ S600 Owner's Manual

208 Control systems
COMAND navigation system (route guidance)
Preparation phase
COMAND prepares you for the upcoming
driving maneuver. Based on the example
display below, the driving maneuver is an-
nounced with the “Prepare to turn left”
message. The display is not split and
shows the map over the full screen.
1Point at which the driving maneuver
takes place (light blue dot)
2Route (highlighted blue)
3Current vehicle position; the triangle
points in the vehicle’s direction of trav-
elAnnouncement phase
COMAND announces the next driving ma-
neuver. Based on the example display be-
low, the driving maneuver is announced
700 feet in advance with the “Turn left in
700 feet to your destination” message.
The display is divided in two. In the left
half, you see the normal map view. In the
right half, there is either an enlarged view
of the area surrounding the intersection
(intersection zoom) or simply a symbol for
the next driving maneuver.
The following example illustration shows
the intersection zoom in the right half.1Next road
2Driving maneuver (turn left)
3Graphical representation of the dis-
tance to the driving maneuver
4Point at which the driving maneuver
takes place (light blue dot, shown in
both the left and right displays)
5Information about distance to the next
driving maneuver
6Route (highlighted in blue; shown in
both the left and right displays)
7Current vehicle position; the triangle in-
dicates the vehicle’s direction of travel
(shown in both the left and right dis-
plays)
8Street on which you are currently driv-
ing, if included on the digital map
9Destination
iThe filled-in section of distance graphic 3
gets shorter the nearer you get to the announced
driving maneuver.

209 Control systems
COMAND navigation system (route guidance)
Maneuver phase
COMAND announces the next driving ma-
neuver. Based on the example display be-
low, the driving maneuver is announced
150 feet in advance with the “Now turn
left” message. The display is also split into
two halves, as for the announcement
phase.
1Graphical representation of the dis-
tance to the next driving maneuver
2Information about distance to the next
driving maneuverExample of a display without driving
maneuvers
1Main destination <
2Stopover = (only visible if a stopover
has been entered)
3Route (highlighted blue)
4Current vehicle position; the triangle in-
dicates the vehicle’s direction of travel
5Set map orientation – for an explana-
tion and settings, see (
page 169)
6Set scale – for an explanation and set-
tings, see (
page 167)Destination or destination area
reached
Once you have reached your destination,
you will hear the announcement “You have
reached the destination”. For certain POIs
(airports or highway junctions), you will
hear the announcement “You have reached
the destination area”. In addition, you will
see a corresponding display and route
guidance is automatically ended.
1Destination on the map
2Destination flag
iOnce the maneuver is completed, COMAND
automatically switches back to the non-split
screen.

210 Control systems
COMAND navigation system (route guidance)
Partially digitized areas If the destination is within a partially
digitized area
COMAND guides you through fully digitized
areas for as long as possible. Route guid-
ance is conducted in the usual manner, i.e.
with navigation announcements and route
guidance displays.
Before the vehicle reaches a partially digi-
tized area, COMAND notifies you of this
with the following announcements:

“Be prepared to enter an area where
turn by turn guidance cannot be provid-
ed.”

“In 700 feet you will enter an area
where turn by turn guidance cannot be
provided.”

“You are about to enter an area where
turn by turn guidance cannot be provid-
ed.”Route guidance within a partially digi-
tized area
If you start route guidance in this type of
area, you will hear the following announce-
ment: “You are currently in an area where
turn by turn guidance cannot be provided.”
Route guidance is provided by means of a
direction arrow showing the compass
heading to the destination. COMAND will
not generate automatic navigation an-
nouncements.
If you try to call up an announcement man-
ually, (page 213) you will hear the an-
nouncement “You are currently in an area
where turn by turn guidance cannot be pro-
vided.”.
iThe digital map may contain areas that are
only partially digitized although they are within a
digitized region.
Warning!G
Due to incomplete digitization, the route
shown on the map may differ from the actual
road/traffic situation.
If you follow the route shown on the map, for
example, it is possible that you could drive
the wrong way down a one-way street or
that a street cannot be driven on.
When using route guidance in a partially dig-
itized area, you must therefore be sure to
observe all relevant traffic regulations and
the course of the road.
All relevant traffic regulations and the
course of the road always take priority over
the route shown on the map.
iThe indicated distance can be seen here by
way of example. In reality, it may be different.
iWhen you call up the route info to this type
of destination, (
page 215) the following data
shown there may differ from the actual situation:

