11-246Electronic Throttle Control System
DTC Troubleshooting (cont’d)
F
ECM/PCM CONNECTOR C (44P)IG1ETCS (WHT) B
ETCS CONTROL RELAY 4P CONNECTOR
17. Remove the ETCS control relay (F) from the under-
hood fuse/relay box.
18. Jump the SCS line with the HDS.
19. Disconnect ECM/PCM connector C (44P).
20. Check for continuity between ECM/PCM connector terminal C1 and body ground.
Repair short in the wire between the ECM/
PCM (C1) and the ETCS control relay, then go to
step 23.
Go to step 21. 21. Check for continuity between ETCS control relay 4P
connector terminal No. 1 and body ground.
Replace the under-hood fuse/relay box
(see page 22-65), then go to step 23.
Go to step 28.
22. Turn the ignition switch to LOCK (0).
23. Reconnect all connectors.
24. Turn the ignition switch to ON (II).
25. Reset the ECM/PCM with the HDS.
26. Do the ECM/PCM idle learn procedure (see page 11-310).
27. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the ETCS control relay and the ECM/
PCM, then go to step 1.
Troubleshooting is complete. If any other
Temporary DTCs or DTCs are indicated, go to the
indicated DTC’s troubleshooting.
Terminal side of female terminals Terminal side of female terminals
Is there continuity?
Is there continuity?
Is DTC P1659 indicated?
08/08/21 14:26:43 61SNR030_110_0246
ProCarManuals.com
DYNOMITE -2009-

Î



(#') µ
µ
YES
NO
11-318 Fuel Supply System
Fuel Pump Circuit Troubleshooting
A
PGM-FI MAIN RELAY 2 (FUEL PUMP) 4P CONNECTOR IGP UNDER-DASH FUSE/RELAY BOX CONNECTOR G (21P)
IGP (ORN)
JUMPER WIRE
UNDER-HOOD FUSE/RELAY BOX CONNECTOR E (10P) IGP (ORN)
If you suspect a problem with the fuel pump, check that
the fuel pump actually runs; when it is on, you will hear
some noise if you listen to the fuel fill port with the fuel
fill cap removed. The fuel pump should run for
2 seconds when the ignition switch is first turned on. If
the fuel pump does not make noise, check as follows:1. Turn the ignition switch to LOCK (0).
2. Remove the under-dash fuse/relay box (see page 22-66), then remove PGM-FI main relay 2 (FUEL
PUMP) (A) from the under-dash fuse/relay box.
3. Reinstall the under-dash fuse/relay box.
4. Turn the ignition switch to ON (II).
5. Measure the voltage between PGM-FI main relay 2 (FUEL PUMP) 4P connector terminal No. 4 and
body ground. Go to step 12.
Go to step 6.
6. Turn the ignition switch to LOCK (0).
7. Disconnect the under-hood fuse/relay box connector E (10P).
8. Disconnect the C101 connector at left side of engine compartment (see page 22-16).
9. Disconnect under-dash fuse/relay box connector G (21P).
10. Connect under-dash fuse/relay box connector G (21P) terminal No. 4 to body ground with a jumper
wire.
11. Check for continuity between under-hood fuse/ relay box connector E (10P) terminal No. 5 and
body ground.
Terminal side of female terminals Wire side of female terminals
Wire side of female terminals
Is there battery voltage?
08/08/21 14:29:45 61SNR030_110_0318
ProCarManuals.com
DYNOMITE -2009-



µ
µ
µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
11-319
PGM-FI MAIN RELAY 2 (FUEL PUMP) 4P CONNECTORIG1 PGM-FI MAIN RELAY 2 (FUEL PUMP) 4P CONNECTOR
IMOFPRJUMPER WIRE
IMOFPR (BRN)
ECM/PCM CONNECTOR A (44P)
 Replace PGM-FI main relay 1.
 If needed, replace the under-hood fuse/relay box
(see page 22-65).
Repair open in the wire between the under-
hood fuse/relay box and the under-dash fuse/relay
box.
12. Measure the voltage between PGM-FI main relay 2 (FUEL PUMP) 4P connector terminal No. 1 and
body ground.
Go to step 13.
 ChecktheNo.2FUELPUMP(15A)fuseinthe under-dash fuse/relay box.
 If needed, replace the under-dash fuse/relay box (see page 22-66).
13. Turn the ignition switch to LOCK (0). 14. Connect PGM-FI main relay 2 (FUEL PUMP) 4P
connector terminal No. 3 to body ground with a
jumper wire.
15. Jump the SCS line with the HDS.
16. Disconnect ECM/PCM connector A (44P).
17. Check for continuity between body ground and ECM/PCM connector terminal A15.
Go to step 18.
Repair open in the wire between PGM-FI main
relay 2 (FUEL PUMP) and the ECM/PCM (A15).
18. Remove the under-dash fuse/relay box (see page 22-66), then reinstall PGM-FI main relay 2 (FUEL
PUMP).
19. Reinstall the under-dash fuse/relay box (see page 22-66).
(cont’d)
Terminal side of female terminals Terminal side of female terminals
Terminal side of female terminals
Is there continuity?
Is there battery voltage? Is there continuity?
08/08/21 14:29:46 61SNR030_110_0319
ProCarManuals.com
DYNOMITE -2009-






