Disposal of Damaged ComponentsDeployment Tool Check
24-199
1. If installed in a vehicle, follow the removal
procedure for the driver’s airbag (see page 24-188),
front passenger’s airbag (see page 24-189), side
airbag (see page 24-191), side curtain airbag
(see page 24-192), seat belt tensioner (see page
24-4), and seat belt buckle tensioner (see page 24-6).
2. In all cases, make a short circuit by cutting, stripping, and twisting together the two inflator
wires.
NOTE: The driver’s and front passenger’s airbags
have dual inflators. The like color wires go to the
individual inflators.
3. Package the component in exactly the same
packaging that the new replacement part came in.
4. Mark the outside of the box DAMAGED AIRBAG NOT DEPLOYED, DAMAGED SIDE AIRBAG NOT
DEPLOYED, DAMAGED SIDE CURTAIN AIRBAG
NOT DEPLOYED, or DAMAGED SEAT BELT
TENSIONER NOT DEPLOYED so it does not get
confused with your parts stock.
5. Contact your Acura District Parts and Service Manager for instructions on how and where to
return it for disposal. 1. Connect the yellow clips to both switch protector
handles on the tool.
2. Then connect the red lead to the positive battery post and the black lead to the negative battery post.
3. Push the operation switch: The green light should come on, indicating that the tool is operating
properly and is ready for use. If the red light stays
on, the tool is faulty, and another one must be used
for the procedure.
4. Disconnect the tool clips and connectors from the protector handles and the battery.
