2006 MERCEDES-BENZ R350 Owner's Manual

56 Getting startedDrivingParking brake
1Parking brake pedal
2Release handle

Release the parking brake by pulling on
release handle2.
The warning lamp; (USA only) or
3(Canada only) in the instrument
cluster goes out.
Driving
Depress the brake pedal.
The gear selector lever can now be
used.

Shift automatic transmission toD orR
(page 198).

Release the brake pedal.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could release the
parking brake, which could result in an acci-
dent and/or serious injury.
iWait for the gear selection process to
complete before setting the vehicle in
motion.iShifting from gear positionP to posi-
tion R, N, orD is only possible with the
brake pedal depressed. Without the
brake pedal depressed, the gear selec-
tor lever can be moved, but the parking
pawl remains engaged, not allowing
shifting to occur.

57 Getting started
Driving

Carefully depress the accelerator
pedal.
Once the vehicle is in motion, the auto-
matic central locking system engages
and the locking knobs drop down.After a cold start, the automatic transmis-
sion shifts at a higher engine revolution.
This allows the catalytic converter to reach
its operating temperature earlier.
For more information, see “Driving instruc-
tions” (
page 331).
iThe automatic door lock feature can be
deactivated (
page 188).
iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.!If you hear a warning signal and the
message
Release parking brake

appears in the multifunction display
when driving off, you have forgotten to
release the parking brake.
Release the parking brake.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.Warning!
G
It is dangerous to shift the gear selector
lever out ofP orN if the engine speed is
higher than idle speed. If your foot is not
firmly on the brake pedal, the vehicle could
accelerate quickly forward or in reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.
!Shift the automatic transmission to
positionP orR only when the vehicle is
stopped in order to avoid damaging the
transmission.!Do not run cold engine at high engine
speeds. Running a cold engine at high
engine speeds may shorten the service
life of the engine.!Simultaneously depressing the acceler-
ator pedal and applying the brake re-
duces engine performance and causes
premature brake and drivetrain wear.

58 Getting startedDrivingSwitching on headlamps
For more information on headlamps, see
“Lighting” (
page 147).
Low beam headlamps
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
Exterior lamp switch1 Off
2Low beam headlamps on
Turn the exterior lamp switch to
positionB.
The low beam headlamps come on.High beam
The combination switch is located on the
left of the steering column.
Combination switch1High beam
2High beam flasher
Push the combination switch in direc-
tion of arrow1.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 24).
For more information on headlamps, see
“Combination switch” (
page 151).
Turn signals
The combination switch is located on the
left of the steering column.Combination switch1Turn signals, right
2Turn signals, left
Press combination switch in direction
of arrow1 or2.
The corresponding turn signal indicator
lampLorK in the instrument
cluster flashes.

59 Getting started
Driving
The combination switch resets automati-
cally after major steering wheel move-
ment.
Windshield wipers
The combination switch is located on the
left of the steering column.Combination switch1Single wipe
Wiping with windshield washer fluid
2Switching on windshield wipers
Switch on the ignition (
page 38).Switching on windshield wipers

Turn the combination switch to the de-
sired position depending on the inten-
sity of the rain.
0Windshield wipers off
IIntermittent wiping
IINormal wiper speed
IIIFast wiper speed
iTo signal minor directional changes,
move combination switch to point of
resistance and release. The corre-
sponding turn signal flashes three
times.
!Do not operate the windshield wipers
when the windshield is dry. Dust that
accumulates on a windshield might
scratch the glass and/or damage the
wiper blades when wiping occurs on a
dry windshield. If it is necessary to op-
erate the windshield wipers in dry
weather conditions, always operate the
windshield wipers with windshield
washer fluid (
page 60).

60 Getting startedDrivingIntermittent wiping
Intermittent wiping interval is dependent
on wetness of windshield.
Set the wiper switch to positionI.
After the initial wipe, pauses between
wipes are automatically controlled by the
rain sensor.
Single wipe

Press the combination switch briefly in
direction of arrow1 to the resistance
point.
The windshield wipers wipe one time
without washer fluid.Wiping with windshield washer fluid

Press the combination switch in direc-
tion of arrow1 past the resistance
point.
The windshield wipers operate with
washer fluid.
For information on filling up the washer
reservoir, see “Windshield / rear window
washer system and headlamp cleaning
system*” (
page 352).
!Do not leave windshield wipers in inter-
mittent setting when the vehicle is tak-
en to an automatic car wash or during
windshield cleaning. Wipers will oper-
ate in the presence of water sprayed on
the windshield, and windshield wipers
may be damaged as a result.
iIntermittent wiping is interrupted when
the vehicle is at a standstill and a front
door is opened.
Intermittent wiping will be continued
when

all doors are closed
and


the automatic transmission is set to
position D or R
or


the wiper setting is changed using
the combination switch
iTo prevent smears on the windshield,
wipe with windshield washer fluid every
now and then even when it is raining.

61 Getting started
Driving
Rear window wiper/washer
The combination switch is located on the
left of the steering column.Combination switch1Rear window wiper switch
2Wiping rear window with washer fluid
3Intermittent wiping
4Rear window wiper off
5Wiping rear window with washer fluid
!If anything blocks the windshield
wipers (leaves, snow, etc.), switch
them off immediately.

For safety reasons, stop the vehicle
in a safe location and

remove the SmartKey from the
starter switch
or


turn off the engine by pressing
the KEYLESS-GO* start/stop
button and open the driver’s
door (with the driver’s door
open, starter switch is in
position0, same as with
SmartKey removed from starter
switch)
before attempting to remove any
blockage.


Remove blockage.


Turn the windshield wipers on
again.
If the windshield wipers fail to function
at all in combination switch positionI,


set the combination switch to the
next higher wiper speed


have the windshield wipers
checked at the nearest authorized
Mercedes-Benz Light Truck Center

62 Getting startedDriving6Rear window wiper indicator
Switch on the ignition (
page 38).
Activating intermittent wipe

Turn rear window wiper switch 1 to
position3 (
page 61).
In the lower multifunction display you
will see symbol6, indicating that the
rear window wiper is activated.Deactivating intermittent wipe

Turn rear window wiper switch 1 to
position4 (
page 61).
Symbol6for the rear window wiper is
cleared from the lower multifunction
display, indicating that the rear window
wiper is deactivated.
Wiping with windshield washer fluid

Turn rear window wiper switch 1 to
position 2 or 5 (
page 61).
The wiper operates with washer fluid.

Hold rear window wiper switch 1 in
position 2 or 5 (
page 61) until the
rear window is clean.
For information on filling up the washer
reservoir, see “Windshield / rear window
washer system and headlamp cleaning
system*” (
page 352).
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.


The engine electronics may not be
operating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.

Have the problem repaired by an
authorized Mercedes-Benz Light Truck
Center as soon as possible.
iThe rear window wiper engages auto-
matically when the automatic transmis-
sion is shifted to positionR with the
windshield wipers switched on.

63 Getting started
Driving
The coolant temperature is above
248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.
Stop the vehicle as soon as possible in
a safe location and turn off the engine.
Allow engine and coolant to cool.

Check the coolant level and add cool-
ant if necessary (
page 351).In case of accident
If the vehicle is leaking fuel:

Do not start the engine under any
circumstances.

Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be de-
termined:

Notify an authorized Mercedes-Benz
Light Truck Center.
If no damage can be determined on the


major assemblies


fuel system


engine mount:

Start the engine in the usual manner.
