2005 SUBARU LEGACY Owners Manual

2-4
Keys and doors
Immobilizer (if equipped)
The immobilizer system is designed to prevent an un-
authorized person from starting the engine. Only keys
registered with your vehicle’s immobilizer system can
be used to operate your vehicle. Even if an unregis-
tered key fits into the ignition switch and can be turned
to the “START” position, the engine will automatically
stop after several seconds.
Each immobilizer key contains a transponder in which
the key’s ID code is stored. When a key is inserted into
the ignition switch and turned to the “ON” position, the
transponder transmits the key’s ID code to the immo-
bilizer system’s receiver. If the transmitted ID code
matches the ID code registered in the immobilizer sys-
tem, the system allows the engine to be started. Since
the ID code is transmitted and acted upon almost in-
stantly, the immobilizer system does not impede nor-
mal starting of the engine.
If the engine fails to start, pull out the key once before
trying again. (Refer to the “Ignition switch” section [chapter 3].)
This device complies with Part 15 of the FCC
Rules and with RSS-210 of Industry Canada. Oper-
ation is subject to the following two conditions: (1)
This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved
by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE
To protect your vehicle from theft, please pay
close attention to the following security precau- tions: "
Never leave your vehicle unattended with its
keys inside. " Before leaving your vehicle, close all windows
and lock the doors and rear gate. " Do not leave spare keys or any record of your
key number in the vehicle.
Do not get the key wet. If the key gets wet, wipeit dry with a cloth immediately.

2-5
Keys and doors
– CONTINUED –
!Security ID plate
A) Key number plate
B) Security ID plate
The security ID is stamped on the metal plate attached
to the key set. Write down the security ID and keep it
in another safe place, not in the vehicle. This number
is needed to make a replacement key if you lose your
key or lock it inside the vehicle.
This number is also needed for replacement or repair
of the engine control unit, integrated unit, and combi- nation meter. !
Security indicator light
The security indicator light deters potential thieves by
indicating that the vehicle is equipped with an immobi-
lizer system. It begins flashing about 60 seconds after
the ignition switch is turned from the “ON” position to
the “ACC” or “LOCK” position or immediately after the
key is pulled out.
If the security indicator light does not flash, the immo-
bilizer system may be faulty. If this occurs, contact
your SUBARU dealer as soon as possible.
In case an unauthorized key is used (e.g. an imitation
key), the security indicator light comes on.
A B
UB2534BBUB7507KA

2-6
Keys and doors
NOTE
Even if the security indicator light flashes irregu-
larly or its fuse blows (the light does not flash if its
fuse is blown), the immobilizer system will func-
tion normally. !
Key replacement
Your key number plate and security ID plate will be re-
quired if you ever need a replacement key made. Any
new key must be registered for use with your vehicle’s
immobilizer system before it can be used. Up to four
keys can be registered for use with one vehicle.
For security, all the keys registered with your vehicle’s
immobilizer system will have their ID codes erased
and re-registered when a new key is made. Therefore,
all of your vehicle’s keys must be presented when a
new key is registered. Any key that is not re-registered
when a new key is made cannot be used after the oth-
er keys are re-registered. For information on replace-
ment keys and on the registration of keys with your im-
mobilizer system, contact your SUBARU dealer.Door locks ! Locking and unlocking from the out- side
To lock the door from the outside with the key, turn the
key toward the rear. To unlock the door, turn the key
toward the front.
Lift the outside door handle to open an unlocked door.
UB2205BA

2-7
Keys and doors
– CONTINUED –
Locking without the key
1) Rotate the lock lever rearward.
2) Close the door.
To lock the door from the outside without the key, ro-
tate the lock lever rearward and then close the door. Locking without the key
1) Push the power door locking switch forward.
2) Close the door.
To lock the door from the outside using the power door
locking switch, push the switch forward (“LOCK” side)
and then close the door. In this case, all closed doors
and the rear gate (for Station wagon) are locked at the
same time.
Always make sure that all doors and the rear gate are
locked before leaving your vehicle.
NOTE
Make sure that you do not leave the key inside the
2 1
UB2535BB
LOCK
21
UB2535CB

2-8
Keys and doors
vehicle before locking the doors from the outside
without the key. !
Locking and unlocking from the inside
Keep all doors locked when you drive, especial-
ly when small children are in your vehicle.
Along with the proper use of seatbelts and child
restraints, locking the doors reduces the
chance of being thrown out of the vehicle in an
accident.
It also helps prevent passengers from falling
out if a door is accidentally opened, and intrud-
ers from unexpectedly opening doors and en-
tering your vehicle. To lock the door from the inside, rotate the lock lever rearward.
UB2536BA

2-9
Keys and doors
– CONTINUED –
To unlock the door from the inside, rotate the lock le- ver forward.
The red mark on the lock lever appears when the door
is unlocked.
Pull the inside door handle to open an unlocked door.
Always make sure that all doors and the rear gate
(Station wagon) are closed and locked before starting to drive. !Battery drainage prevention function
When a door or the rear gate is not completely closed
and the dome light, ignition switch light, and door open
warning light remain illuminated as a result, the lights are automatically turned off by the battery drainage
prevention function after 10 minutes of illumination to
prevent the battery from going dead. The operational/
non-operational setting of this function can be
changed by a SUBARU dealer. Contact the nearest
SUBARU dealer if you would like to change the set-
ting.
NOTE "
When leaving the vehicle, please make sure that
all doors and the rear gate are completely closed. " The battery drainage prevention function does
not operate while the key is in the ignition switch.
UB2505BA

2-10
Keys and doors
Power door locking switches
Driver’s switch
A) Lock
B) Unlock Front passenger’s switch
A) Lock
B) Unlock
All doors and the rear gate (Station wagon) can be
locked and unlocked by the power door locking switch-
es located at the driver’s side and the front passen-
ger’s side doors.
To lock all doors (including the rear gate of a Station
wagon), push the switch to the front (“LOCK”) position.
To unlock all doors (including the rear gate of a Station
wagon), pull the switch to the rear position.
When you close the doors after you set the door locks,
LOCK
A
B
UB2537BB
A
B
UB2206BB

2-11
Keys and doors
– CONTINUED –
the doors remain locked.
NOTE
Make sure that you do not leave the key inside the
vehicle before locking the doors from the outside
using power door locking switches. !Key lock-in prevention function
This function prevents the doors from being locked
with the key still in the ignition switch. ! Behavior with key lock-in prevention function
operative
With the driver’s door open, the doors are automatical-
ly kept unlocked even if the door locking switch is
pushed to the front (“LOCK”) position. ! Behavior with key lock-in prevention function
non-operative
" If the lock lever is turned to the rear (“LOCK”) posi-
tion with the driver’s door open and the driver’s door is
then closed with the lock lever in that position, the driv-
er’s door is locked. " If the spare key is used to lock the driver’s door from
the outside of the vehicle, the door is locked.
This function’s operative/non-operative setting can be
changed. The setting can be changed by a SUBARU dealer.
Contact a SUBARU dealer for details.
NOTE
When leaving the vehicle, make sure you are hold-
ing the key before locking the doors.
