2005 SUBARU LEGACY Owners Manual

9-2
In case of emergency
In case of emergencyIf you park your vehicle in an emer-
gency
The hazard warning flasher should be used in day or
night to warn other drivers when you have to park your
vehicle under emergency conditions.
Avoid stopping on the road. It is best to safely pull off
the road if a problem occurs.
The hazard warning flasher can be activated regard-
less of the ignition switch position.
Turn on the hazard warning by pushing the hazard
warning flasher switch. Turn it off by pushing the
switch again.
NOTE
When the hazard warning flasher is on, the turn
signals do not work.
UB9500BA

9-3
In case of emergency
– CONTINUED –
Temporary spare tire
"Never tow a trailer when the temporary spare
tire is used. The temporary spare tire is not de-
signed to sustain the towing load. Use of the
temporary spare tire when towing can result in
failure of the spare tire and/or less stability of
the vehicle and may lead to an accident. " When a spare tire is mounted or a wheel rim
is replaced without the original pressure sen-
sor/transmitter being transferred, the low tire
pressure warning light will flash. This indicates
the tire pressure monitoring system (TPMS) is
unable to monitor all four road wheels. Contact
your SUBARU dealer as soon as possible for
tire and sensor replacement and/or system re-
setting.
Never use any temporary spare tire other than
the original. Using other sizes may result in se-
vere mechanical damage to the drive train of
your vehicle.
The temporary spare tire is smaller and lighter than a
conventional tire and is designed for emergency use
only. Remove the temporary spare tire and re-install
the conventional tire as soon as possible because the
spare tire is designed only for temporary use.
Check the inflation pressure of the temporary spare
tire periodically to keep the tire ready for use. The cor-
rect pressure is 60 psi (420 kPa, 4.2 kgf/cm 2
).
When using the temporary spare tire, note the follow-
ing: " Do not exceed 50 mph (80 km/h).
" Do not put a tire chain on the temporary spare tire.
Because of the smaller tire size, a tire chain will not fit
properly. " Do not use two or more temporary spare tires at the
same time. " Do not drive over obstacles. This tire has a smaller
diameter, so road clearance is reduced.

9-4
In case of emergency
1) Tread wear indicator bar
2) Indicator location mark
" When the wear indicator appears on the tread, re-
place the tire.NOTE
If your vehicle is an AWD type with an automatic
transmission but is neither a Turbo model nor a
3.0-liter model, deactivate its all-wheel-drive capa-
bility as follows: Before driving your vehicle with
the temporary spare tire, put a spare fuse inside
the FWD connector located in the engine compart-
ment and confirm that the “ ” warning light
comes on. The all wheel drive capability of the ve-
hicle has now been deactivated. After re-installing
the conventional tire, remove the spare fuse from
the FWD connector in order to reactivate all wheel
drive.
1
2
US9525BBUBB501BA

9-5
In case of emergency
– CONTINUED –
Flat tires
If you have a flat tire while driving, never brake sud-
denly; keep driving straight ahead while gradually re-
ducing speed. Then slowly pull off the road to a safe
place. !Changing a flat tire
"Do not jack up the vehicle on an incline or a
loose road surface. The jack can come out of
the jacking point or sink into the ground and
this can result in a severe accident." Use only the jack provided with your vehicle.
The jack supplied with the vehicle is designed
only for changing a tire. Never get under the ve-
hicle while supporting the vehicle with this jack. " Always turn the engine off before raising the
flat tire off the ground using the jack. Never
swing or push the vehicle supported with the
jack. The jack can come out of the jacking point
due to a jolt and this can result in a severe acci-
dent. 1. Park on a hard, level surface, whenever possible,
then stop the engine.
2. Set the parking brake securely and shift a manual
transmission vehicle in reverse or an automatic trans-
mission vehicle in the “P” (Park) position.
3. Turn on the hazard warning flasher and have ev-
eryone get out of the vehicle.
4. Put wheel blocks at the front and rear of the tire di-
agonally opposite the flat tire.
HS9003BA

9-6
In case of emergency
Sedan
A) Jack handle
B) Spare tire
C) Jack and tool bucket
Station wagon
A) Jack handle
B) Jack and tool bucket
C) Spare tire
5. Take out the spare tire, jack, and jack handle.
The spare tire and jack are stored under the floor of
the trunk or cargo area.
To remove the spare tire and jack, proceed as follows:
B C
AUB9211BB
A
C
B
UB9210BB

9-7
In case of emergency
– CONTINUED –
Sedan:
1. Lift the handle of the floor cover and hook the han-
dle onto the trunk edge. 2. Remove the jack handle from the back of the floor cover.
3. Take out the storage tray.
UB9222BA
UB6239BA

9-8
In case of emergency
4. Take out the jack and tool bucket.
A) Wheel nut wrench
B) Jack
5. Take the wheel nut wrench and jack out of the tool bucket.
UB9209BA
A
B
UB9213BB

9-9
In case of emergency
– CONTINUED –
6. Turn the attaching bolt counterclockwise, then take
the spare tire out. Station wagon:
1. Open the lid and hang the hook provided on the
under side of the lid on the rear edge of the roof to
keep the lid open.
UB9518BA
UB6522BA
