DTC P1298:
YES
NO
YES
NO YES
NO
11-162PGM-FI System
DTC Troubleshooting (cont’d)
ELD 3P CONNECTOR
IG1 (YEL) ELD 3P CONNECTOR
ECM/PCM CONNECTOR A (44P) ELD (ORN)
ELD (ORN)
ELD Circuit High Voltage
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).1. Turn the ignition switch to ON (II).
2. Check the ELD in the DATA LIST with the HDS.
Go to step 3.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the ELD and the ECM/PCM.
3. Turn the ignition switch to LOCK (0).
4. Disconnect the ELD 3P connector.
5. Turn the ignition switch to ON (II).
6. Measure the voltage between ELD 3P connector terminal No. 1 and body ground.
Go to step 7.
Check the No. 3 ALTERNATOR (10 A) fuse in
the under-dash fuse/relay box. If the fuse is OK,
repair open in the wire between the No. 3
ALTERNATOR (10 A) fuse and the ELD, then go to
step 13. 7. Turn the ignition switch to LOCK (0).
8. Jump the SCS line with the HDS.
9. Disconnect ECM/PCM connector A (44P).
10. Check for continuity between ELD 3P connector terminal No. 3 and ECM/PCM connector terminal
A23.
Go to step 11.
Repair open in the wire between the ECM/
PCM (A23) and the ELD, then go to step 13.
Wire side of female terminals Wire side of female terminals
Terminal side of female terminals
Is 0.2 A or less indicated?
Is there battery voltage? Is there continuity?
08/08/21 14:20:24 61SNR030_110_0162
ProCarManuals.com
DYNOMITE -2009-

(#'

)
µ
µ µ
µ
DTC P1549:
YES
NO YES
NO
11-164PGM-FI System
DTC Troubleshooting (cont’d)
Charging System High Voltage
NOTE:
 Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
 If a high voltage battery (24 V, etc.) connected to the vehicle, this DTC can be stored.
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine.
4. Check under these conditions: A/Coff
 Headlights off
 Rear window defogger off
5. Hold the engine speed at 2,000 rpm (A/T in P or N, M/T in neutral) for 1 minute.
6. Check for Temporary DTCs or DTCs with the HDS.
Replace the alternator (see page 4-34), then
go to step 7.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the alternator and the under-hood fuse/relay
box.
7. Turn the ignition switch to ON (II).
8. Reset the ECM/PCM with the HDS.
9. Do the ECM/PCM idle learn procedure (see page 11-310).
10. Start the engine.
11. Check under these conditions: A/Coff
 Headlights off
 Rear window defogger off
12. Hold the engine speed at 2,000 rpm (A/T in P or N, M/T in neutral) for 1 minute. 13. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the alternator and the under-hood
fuse/relaybox,thengotostep1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting.
Is DTC P1549 indicated? Is DTC P1549 indicated?
08/08/21 14:20:25 61SNR030_110_0164
ProCarManuals.com
DYNOMITE -2009-

´´
´
´´
(#'

)
µ
µ
µ
µ µ
µ
µ
µ
DTC P16BB:
YES
NO
YES
NO YES
NO
YES
NO
11-165
Alternator B Terminal Circuit
Low Voltage
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with HDS.
3. Start the engine.
4. Check under these conditions:
A/Con
 Temperature control at maximum cool
 Blower fan at maximum speed
 Rear window defogger on
 Headlights on high beam
5. Hold the engine speed at 2,000 rpm (A/T in P or N, M/T in neutral) for 1 minute.
6. Check for Temporary DTCs or DTCs with the HDS.
Go to step 7.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the alternator and the under-hood fuse/relay box,
and check the battery performance (see page
22-67).
7. Check for poor connections or loose terminals at the alternator and the under-hood fuse/relay box
( B line).
Go to step 8.
Repair the connectors or the terminals, then
go to step 9. 8. Check for an open in the wire ( B line) between
the alternator and the under-hood fuse/relay box
( B line).
Replace the alternator (see page 4-34), then
go to step 9.
Repair open in the wire ( B line) between the
alternator and the under-hood fuse/relay box ( B
line),thengotostep9.
9. Turn the ignition switch to ON (II).
10. Reset the ECM/PCM with the HDS.
11. Do the ECM/PCM idle learn procedure (see page 11-310).
12. Start the engine.
13. Check under these conditions: A/Con
 Temperature control at maximum cool
 Blower fan at maximum speed
 Rear window defogger on
 Headlights on high beam
14. Hold the engine speed at 2,000 rpm (A/T in P or N, M/T in neutral) for 1 minute.
15. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the alternator and the under-hood
fuse/relaybox,thengotostep1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting.
Is DTC P16BB indicated?
Ar e t he connect i ons and t he t er mi nal s OK ? I s t he har ness OK ?
Is DTC P16BB indicated?
08/08/21 14:20:25 61SNR030_110_0165
ProCarManuals.com
DYNOMITE -2009-


(#'

)
µ
µ
µ
µ µ
µ
µ
µ
DTC P16BC:
