2005 SUBARU LEGACY Owners Manual

6-28
Interior equipment
Fit the top of the rear gate board into the groove in the
rear gate panel.
Stowage boxes (Station wagon)
A stowage box is located on each side of the cargo ar-
ea. You can access each one by pushing up and pull-
ing the knob on the lid.
UB6535CA
UB6533BA

6-29
Interior equipment
– CONTINUED –
Convenient tie-down hooks (if
equipped)
The convenient tie-down hooks are designed
only for securing light cargo. Never try to se-
cure cargo that exceeds the capacity of the
hooks. The maximum load capacity is 44 lbs (20
kg) per hook.
The cargo area is equipped with four tie-down hooks so that cargo can be secured with a luggage net or
ropes.
When using the tie-down hooks, turn them down out of
the storing recesses. When not in use, put the hooks
up into the storing recesses.
UB6238BA

6-30
Interior equipment
Under-floor storage compartment
The subfloor storage is located under the floor of the
trunk or cargo area and can be used to store small
items. To open the lid, pull the tab or handle up.
NOTE
When storing a flat tire, put the subfloor storage in
the trunk or cargo area.
"
Always keep the lid of the subfloor storage
closed while driving to reduce the risk of injury
in the event of sudden stop or an accident. " Do not store spray cans, containers with
flammable or corrosive liquids or any other
dangerous items in the subfloor storage. !
Sedan
UB6239BA

6-31
Interior equipment
– CONTINUED –
!Station wagon
Hang the hook provided on the underside of the lid on
the rear edge of the roof to keep the lid open. HomeLink® Wireless Control System
(if equipped)
A) HomeLink® buttons
B) Indicator light
C) Hand-held transmitter* * Not part of your vehicle’s keyless entry system but of
a HomeLink®-compatible device.
The HomeLink® Wireless Control System, located on
the driver’s sun visor, is a handy way to operate, from
inside of your vehicle, up to three remote-controlled in-
door and outdoor devices, such as garage door open-
ers, entrance gates, door locks, home lighting, and se-
UB6531BA
A
B
C
UB6219BB

6-32
Interior equipment
curity systems. There are three HomeLink® buttons
on the sun visor, each of which you can program for
operation of one desired device. For details on the de-
vice types which can be operated by this system, con-
sult HomeLink website at www.homelink.com or call 1-
800-355-3515.
Note of the following about this system:
If your vehicle is equipped with the HomeLink® Wire-
less Control System, it complies with Part 15 of the
Federal Communication Commission Rules in the U.S.
and the RSS- 210 of Ind ustry Ca nad a in C anad a.
Its operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference re-
ceived, including interference that may cause undes-
ired operation.
Changes and modifications to this system by anyone
other than an authorized service facility could void au-
thorization to use this equipment.
" When programming the HomeLink® Wireless
Control System, you may be operating a garage
door opener or other device. Make sure that
people and objects are out of the way of the ga- rage door opener or other device to prevent po-
tential harm or damage."
Do not use the HomeLink® Wireless Control
System with any garage door opener that
lacks the safety stop and reverse feature as re-
quired by applicable safety standards. A ga-
rage door opener which cannot detect an ob-
ject, signaling the door to stop and reverse,
does not meet these safety standards. Using a
garage door opener without these features in-
creases risk of serious injury or death. Formore information, consult HomeLink website
at www.homelink.com or call 1-800-355-3515.
When programming the HomeLink® Wireless
Control System to operate a garage door open-
er or an entrance gate, unplug the device’s mo-
tor from the outlet during programming to pre-
vent motor burnout.
NOTE
" After programming your HomeLink® Wireless
Control System for the desired devices, retain the

6-33
Interior equipment
– CONTINUED –
hand-held transmitters for further programming or
device testing in the event of a problem."It is recommended to insert a new battery in the
hand-held transmitter of a device to ensure cor-
rect programming. ! Garage door opener programming in the U.S.A.
NOTE
When programming the HomeLink® Wireless
Control System for a garage door opener, it is sug-
gested that you park the vehicle outside the ga-
rage.
1. Unplug the motor of the garage door opener from
the outlet. 2. Press and hold the two outside HomeLink® buttons
until the indicator light begins to flash (after 20 sec-
onds). Release both buttons.
NOTE
If any of the HomeLink® buttons are already pro-
grammed for other devices, skip step 2 because it
clears the memory of all the three buttons.
3. Hold the end of the garage door opener’s hand-
held transmitter between 1 and 3 inches (25 and 76
mm) away from the HomeLink® buttons on the driver’s
sun visor, keeping the indicator light in view.
UB6220BA

6-34
Interior equipment
4. Using both hands, simultaneously push the hand-
held transmitter button and the desired HomeLink®
button. DO NOT release the buttons until step 5 has
been completed.
5. Hold down both buttons until the HomeLink® indi-
cator light flashes, first slowly then rapidly. When the
indicator light flashes rapidly, both buttons may be re-
leased. (The rapidly flashing light indicates successful
programming of the new frequency signal.)
6. Press and hold the programmed button and check
the HomeLink® indicator light.
If the indicator light stays on continuously, your garage
door should activate and the programming is complet-
ed.
If the indicator light flashes rapidly for two seconds
and then stays on continuously, your garage door
opener may be protected by a rolling code feature. In
this case you need to perform the additional steps for
“Rolling-code-protected garage opener programming
in the U.S.A.” described below.
NOTE
Rolling-code-protected garage door openers are
manufactured after 1996. See the instruction man-
ual of your garage opener for confirmation.
7. Reconnect the motor of your garage door opener to
the outlet.
8. Test your garage door opener by pressing the pro-
grammed HomeLink® button. !
Programming rolling-code-protected
garage door openers in the U.S.A.
If your garage door opener has a rolling code feature,
program the HomeLink® Wireless Control System for
it by following steps 1 through 5 in the “Programming
garage door openers in the U.S.A.” section above and
then continuing the steps below.
NOTE
The assistance of a second person may make the
programming quicker and easier.
UB6219CA

6-35
Interior equipment
– CONTINUED –
1. Locate the training button on the garage door open-
er motor head unit. The exact location and color of the
button may vary by brand of garage door opener. If it
is difficult to locate the training button, refer to your ga-
rage door opener’s instruction manual. A) Training button
2. Press the training button on the garage door open-
er motor head unit (which activates the “training light”
on the unit). Proceed to step 3 within 30 seconds.
3. Inside the vehicle, firmly press and release the
HomeLink® button that was programmed in the sec-
tion above. Press and release the button a second
time to complete the programming procedure.
NOTE
Some garage door openers may require you to do
the above procedure a third time to complete the
programming.
UB6221BA
A
UB6222BB