µ
µ µ
µ
µ
µ
YES
NO YES
NO
YES
NO
11-320Fuel Supply System
Fuel Pump Circuit Troubleshooting (cont’d)
MRLY (GRN)
JUMPER WIRE
ECM/PCM CONNECTOR A (44P)
IMOFPR (BRN)
ECM/PCM CONNECTOR A (44P)UNDER-DASH FUSE/RELAY BOX CONNECTOR F (34P)
IMOFPR (BRN)
IMOFPR (BRN)
UNDER-DASH FUSE/RELAY BOX CONNECTOR F (34P)
20. Connect ECM/PCM connector terminal A6 to body
ground with a jumper wire.
21. Turn the ignition switch to ON (II).
22. Measure the voltage between ECM/PCM connector terminal A15 and body ground.
Go to step 23.
Replace PGM-FI main relay 2 (FUEL PUMP).
23. Turn the ignition switch to LOCK (0).
24. Reconnect ECM/PCM connector A (44P).
25. Open the SCS line with the HDS.
26. Turn the ignition switch to LOCK (0). 27. Turn the ignition switch to ON (II), and measure the
voltage between under-dash fuse/relay box
connector F (34P) terminal No. 10 and body ground
within 2 seconds.
Update the ECM/PCM if it does not have the
latest software (see page 11-227), or substitute a
known-good ECM/PCM (see page 11-7), then
recheck. If the symptom/indication goes away with
a known-good ECM/PCM, replace the original ECM/
PCM (see page 11-228).
Go to step 28.
28. Turn the ignition switch to ON (II), and measure the voltage between under-dash fuse/relay box
connector F (34P) terminal No. 10 and body ground
after 2 seconds.
Go to step 29.
If needed replace the under-dash fuse/relay
box (see page 22-66), then go to step 29.
Terminal side of female terminals
Terminal side of female terminalsWire side of female terminals
Wire side of female terminals
Is there battery voltage? Is there battery voltage?
Is there battery voltage?
08/08/21 14:29:46 61SNR030_110_0320
ProCarManuals.com
DYNOMITE -2009-

Î
Without the HDS
11-323
A
B C
E
D
A
14. Disconnect the quick-connect fitting (A): Hold the
connector (B) with one hand, and squeeze the
retainer tabs (C) with the other hand to release
them from the locking tabs (D). Pull the connector
off.
NOTE: Be careful not to damage the line (E) or other parts.
 Do not use tools.
 If the connector does not move, keep the retainer tabs pressed down, and alternately pull and push
the connector until it comes off easily.
 Do not remove the retainer from the line; once removed, the retainer must be replaced with a
new one.
15. After disconnecting the quick-connect fitting, check it for dirt or damage (see step 4 on page 11-330).
16. Do the battery terminal reconnection procedure (see page 22-68). 1. Remove the under-dash fuse/relay box (see page
22-66), then remove PGM-Fl main relay 2 (FUEL
PUMP) (A) from the under-dash fuse/relay box.
2. Reinstall the under-dash fuse/relay box.
3. Start the engine, and let it idle until it stalls. NOTE: If any DTCs are stored, clear and ignore
them.
4. Turn the ignition switch to LOCK (0).
5. Remove the fuel fill cap.
6. Do the battery terminal disconnection procedure (see page 22-68).
(cont’d)
08/08/21 14:29:48 61SNR030_110_0323
ProCarManuals.com
DYNOMITE -2009-




(#')
11-340 Fuel Supply System
Fuel Gauge Sending Unit Test
A
A
B
FUEL TANK UNIT 4P CONNECTOR
ORN
LT GRN
NOTE: For the fuel gauge system circuit diagram, refer
to the Gauges Circuit Diagram (see page 22-244). 1. Check the No. 10 METER (7.5 A) fuse in the under- dash fuse/relay box before testing.
2. Check for body electrical system DTCs.  If no DTCs are found, go to step 3.
 If DTC B1175 or B1176 is indicated, go to theindicated DTC’s troubleshooting.
3. Turn the ignition switch to LOCK (0).
4. Remove the rear seat cushion (see page 20-131).
5. Remove the rear floor upper cross-member (A). 6. Remove the access panel (A) from the floor.
7. Disconnect the fuel tank unit 4P connector (B).
8. Measure the voltage between fuel tank unit 4P
connector terminals No. 1 and No. 3 with the
ignition switch ON (II). There should be battery
voltage.
 If the voltage is OK, go to step 9.
 If the voltage is not as specified, check for: – a short in the ORN wire to ground.
– anopenintheORNorLTGRNwire.
9. Turn the ignition switch to LOCK (0).
10. Remove the fuel tank unit from the fuel tank (see page 11-334).
Wire side of female terminals
08/08/21 14:31:01 61SNR030_110_0340
ProCarManuals.com
DYNOMITE -2009-

