2005 SUBARU LEGACY Owners Manual

5-34
Audio
NOTE
The scan mode will be cancelled if you perform
any of the following steps:"
Press the “RPT” button
" Press the “RDM” button
" Select the radio mode
" Press the disc select button
" Press the “ ” button
" Turn off the power of the audio equipment.
" Turn the ignition switch to the “OFF” position.
! How to unload CDs from the player
" Ejecting a CD from the player
Of the discs loaded, you can select and remove only
one disc.0
1. Use the disc select button to select the disc to be
ejected.
123 456
UB5210AA

5-35
Audio
– CONTINUED –
2. Briefly press the “ ” button. The selected disc
will be ejected. The disc number indicator will flash at
this time. When you remove the ejected disc, the disc
number indicator will go off.
To remove more discs in succession, repeat Steps 1
and 2. "
Ejecting all discs from the player (All disc ejec-tion mode)
0
1. If you continue to press the “ ” button, the play-
er will produce beep sound and will enter the all disc
ejection mode. At this time, the disc number indicator
and “ALL EJECT” indicator will flash.
2. Remove the disc that has been ejected. The other
discs loaded will then be ejected one after another. If
you do not remove the disc that has been ejected, the
“All disc ejection mode” will be canceled.
NOTE "Avoid driving the vehicle with a CD sticking out,
because vibration might make it fall out.
UB5215BA
UB5215BA

5-36
Audio
"
If you press the “ ” button while the player is
in all disc ejection mode, the mode will be can-
celled following ejection of the disc that is current-
ly being ejected. " If you press the “CD” button while the player is
in all disc ejection mode, the player will draw in the
discs that have been ejected and play them.

5-37
Audio
– CONTINUED –
Type C audio set (if equipped)
The audio set will operate only when the ignition switch is in the “ACC” or
“ON” positions.
PUSH POWER-VOL
SEEK
SCAN
FOLDER
TUNE
TRACK
AUDIO
MP3
6 CD CHANGER P-201UE
BAL RPT
RDM
TEXTLOAD
FM AMCD
123 456
UB5205AA

5-38
Audio
!
Radio operation
! Power switch and volume control
The dial is used for both power (ON/OFF) and volume
control. The radio is turned ON and OFF by pushing
the dial and the volume is controlled by turning the di-
al. The dial can also be used for tone and balance ad-
justment. !
Tone and balance control
The volume control dial normally functions as a vol-
ume control. This dial becomes a control for Bass,
Midrange, Treble, Fader or Balance when you select
the appropriate tone and balance control mode.
Choose desired volume level for each mode by turning
the volume control dial. The control function returns to
volume control mode after about 5 seconds.
PUSH POWER-VOL
UB5206BA
PUSH POWER-VOL
UB5206CA

5-39
Audio
– CONTINUED –
"To change tone control modes
Each brief press of the “AUDIO” button changes con-
trol modes in the following sequence starting from vol-
ume control mode. (When the radio is first turned on,
the control mode is in the volume control.)
The “AUDIO” button is used for selecting the following
control modes:
AUDIO
UB5207BA
Volume
(VOLUME) Bass
(BASS) Midrange
(MIDDLE) Treble
(TREBLE)
Control mode
(Range of lev- els)
Turn
counterclockwise Turn clockwise
Bass control
(–6 to +6) For less bass sound For more bass
sound
Midrange con-
trol (–6 to +6) For less midrange
sound For more midrange
sound
Treble control
(–6 to +6) For less treble
sound For more treble
sound
Volume con-
trol (0 to 40) For less volume For more volume
HS5014BA

5-40
Audio
"
To change balance control modes
Each brief press of the “BAL” button changes control
modes in the following sequence starting from volume
control mode. (When the radio is first turned on, the
control mode is in the volume control.)
The “BAL” button is used for selecting the following control modes:
BAL
UB5208BA
Volume
(VOLUME) Balance
(BALANCE)
Fader
(FADER)
Control mode
(Range of lev- els)
Turn
counterclockwise Turn clockwise
Fader control
(R9 to F9) To increase rear
speaker volume and decrease front
speaker volume To increase front
speaker volume and decrease rear
speaker volume
Balance con-
trol (L9 to R9) To increase left
speaker volume and decrease right
speaker volume To increase right
speaker volume and
decrease left speak- er volume
Volume con-
trol (0 to 40) For less volume For more volume
HS5014BA

5-41
Audio
– CONTINUED –
!FM/AM selection button
Push the “FM” or “AM” button when the radio is off to turn on the radio.
Push the “FM” or “AM” button when the radio is on to
select FM1, FM2 or AM reception. ! Stereo indicator
The stereo indicator “ST” will come on when an FM
stereo broadcast is received. !
Tuning
" Manual tuning
Press the “ ” side of the TUNE/TRACK button to in-
crease the tuning frequency and press the tuning but-
ton marked “ ” to decrease it.
Each time the button is pressed, the frequency interval
can be changed between 10 kHz in the AM mode and
0.2 MHz in the FM mode.
If you hold down the “ ” side of the button, the tun-
ing frequency will increase continuously, and if you
hold down the “ ” side of the button, the tuning fre-
quency will decrease continuously. Release the button
when your desired frequency is reached.
FM AM
CD
UB5209BA
TUNE
TRACK
UB5211DA
