2005 NISSAN X-TRAIL display

NAVIGATION SYSTEM
AV-41
C
D
E
F
G
H
I
J
L
MA
B
AV

Component DescriptionEKS00M7G
NAVI CONTROL UNIT

The gyro (angular speed sensor) and the DVD-ROM drive are
built-in units that control the navigation functions.

Signals are received from the gyro, the vehicle speed sensor,
and the GPS antenna. Vehicle location is determined by com-
bining this data with the data contained in the DVD-ROM map.
Location information is shown on liquid crystal display panel.
DVD-ROM Drive
Maps, traffic control regulations, and other pertinent information can
be easily read from the DVD-ROM disc.
Map DVD-ROM

The map DVD-ROM has maps, traffic control regulations, and other pertinent information.

To improve DVD-ROM map matching and route determination functions, the DVD-ROM uses an exclusive
Nissan format. Therefore, the use of a DVD-ROM provided by other manufacturers cannot be used.
Gyro (Angular Speed Sensor)

The oscillator gyro sensor is used to detect changes in vehicle steering angle.

The gyro is built into the navigation (NAVI) control unit.
GPS ANTENNA
The GPS antenna receives and amplifies the radio waves from the GPS satellites, and then transmits the GPS
signal to NAVI control unit.
PKIA0248E
PKIA0249E

AV-42
NAVIGATION SYSTEM

Antenna Route
DISPLAY

Images on the display include RGB image such as map screen
and rear view image displayed when setting the select lever to R
range.

NAVI control unit controls images on the display.
NAVI SWITCH

NAVI switch connects to the display and transfer unit with com-
munication lines. NAVI switch transmits the demand signal and
the response signal with the serial transmission.

Communication form of the operation signal is conversed in
transfer unit to NAVI switch. The operation signal is transmitted
to NAVI control unit.
PKIB9383E
PKIB9465E
PKIB9465E

NAVIGATION SYSTEM
AV-43
C
D
E
F
G
H
I
J
L
MA
B
AV

TRANSFER UNIT

Transfer unit interfaces the communication signal among NAVI
switch, display and transfer unit to the communication signal
between transfer unit and NAVI control unit.

Transfer unit outputs ON signal and voice guidance signal to
voice change relay.
VOICE CHANGE RELAY
Voice change relay converses the voice signal transmitted from audio unit and the voice guidance signal
transmitted from NAVI control unit through transfer unit. And voice change relay outputs the voice signal and
the voice guidance signal to driver-side speaker.
TMC TUNER
TMC tuner connects to NAVI control unit with a communication line.
TMC tuner transmits traffic message channel information to NAVI
control unit, and indicates the traffic message channel information on
the display. Also TMC tuner receives the receivable channel list from
NAVI control unit.
PKIB9466E
PKIB9467E

AV-44
NAVIGATION SYSTEM

System Operation DescriptionEKS00M7H
NAVIGATION SYSTEM
Here is an example of functions. For details, refer to the owner's manual or navigation system owner's manual.
MAP VIEWING STYLE

The NISSAN Navigation System gives you a choice of two map viewing styles, a normal 2-dimensional
PLAN VIEW map and 3-dimensional BIRDVIEW
® map.

The 3-dimensional BIRDVIEW® map depicts a geographic area as seen from an elevated perspective.
PLAN VIEW Map
BIRDVIEW
® Map
Description

Display area: Trapezoidal representation showing approximate
distances (Wn, D, and Wd).

Ten horizontal grid lines indicate display width while six vertical
grid lines indicate display depth and direction.

