2006 MERCEDES-BENZ R350 Owner's Manual

528 Technical dataFuels, coolants, lubricants, etc.Windshield washer and headlamp cleaning* system
Both the windshield washer and headlamp
cleaning* system are supplied from the
windshield washer fluid reservoir.
The windshield and headlamp washer fluid
reservoir has a capacity of approx.
8.2 US qt (7.8 l).
Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer
solvent/antifreeze, depending on am-
bient temperatures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:


1 part “MB SummerFit” to 100 parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1gal [4.0l] water)
For temperatures below freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and commercially avail-
able premixed windshield washer
solvent / antifreeze:


1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent)
Warning!
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.

529 Technical terms
ABS
(A
ntilock B
rake S
ystem)
Prevents the wheels from locking up
during braking so that the vehicle can
continue to be steered.
Accessory weight
(
page 385)
ADS
(Adaptive D
amping S
ystem)
Automatically adapts the optimum sus-
pension damping to prevailing driving
conditions.
Airmatic*
Automatically selects the optimum sus-
pension tuning and ride height for your
vehicle. Airmatic consists of two com-
ponents:


Adaptive Damping System


Vehicle level control
Air pressure
(
page 385)Alignment bolt
Metal pin with thread. The centering
pin is an aid used when changing a tire
to align the wheel with the wheel hub.
Aspect ratio
(
page 385)
Bar
(page 386)
BAS
(Brake A
ssist S
ystem)
System for potentially reducing braking
distances in emergency braking situa-
tions. The system is activated when it
senses an emergency based on how
fast the brake is applied.
Bead
(
page 386)
Bi-Xenon headlamps*
Headlamps which use an electric arc as
the light source and produce a more
intense light than filament headlamps.
Bi-Xenon headlamps produce low
beam and high beam.CAC
(C
ustomer A
ssistance C
enter)
Mercedes-Benz customer service
center, which can help you with any
questions about your vehicle and
provide assistance in the event of a
breakdown.
CAN system
(C
ontroller A
rea N
etwork)
Data bus network serving to control
vehicle functions such as door locking
or windshield wiping.
Cockpit
All instruments, switches, buttons and
indicator / warning lamps in the
passenger compartment needed for
vehicle operation and monitoring.
Cold tire inflation pressure
(
page 386)

530 Technical termsCollapsible tire
An especially compact spare tire that
must be inflated with a provided air
pump before using. It should only be
used to bring the vehicle to the nearest
service station.
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to ad-
just settings.
Cruise control
Driving convenience system for
automatically maintaining the vehicle
speed set by the driver.
Curb weight
(
page 386)
DOT
(Department o
f Transportation)
(
page 386)Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine
produced.
Engine oil viscosity
Measurement for the inner friction (vis-
cosity) of the oil at different tempera-
tures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can tol-
erate without becoming viscous, the
better the viscosity.
ESP
®(Electronic S
tability Pr
ogram)
Improves vehicle handling and direc-
tional stability.
ETD
(E
mergency T
ensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the sys-
tem's threshold to tighten the seat
belts.
->SRSFSS PLUS (Canada vehicles)
(F
lexible S
ervice S
ystem PLUS)
Maintenance service indicator in the
speedometer display that informs the
driver when the next vehicle mainte-
nance service is due. FSS evaluates en-
gine temperature, oil level, vehicle
speed, engine speed, distance driven
and the time elapsed since your last
service, and calls for the next mainte-
nance service accordingly.
GAWR
(G
ross A
xle W
eight R
ating)
(
page 386)
Gear range
Number of gears which are available to
the automatic transmission for shifting.
The automatic gear shifting process
can be adapted to specific operating
conditions using the gear selector
lever.

531 Technical terms
GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special re-
ceivers. Employs CD or DVD digital
maps for navigation.
GVW
(G
ross V
ehicle W
eight)
(
page 386)
GVWR
(Gross V
ehicle W
eight R
ating)
(
page 386)
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision, in-
cluding the tachometer, speedometer,
engine temperature and fuel gauge.Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the vehi-
cle and should not be used for normal
acceleration needs.
Kilopascal (kPa)
(
page 386)
Line of fall
The direct line that an object moves
downhill when influenced by the force
of gravity alone.
Locking knob
Knob on the door which indicates
whether the door is locked or un-
locked. Pushing the locking knob down
on an individual door from inside will
lock that door.Maintenance System (U.S. vehicles)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. The Maintenance
system tracks distance driven and the
time elapsed since the last mainte-
nance service, calculates other mainte-
nance service work required, and calls
for the next service accordingly.
Maximum load rating
(
page 387)
Maximum loaded vehicle weight
(page 387)
Maximum tire inflation pressure
(page 387)
Modular COMAND System
Information and operating center for
vehicle sound and communications
systems, including the radio and the ra-
dio and navigation system, as well as
for other optional equipment (CD
changer, telephone, etc.).