(#'
)
11-34111-341
Low Fuel Indicator Test
F
1/2
E LOW
11. Measure the resistance between fuel tank unit 4P
connector terminals No. 1 and No. 3 with the float
at E (EMPTY), LOW (LOW FUEL INDICATOR), 1/2
(HALF FULL), and F (FULL) positions.
If you do not get the following readings, replace the
fuel gauge sending unit (see page 11-338).
F
139.8 mm (5.5 in.) 1/2
72.1 mm (2.8 in.) LOW
19.5 mm (0.77 in.) E
8.9 mm
(0.35 in.)
() 19 to
21 205.8 to
215.8 537.5 to
707 772 to
788
12. Reconnect the fuel tank unit 4P connector.
13. Remove the No. 23 BACK UP (10 A) fuse from the under-hood fuse/relay box for at least 10 seconds,
then reinstall it.
14. Turn the ignition switch to ON (II).
15. Check that the pointer of the fuel gauge indicates F with the float at F.
 If the pointer of the fuel gauge does not indicate F, replace the gauge assembly.
 If the gauge is OK, the test is complete.
NOTE:  The pointer of the fuel gauge returns to the bottom of the gauge dial when the ignition switch
is turned to ACC or to LOCK (0), regardless of the
fuel level.
 Remove the No. 23 BACK UP (10 A) fuse from the under-hood fuse/relay box for at least 10 seconds
after completing troubleshooting, otherwise it
may take up to 20 minutes for the fuel gauge to
indicate the correct fuel level. 1. Do the gauge self-diagnostic function (see page
22-241).
 If the low fuel indicator flashes, go to step 2.
 If the low fuel indicator does not flash, replace the gauge control module (tach) (see page
22-277).
2. Check for body electrical system DTCs.
 If any DTCs are indicated, do the indicated DTC’stroubleshooting.
 If no DTCs are indicated, go to step 3.
3. Do the fuel gauge sending unit test (see page 11-340).
Float
Position
Resistance
Terminal side of
male terminals
08/08/21 14:31:02 61SNR030_110_0341
ProCarManuals.com
DYNOMITE -2009-

(#'
)
11-34111-341
Low Fuel Indicator Test
F
1/2
E LOW
11. Measure the resistance between fuel tank unit 4P
connector terminals No. 1 and No. 3 with the float
at E (EMPTY), LOW (LOW FUEL INDICATOR), 1/2
(HALF FULL), and F (FULL) positions.
If you do not get the following readings, replace the
fuel gauge sending unit (see page 11-338).
F
139.8 mm (5.5 in.) 1/2
72.1 mm (2.8 in.) LOW
19.5 mm (0.77 in.) E
8.9 mm
(0.35 in.)
() 19 to
21 205.8 to
215.8 537.5 to
707 772 to
788
12. Reconnect the fuel tank unit 4P connector.
13. Remove the No. 23 BACK UP (10 A) fuse from the under-hood fuse/relay box for at least 10 seconds,
then reinstall it.
14. Turn the ignition switch to ON (II).
15. Check that the pointer of the fuel gauge indicates F with the float at F.
 If the pointer of the fuel gauge does not indicate F, replace the gauge assembly.
 If the gauge is OK, the test is complete.
NOTE:  The pointer of the fuel gauge returns to the bottom of the gauge dial when the ignition switch
is turned to ACC or to LOCK (0), regardless of the
fuel level.
 Remove the No. 23 BACK UP (10 A) fuse from the under-hood fuse/relay box for at least 10 seconds
after completing troubleshooting, otherwise it
may take up to 20 minutes for the fuel gauge to
indicate the correct fuel level. 1. Do the gauge self-diagnostic function (see page
22-241).
 If the low fuel indicator flashes, go to step 2.
 If the low fuel indicator does not flash, replace the gauge control module (tach) (see page
22-277).
2. Check for body electrical system DTCs.
 If any DTCs are indicated, do the indicated DTC’stroubleshooting.
 If no DTCs are indicated, go to step 3.
3. Do the fuel gauge sending unit test (see page 11-340).
Float
Position
Resistance
Terminal side of
male terminals
08/08/21 14:31:02 61SNR030_110_0341
ProCarManuals.com
DYNOMITE -2009-