Distance to the destination

Estimated driving time to the destination

Estimated arrival time

211 Control systems
COMAND navigation system (route guidance)
During route guidance, the display is divid-
ed. On the right-hand side you will see the
direction arrow showing the compass
heading to the destination.
On the left-hand side of the display you will
see the map with the suggested route. The
suggested route is highlighted blue. How-
ever, it may not be possible to follow the
suggested route because, for example, the
road is closed or not open for car traffic.
If, during route guidance, COMAND leads
you back into a fully digitalized area, route
guidance will simply continue in the usual
manner.Off-road and off-map
Route guidance to an off-road
destination
COMAND can guide you to destinations
within the area covered by the digital map,
even if a destination is not located at a
road known to the system.These destinations are shown as off-road
destinations, which you can enter using
the map, for example.
In these cases, COMAND guides you for as
long as possible with navigation announce-
ments and displays on roads known to the
system.
Shortly before you reach the last known
the point to leave the digitized road net-
work, you will hear the announcement “The
destination is nearby. Follow the arrow on
the display”.
You will then see an arrow that indicates
the direction to the off-road destination.
When the off-road destination is close to
the road, “Area of dest. reached” appears
in addition below the arrow.
The section of the route from the last
known point on the map to the off-road
destination is indicated with a dashed line
after a certain length. It simply shows the
direction to the off-road destination with-
out taking account of any type of obstacles
in the way.
Warning!G
The COMAND navigation system may direct
you to off-road routes that your vehicle may
not be capable of traversing through without
damaging your tires, wheels or vehicle. It is
the driver’s sole responsibility to determine
the suitability of the route. Off-road routes
may be of varying conditions and their ap-
propriateness for use may be affected by
various factors such as time of day, time of
year and immediate weather conditions that
cannot be judged or taken into consider-
ation by the COMAND system.

212 Control systems
COMAND navigation system (route guidance)
1Current vehicle position; the triangle in-
dicates the vehicle’s direction of travel
2Off-road section of the route
3Off-road destination
4Direction arrow, shows compass head-
ing to destination
On the off-road section of the route, direc-
tion arrows showing the compass heading
to the destination guide you. You will also
see the “Direction to destination” display.Route guidance from an off-road
location to a destination
If there is no road available on map at cur-
rent position of the car, vehicle is off road.
COMAND is also able to guide you to a des-
tination from such a location.
At the start of the route guidance, you will
see the “Off Road” message and a direc-
tion arrow. The direction arrow shows the
compass heading to the actual destina-
tion.
The route is highlighted blue from the near-
est road known to the system.
As soon as the vehicle is back on a road
known to the system, route guidance con-
tinues in the usual way.
Route guidance from an off-map
location to a destination
If the vehicle position is outside the area
covered by the digital map, then the vehi-
cle is in an off-map location.
COMAND is also able to guide you to a des-
tination from such a location.At the start of the route guidance, you will
see the “Off Map” message and a direction
arrow. The direction arrow shows the com-
pass heading to the actual destination.
The route is highlighted blue from the near-
est road known to the system.
As soon as the vehicle is back on a road
known to the system, route guidance con-
tinues in the usual way.
Off-road during route guidance
The road layout may differ from the data on
the digital map, due to road construction
measures, for example.
In such cases, the system cannot allocate
the vehicle’s position to the digital map
and the vehicle is therefore in an off-road
position.
The “Off Road” message and an arrow
showing the compass heading to the desti-
nation appear on the display.
As soon as the system can allocate the ve-
hicle position’s to the map again, route
guidance continues in the usual way.

213 Control systems
COMAND navigation system (route guidance)
Navigation announcements
Route guidance is already active.Calling up a current announcement:
Select “Navi”
6.
or
Press P favorite button if the button
has been programmed with this func-
tion (
page 238).
Canceling navigation message:
Briefly press F shortcut button dur-
ing an announcement.
Switching off navigation messages:
Press and hold F during an an-
nouncement until the announcement is
switched off.
You will see the message “The driving
instructions have been muted.” for a
short while.
Switching navigation announce-
ments back on manually:
Select “Navi”
6.
Adjusting volume of the messages:
Adjust the volume during an automatic
announcement (
page 96).
or
Call up an announcement manually us-
ing “Navi”
6 and adjust the vol-
ume (
page 96).
Warning!G
Navigation announcements are intended to
direct you while driving without diverting
your attention from the road and driving.
Please always use this feature instead of
consulting the map display for directions.
Consulting the symbols or map display for
directions may cause you to divert your at-
tention from driving and increase your risk
of an accident.
iIf Russian or Chinese is set as the system
language, the navigation announcements are in
English. You will find how to set the system lan-
guage on (
page 238).
Navigation announcements are muted during
telephone calls. You can, however, call up a cur-
rent announcement at any time. You can also
call up a current announcement at any time if
you have missed an announcement.
iYou will find the button programming on
(
page 238).
iThe announcements remain switched off
even if you start a new route guidance or if
COMAND is switched off/on with theo but-
ton.
If you switch COMAND off by removing the
SmartKey from the starter switch and then
switch the ignition back on after more than
3 minutes, the announcements are automatical-
ly switched back on.

214 Control systems
COMAND navigation system (during route guidance)
Cancel route guidance
Select “Destination”
“Cancel Route
Guidance” in map view with the menu
system displayed (
page 166).
Continuing cancelled route guidance
Select “Destination”
“Continue
Route Guidance” in map view with the
menu system displayed (
page 166).
COMAND calculates the route.
Route browser
Select “Route”
“Route Browser” in
map view with the menu system dis-
played (
page 166).
The route browser appears.
1Highlighted route section
2Current vehicle position; the triangle in-
dicates the vehicle’s direction of travel
3Information about the highlighted route
section
Displaying next or previous route
section: Select “Next” or “Previous”.
Increasing or reducing size of the
map: Select; or :.
Closing route browser:
Select “Back”.
iThe route browser shows an overview of the
route. You can use the route browser to move
along the route section by section and view infor-
mation about and details of each section of the
route.
iThe information 3 about the marked route
section shows the street name and the length of
the route section. Marked route section 1 is al-
ways highlighted in white and outlined in red.

215 Control systems
COMAND navigation system (during route guidance)
Displaying route information
Select “Route”
“Route Info” in map
view with the menu system displayed
(
page 166).
The route information appears.
Example display with main destination and
stopover
1Distance to the destination
2Symbol = for stopover
3Abbreviation for province (CDN) or
state (USA)
4Town/city
5Street
6Symbol < for main destination
7Estimated driving time to the destina-
tion
8Estimated arrival time
Closing route info: Slide omp or
press back button L in the center
console (
page 86).
iCOMAND uses the time set in COMAND as
the basis for calculating the estimated arrival
time. The clock must be set correctly in
COMAND (
page 235). The calculation of the
estimated arrival time does not additionally take
into account whether Daylight Saving Time or
standard time is applicable at the destination. If
the destination is in a different time zone, arrival
time display
8 is in local time. This is indicated
by “LT” in the display.
The following data cannot be seen until the route
calculation has been completed:

Distance to destination 1

Estimated arrival time 8

Estimated remaining travel time 7
If the destination is located within a partially dig-
itized area, the following data may differ from the
facts:

Distance to destination 1

Estimated arrival time 8

Estimated remaining travel time 7