532 Technical termsMemory function*
Used to store three individual seat,
steering wheel and mirror positions.
MON
(M
otor O
ctane N
umber)
The Motor Octane Number for gasoline
as determined by a standardized meth-
od. It is an indication of a gasoline's
ability to resist undesired detonation
(knocking). The average of both the
MON (Motor Octane Number) and
->RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.
Multifunction display
The display field in the instrument clus-
ter used to present information provid-
ed by the control system.
Multifunction steering wheel
Steering wheel with buttons for operat-
ing the control system.Normal occupant weight
(
page 387)
Overspeed range
Engine speeds within the red marking
on the tachometer dial. Avoid this en-
gine speed range, as it may result in se-
rious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Occupant distribution
(page 387)
Parktronic (Parking assist)*
System which uses visual and acoustic
signals to assist the driver during park-
ing maneuvers.
Poly-V-belt drive
Drives engine-components (alternator,
AC compressor, etc.) from the engine.Power train
Collective term designating all compo-
nents used to generate and transmit
motive power to the drive axles, includ-
ing


engine


clutch / torque converter


transmission


transfer case


drive shaft


differential


axle shafts / axles
PRE-SAFE
®*
(Pre
ventive Occupant Safe
ty System)
Vehicles equipped with PRE-SAFE
®*
take preventive measures when the
system senses certain driving dynam-
ics suggesting a possible accident.
Production options weight
(
page 387)

533 Technical terms
Program mode selector switch
Used to switch the automatic transmis-
sion between standard operation (S)
and comfort operation (C).
PSI
(P
ounds p
er s
quare i
nch)
(
page 387)
Recommended tire inflation pressure
(page 387)
REST
(Residual E
ngine H
eat U
tilization)
Feature that uses the engine heat
stored in the coolant to heat the vehi-
cle interior for a short time after the en-
gine has been turned off.
Restraint system
Seat belts, belt tensioner, air bags and
child seat restraint systems. As inde-
pendent systems, their protective func-
tions complement one another.
Rim
(
page 387)RON
(R
esearch O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line's ability to resist undesired detona-
tion (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.
Sidewall
(
page 387)
SRS
(Supplemental R
estraint S
ystem)
Seat belts, emergency tensioning de-
vice and air bags. Though independent
systems, they are closely interfaced to
provide effective occupant protection.Tele Aid System*
(T
elematic A
larm I
dentification on
D
emand)
The Tele Aid system consists of three
types of response: automatic and man-
ual emergency, roadside assistance
and information. Tele Aid is initially ac-
tivated by completing a subscriber
agreement and placing an acquain-
tance call.
The Tele Aid system is operational pro-
vided that the vehicle’s battery is
charged, properly connected, not dam-
aged and cellular and GPS coverage is
available.
Telematics*
A combination of the terms “telecom-
munications” and “informatics”.
Tightening torque
Force times lever arm (e.g. a wheel
wrench) with which threaded fasteners
such as wheel bolts are tightened.

534 Technical termsTIN
(T
ire I
dentification N
umber)
(
page 387)
Tire load rating
(page 387)
Tire ply composition and material used
(page 388)
Tire speed rating
(page 388)
Traction
(page 388)
Transfer case
Speed of rotation / torque converter
that works together with the ->auto-
matic transmission.
Tread
(page 388)Treadwear indicators
(
page 388)
TWR
(Tongue W
eight R
ating)
(
page 388)
Uniform Tire Quality Grading Standards
(page 388)
Vehicle capacity weight
(page 388)
Vehicle level control
The ground clearance of the vehicle is
automatically controlled according to a
selected setting and speed.The driver
can set the ground clearance manually
for example on very rough roads.
VIN
(Vehicle I
dentification N
umber)
The number set by the manufacturer
and placed on the body to uniquely
identify each vehicle produced.

535 Index
A
ABS 97, 529
ABS control 97
Malfunction indicator lamp 404
Messages in display 418
Warning lamp 404
Accelerator position, automatic
transmission 203
Accessory weight 385, 529
Accident
In case of 63
Activating
Air circulation mode 242
Air conditioning (cooling) 226
Air recirculation mode 225, 239
Anti-theft alarm system 105
Central locking (control system) 188
Defrosting 223
Easy-entry/exit feature* 189
Electric air pump 483
ESP
®
102
Exterior headlamps 58
Hazard warning flasher 154
Headlamps 58
High beams 151
Ignition 38Immobilizer 66, 104
Rear window defroster 215
Rear window wiper 62
Residual heat 243
Residual heat* 228
Seat heating* 142
Tow-away alarm 107
Warning indicators (Parktronic*) 276
Windshield wipers 59
Adding
Coolant 351
Engine oil 349
Additional turn signal lamps
Replacing bulbs 466
Adjusting 42
Air distribution 222, 236
Air volume 222, 237
Backrest tilt 44
Exterior rear view mirror 48
Head restraint height 44
Head restraint tilt 45
Instrument cluster illumination 158
Interior rear view mirror 48
Mirrors 47
Multicontour seat* 136
Seat cushion depth 136Seat cushion tilt 44
Seat fore and aft adjustment 43
Seat height 44
Seats 42
Steering column height 47
Steering wheel 45
Adjusting steering column in or out 47
Adjusting steering column up or down 47
Air bags 71
Children 72
Front 75
Passenger 75
Safety guidelines 74
Side impact 76
Window curtain 76
Air conditioning
Turning off 226
Turning on 226
Air conditioning refrigerant 523
Air distribution
Adjusting 222, 236
Air pressure 385, 529
Air pressure see Tire inflation pressure
Air pump, electric
Turning on 483