Pushing the “ZOOM IN” button during operation displays the
scale change and the view point height on the left side of the
screen.
The height of the view point increases or decreases when
“ZOOM” or “WIDE” is selected with the joystick.
SKIA1377E
SKIA1378E
SKIA5613E

NAVIGATION SYSTEM
AV-45
C
D
E
F
G
H
I
J
L
MA
B
AV

MAP DISPLAY
Function of each icon is as follows:
1. Direction indicator

This indicates the direction of the map.
2. Vehicle mark (cross pointer)

This indicates your vehicle position and the direction of travel.
3. GPS indicator

This indicates the strength of the GPS signal received.
4. Distance indicator

This indicates the distance on the screen according to the
map scale.SKIA1379E

AV-46
NAVIGATION SYSTEM

FUNCTION OF NAVI SWITCH
DEST Button
This key is used to set the destination (and way points).

Easy Mode

Expert Mode
The function of each icon is as follows:
MAP Button
The map will be displayed.
SKIA9542E
SKIA9142E
IconMode
Description
Easy Expert
Address Book×Use this category item if you want to go to places stored in the address book.
Address (City / Street)××Use this category item if you know the city name, street name and house number of the
destination (and way points).
Point of Interest (POI)××Use this category item if you want to go to a restaurant, hotel, gas station or other facility.
Phone Number×Use this category item when the destination phone number is known.
Previous Dest.×The ten previous destinations are registered automatically, thereby deleting the older ones.
Intersection×Sets a destination using the intersection of 2 streets.
City Centre×Sets the destination (way point) on the map screen of the area around the input city.
Map×Use this category item if you want to choose the place directly on the map display.
Home×When you set your home in the address book, a route home will be calculated by selecting
this key.
Help××You can see the explanation of the navigational functions.

AV-48
NAVIGATION SYSTEM

INFO Button
This button is used to show the drive information and maintenance information on the screen.

“DRIVE INFORMATION” screen is displayed when pressing
“INFO” button once.

“MAINTENANCE INFORMATION” screen is displayed when
pressing “INFO” button twice.
SKIB3592E
SKIB3593E
Display items Display/Setting contents
DRIVE INFORMATIONElapsed Time Displays driving time with a range of 0:00:00 to 9999:59:59.
Journey Distance Displays journey distance with a range of 0.0 to 99999.9.
Average Speed Displays average speed with a range of 0.0 to 999.9.
MAINTENANCE INFORMATIONReminder 1
Maintenance intervals of vehicle's consumable and setting of cycles. Reminder 2
Reminder 3

NAVIGATION SYSTEM
AV-49
C
D
E
F
G
H
I
J
L
MA
B
AV

SETTING Button
This button is used to set various navigational functions for conve-
nient use.
The function of each icon is as follows:
VOICE Button
When the guidance volume is set off, and the “VOICE” button is pushed, the guidance volume will be set to
ON, and the system will announce the current vehicle location.
BACK Button
This button has two functions:
To return to the previous screen

When this key is pushed during set-up, set-up will be cancelled, and the screen display will return to the
previous screen.
To finish the set-up

When this key is pushed after set-up is completed, the settings will be renewed as directed, and the
screen will return to the map.
ZOOM IN/ZOOM OUT Button
Use the “ZOOM IN/ZOOM OUT” button to change the scale of the display and height view.
CANCEL Button
This button has two functions:

Operation is cancelled when pushed during operation.

The “CONFIRMATION” screen is displayed during route guidance in the present location map.
DAY/NIGHT Button
To change the display brightness, push the “ ” button.
Precautions for NAVI Control Unit ReplacementEKS00F2T

When replacing the NAVI control unit, eject the map DVD-ROM before disconnecting the battery.

The NAVI control unit has the following information stored in its memory. Record the memory contents
before replacing the control unit, and input them in the new unit as necessary.
SKIA9143E
Icon Description
Display The key also adjusts the display Brightness/Contrast/Map Background.
Language This key is used to choose one of the languages shown on the display.
Navigation Changes various settings of the navigation system.
Navigation Expert Mode This key changes between Expert Mode and Easy Mode.
Guidance Volume Adjusts or turns off volume of the voice guidance.
Help (only easy mode) You can see the explanation of the navigational functions.
